Toshiba Qosmio X500-S1801 Product Specifications

Qosmio X500 Detailed Product Specification
Model Name X500-S1801
:
C1 2
Operating System
 Genuine Windows
®
7 Professional 64-bit
3
Processor and Graphics
 Intel
®
Core™ i7-720QM Processor (Quad Core)
o 1.6 GHz (2.8 GHz with Turbo Boost Technology), 6MB L3 Cache
 Mobile Intel
®
HM55 Express Chipset
 NVIDIA
® ®
GeForce GTS 360M with 1GB GDDR5 discrete graphics
memory, plus up to 1758MB dynamically allocated shared graphics
®
memory using NVIDIA TurboCache™ technology.
Total Available Graphics memory 2782MB
o
5
Memory
 Configured with 4GB DDR3 1066MHz (max 8GB)
 2 main memory slots. Both slots are occupied.
6
Storage Drive
 500GB (7200 RPM) Serial ATA hard disk drive
 TOSHIBA Hard Drive Impact Sensor (3D sensor)
Fixed Optical Disk Drive
 Blu-ray Disc
®
ROM and DVD SuperMulti drive with Labelflash
supporting 12 formats
Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
o
CD-RW (24x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (8x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (6x)), DVD+RW (8x), DVD-
RAM (5x), BD-ROM (6x)
®
o Use Labelflash media to burn high quality labels directly to disc
8
Display
 18.4" diagonal widescreen TruBrite
native resolution (HD+)
o Native support for 720p content
o 16:9 aspect ratio
Sound
 Built-in harman/kardon
®
stereo speakers
 Dolby
® ®
Sound Theater
Input Devices
 Premium US LED backlit keyboard (black)
 TouchPad™ pointing device with multi-touch control
 TouchPad™ Enable/Disable button
 Media Control Buttons:
o TOSHIBA eco utility™ (Energy-saving mode)
o Mute
o Media
o CD/DVD control buttons
o Volume up, volume down
Communications
 Webcam and microphone
 Gigabit Ethernet
 Wi-Fi ®
Wireless networking (802.11b/g/n)
 Bluetooth ®
version 2.1 plus Enhanced Data Rate (EDR)
Expandability
 ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)
 Memory Card Reader
Secure Digital, Secure Digital High Capacity, Memory Stick™,
o
Memory Stick PRO™, Multi Media Card [shared slot]
Ports
 Video
RGB (monitor) output port
o
HDMI-CEC (REGZA LINK™)
o
 Audio
S/P DIF output port (shared with headphone port)
o
1
Part Number: PQX33U-01H01M
4
7
®
TFT LCD display at 1680 x 945
9
© Copyright 2009 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
Microphone input port
o
Headphone output port
o
 Data
o i.LINK™ IEEE-1394
o 4 USB v2.0 ports (3 USB + 1 eSATA/USB combo with USB
Sleep and Charge
RJ-45 LAN port
o
 Security
Slot for Security Lock
o
Physical Description
 Fusion™ Finish in Omega Black
 Dimensions (W x D x H ): 17.4" x 11.6" x 1.63"/1.63"
 Weight: Starting at 9.7 lbs., depending upon configuration
12
Battery
 12 cell (8000 mAh) Lithium Ion battery pack
 Battery Life Rating (measured by MobileMark™ Productivity 2007)
Included 12 cell battery: 3 hours, 18 minutes
o
Power Supply
 120W (19V x 9.5A) Auto-sensing ,100-240V/50-60Hz AC Adapter
®
 Dimensions (W x D x H): 6.73" x 3.39" x 1.63"
 Weight: starting at 1.94 lbs.
C1
Software
 Toshiba Software and Utilities
Electronic User's Guide
o
Bluetooth Stack for Windows by Toshiba
o
TOSHIBA Recovery Media Creator
o
TOSHIBA Media Controller
o
TOSHIBA Bulletin Board™
o
TOSHIBA ReelTime™
o
TOSHIBA ConfigFree
o
TOSHIBA Disc Creator
o
TOSHIBA DVD Player
o
TOSHIBA Power-saving eco utility™
o
TOSHIBA Face Recognition
o
TOSHIBA PC Health Monitor
o
Hard Disc Drive (HDD) Recovery
o
 Third-party Software
Microsoft
o
Microsoft
o
Internet Explorer 8
o
Adobe
o
Google
o
Corel
o
®
Sun
o
WildTangent
o
 Trial Software
Norton Internet Security™ 2010, 30-day trial
o
Microsoft
o
Edition, 60-day trial
 Special Offers
Toshiba Online Backup
o
Skype
o
Environmental Specifications
 This product is RoHS
 Energy Star Qualified
 EPEAT™ Gold Compliant
16
Temperature
Relative Humidity
(non-condensing)
Thermal Gradient
Qosmio X500-S1801
UPC: 883974391394
10
)
13
14
®
®
Windows Media Player
®
Works 9
® ®
Acrobat Reader
®
Toolbar
® ®
DVD MovieFactory for TOSHIBA
Java™ 2 Runtime Environment
®
Orb™ Game Console
®
Office Ready with Microsoft Office Professional 2007
®
15
compatible
Operating
5° to 35° C
20% to 80%
15° C per hour (max)
11
Non-operating
-20° to 60° C
10% to 95%
20° C per hour (max)
Page 1 of 4
