- Page 1 ® Gefen TV CR Speaker GTV-CR-2SP - GTV-CR-3SP - GTV-CR-5SP User Manual www.gefentv.com...
- Page 2 Notice Gefen, LLC reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. GefenTV CR Speaker is a trademark of Gefen, LLC © 2010 Gefen, LLC, All Rights Reserved All trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
CONTENTS Introduction Operation Notes Features Panel Layout Panel Descriptions Connecting And Operating The Gefen TV CR Speaker Specifi cations Warranty... -
Page 4: Introduction
fi t stylishly in a variety of decors. The Gefen CR speakers are perfectly suited to work with any audio amplifi er, especially the GefenTV Audio Processor, for which they were designed. -
Page 5: Operation Notes
The GefenTV CR Speaker was designed to be placed within 8 inches of a wall. For this reason the GefenTV CR Speaker comes ready to be wall mounted. • Gefen recommends the GTV-MB-CRSP mounting bracket for use with these speakers. • The GefenTV CR Speaker weighs approximately 6.4 pounds. Appropriate caution should be taken when mounting these units on walls. -
Page 6: Features
FEATURES Features • Carefully designed and tuned speakers • Incredibly pristine sound from a compact design • Designed to fi ll small rooms with high-quality sound • Speaker baffl e naturally tilts upward on fl at surfaces Package Includes GTV-CR-2SP (1) CR-2SP Set of 2 Speakers (1) User’s Manual GTV-CR-3SP... -
Page 7: Panel Layout
PANEL LAYOUT Front View Back View... -
Page 8: Panel Descriptions
PANEL DESCRIPTIONS GefenTV CR Speaker Grille This removable grille will protect the speaker divers from getting damaged and will provide a stylish look to your speaker. Speaker Mounting Bracket This speaker system was designed to work with the GTV-MB-CRSP speaker bracket. -
Page 9: Connecting And Operating The Gefentv Cr Speaker
CONNECTING AND OPERATING THE GEFENTV CR SPEAKER How to Connect the GefenTV CR Speaker Connection options for the GefenTV CR Speaker are shown below: NOTE: These are 5-Way binding posts. In addition to the connectors above, this speaker will also accept Dual Banana Plug connectors. To connect all types of connectors (except for the Banana Plug type), unscrew the binding post in a counter-clockwise motion, then insert the speaker wire/ connector into the post and tighten the binding post. -
Page 10: Specifi Cations
SPECIFICATIONS System: Low Frequency Driver Low Frequency 1 x 100mm Driver with 25mm voice coil & ferrite mo- tor. Pulp paper cone coated black surrounded by NBR rubber. High Frequency Driver 1 x 25mm with Neodymium motor & silk dome. Frequency Response (-3dB) 75Hz -- 18kHz Frequency Response (-10dB) -
Page 11: Warranty
Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notifi ed within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi... - Page 13 Rev A1 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefentv.com support@gefentv.com...
