Summary of Contents for GenesisBPS 2002
- Page 1 USER’S MANUAL GENES IS 2002 GENES IS 2006 PLASMA THAWING WATER BATH SYSTEM GenesisBPS, LLC 65 Commerce Way Hackensack, NJ 07601 U.S.A. Tel: 201-708-1400 866-712-5663 Fax: 201-704-1104 www.genesisbps.com 0609...
- Page 2 GENESIS 2006 SHOWN...
- Page 3 To assure proper record keeping, please retain this information for future use. DATE PURCHASED ____________________________ SERIAL # _____________________________________ DISTRIBUTOR NAME __________________________ PHONE NUMBER ______________________________ CITY, STATE __________________________________ The GENESIS THAWING SYSTEMS incorporate water bath technology with the latest engineering to enable the machine to provide plasma thawing in a minimum of time.
-
Page 4: Table Of Contents
CONTENTS page UNPACKING ............TO THAW BLOOD PRODUCTS ......TO REMOVE A THAWED BAG ......TO MAINTAIN THE DEVICE IN THE READY TO THAW STATUS ......TO CLEAN THE BATH OR TO ADD WATER .. 10 CONTROL PANEL AND INDICATORS .... 12 TROUBLESHOOTING GUIDE ...... -
Page 5: Unpacking
1. UNPACKING 1.1 The following is supplied with your GENESIS 2002/2006 unit. Control Unit Water Bath Thawing Bag Dispenser Plasma Overwrap Thawing Bags (1000/Box) Plasma Bag Holder LABath CLEAN Reference Thermometer Thawing Bag Weights User's Manual Optional Accessories : Additional Bag Weights The above items may be purchased from : GenesisBPS, LLC 866-712-5663... - Page 6 indicator will light. To correct this situation, fill bath with water as explained above. Add 2 ml of LABath CLEAN each time the water is changed to control bacterial and algae growth. The bath cleaning agent also helps to prevent the formation of turbidity and odor.
- Page 7 c. To change the default SET TEMP : You can adjust this temperature within the range of ambient to + 56 °C, in one degree increments. To adjust, press the SET TEMP key - then press the numeric key pad to indicate the temperature desired. All keys must be pressed within 5 seconds of each other.
- Page 8 thawing time may vary. The amount of air left in the plasma thawing bag during thawing will also affect thawing time. The laboratory personnel can set the desired thawing time for each unit to be thawed. They do not have to all be set for the same thaw time.
-
Page 9: To Remove A Thawed Bag
3. TO REMOVE A THAWED BAG 3.1 Press the ROCK key to stop the rocking motion. a. Remove the thawed bag (and any weights used) from the Plasma Bag Holder. Discard plasma thawing overwrap bag after each use, as they are designed for single use only. b. -
Page 10: To Clean The Bath Or To Add Water
5. TO CLEAN THE BATH OR TO ADD WATER SAFETY : NEVER ADD WATER OR MOVE THE BATH IF THE POWER SWITCH (ON THE LEFT SIDE PANEL) IS TURNED ON. RECOMMENDATION : FOR MAXIMUM SAFETY, UNPLUG THE UNITS POWER CORD FROM THE ELECTRICAL OUTLET. 5.1 TURN THE POWER SWITCH (ON THE LEFT SIDE PANEL) TO OFF POSITION TO TURN THE UNIT POWER OFF. - Page 11 when filled with water. Do not drop the bath on a hard surface. GENESIS 2006: Remove all, or part of the water. The bath weighs approximately thirty (30) pounds when filled with water. Carefully remove the water bath from the device. 5.6 DO NOT USE BLEACH OR HARSH CLEANERS.
-
Page 12: Control Panel And Indicators
6. CONTROL PANEL AND INDICATORS GENESIS 2002 CONTROL PANEL... - Page 13 GENESIS 2006 CONTROL PANEL...
- Page 14 CONTROL KEYS POWER ..This key turns the unit on and off when the POWER SWITCH on the left panel is turned ON. The POWER SWITCH on the left panel is a master on/off switch to remove electrical power completely from all circuits in the unit.
-
Page 15: Troubleshooting Guide
INDICATORS HEATING ..This red indicator is lit when the heating element is actually drawing current from the circuit and heating the water. When it reaches set temperature, the heating indicator light shuts off. FAULT .... If the water temperature exceeds 58 °C, an alarm will sound and the red fault light will be illuminated. - Page 16 2) The ADD WATER light is on and there is sufficient water in the bath. • With the unit unplugged and raised out of the water, check that there is no obstruction around the float switch in the shroud unit. The float should move freely up and down the stem approximately half-inch.
- Page 17 7) Pump does not circulate the water. • Debris may be in the pump impeller housing. Raise the shroud unit and lock in the up position. Inspect pump for debris and remove with tweezers or similar instrument. 8) HEATING light is flashing. •...
-
Page 18: Special Features
8. SPECIAL FEATURES • Thaws multiple plasma units simultaneously • Thaws standard size plasma as well as cryoprecipitate • Individual time setting for each bag location • Forced water circulation with gentle rocking motion • Compact size - saves valuable bench space •... -
Page 19: Specifications
10. SPECIFICATIONS GENESIS 2002 GENESIS 2006 21.6” L x 8.3” Wide 26.6” L x 9.6” Wide External Dimension x 13.2” High x 13.2” High 13.0” L x 7.0” Wide 18.0” L x 8.0” Wide Interior Bath Dimension x 7.5” Deep x 7.5”... -
Page 20: Ordering/Return Information
11. ORDERING/RETURN INFORMATION ORDERING INFORMATION : To place an order for a part or an accessory, please call : GenesisBPS, LLC 65 Commerce Way Hackensack, NJ 07601 U.S.A. Tel: 201-708-1400 866-712-5663 Fax: 201-704-1104 www.genesisbps.com RETURN INFORMATION : Same as above. 1. - Page 21 Hospital/Account Name Department and shipping address Name and telephone number of contact Date GENESIS 2002/2006 was purchased Serial # RGA # (Return Goods Authorization #) 6. Mark outside of box clearly, with your return address, and GenesisBPS, LLC send to .
-
Page 22: Warranty
GENESIS 2002 GENESIS 2006 PLASMA THAWING WATER BATH SYSTEM WARRANTY The GENESIS 2002/2006, Plasma Thawing Water Bath System is warranted against defects in materials and workmanship for a period of one year from the date of purchase. The warranty applies only to products that have not been tampered with, used for purposes other than those specified, or damaged through misuse, accident, dropping, neglect or other...
