NEX-VG30H
Prosumer Interchangeable lens HD Camcorder
16.1MP Exmor
APS-C HD CMOS sensor
®
With approximately 19.5 times the surface area of conventional camcorders, the 16.1MP Exmor
®
APS-C HD CMOS sensor makes getting cinematic video with a shallow depth of field video a
breeze.
Direct power zoom w/ variable zoom speed control
The NEX-VG30 was built with an all new powered zoom seesaw lever for variable and constant
speed electronic zooming. The easily accessible lever supports 2x digital zoom that can be used
with both variable and fixed focal length lenses.
Sony E-mount 18-200mm OSS image stabilized zoom lens included
The new NEX-VG30H ships with a new Sony E-Mount 3.5-6.3 OSS zoom lens. The new lens provides
an 11x zoom ratio for superior versatility. Take advantage of 6 selectable zoom speeds. The result
is convenient and smooth zooming for your productions. Made to shoot video, it also includes
a silent auto-focus system coupled with Optical Steadyshot™ image stabilization with Active
Mode3, giving you the flexibility of a removable lens with the ergonomics and operability of a
Handycam
camcorder.
®
XGA OLED Tru-Finder™ EVF w/ eye sensor
There's never been anything quite like the Tru-Finder™ OLED electronic viewfinder. For size, speed
and brightness even after sunset, this is a gem. It begins with 2359K dots for amazing resolution
and high contrast ratio for incredible depth. OLED reduces motion blur to a bare minimum. You
can also see the results of camera adjustments in real time with superb color and detail.
Quad Capsule Spatial Array Stereo Microphone
High quality video requires high quality audio. The Quad Capsule Spatial Array stereo
microphone contains four precision placed microphone capsules that are perfectly angled at 45
degrees to provide exceptional front-side directivity and stereo separation.
Mic/Headphone jacks
Dedicated mic and headphone inputs allow for attachment of external microphones (like
shotgun microphone ECM-CG50 for pin point sound recording) and headphones to monitor
sound.
Vegas
Movie Studio HD Platinum 11
®
4
Included free of charge via download, Sony Vegas
Movie Studio HD Platinum 11 allows you to
®
easily add video effects, background music, titles, text, transitions, and much more. Everything
you need to create dramatic HD movies like a pro. Share your creations via DVD, Blu-ray Disc™
media, or upload to the web – all from one easy to use program.
4
16.1MP RAW Still Images at up to 6fps
Enjoy incredible DSLR-quality detail and clarity with 16.1MP RAW still images and even catch fast
action sequences with a continuous burst rate of up to 6fps.
Accepts DSLR A- and E-mount lenses5
Using the LA-EA2 adaptor with translucent mirror technology and a built-in AF motor (sold
separately), you can attach the full selection of A- and E-mount system lenses, which includes
all current models, dozens of Minolta A-mount lenses, and an installed base of millions of lenses
worldwide. Operational restrictions apply.
Videographers may also use the LA-EA1 mount
5
adaptor for standard A-mount lens compatibility.
Comprehensive Manual Control

Advertisement

loading
Need help?

Need help?

Do you have a question about the NEX-VG30H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sony NEX-VG30H

  • Page 1 Sony E-mount 18-200mm OSS image stabilized zoom lens included The new NEX-VG30H ships with a new Sony E-Mount 3.5-6.3 OSS zoom lens. The new lens provides an 11x zoom ratio for superior versatility. Take advantage of 6 selectable zoom speeds. The result is convenient and smooth zooming for your productions.
  • Page 2 Aperture priority, shutter speed priority or manual exposure control can all be accessed while shooting video via a control dial or easy-access buttons. With extensive manual control of Iris, you will be able to adapt to almost any lighting condition to get the best shot. CinemaTone presets and 24p recording for cinematic quality video For extra control over image expression, CinemaTone technology is used to deepen the color and recreate film-like color tones.
  • Page 3: Focus Control

    Still Image Size 3:2 L (16.0M): 4912 x 3264 M (7.1M): 3568 x 2000 S (4.0M): 2448 x 1624 HD PS:Approx.28Mbps/FX:Approx.24Mbps/FH:Approx.17Mbps/HQ:Approx.9Mbps/ Video Mode LP:Approx.5Mbps; STD HQ:9Mbps Audio Format Dolby ® Digital 5.1ch, Dolby ® Digital 5.1Creator; Dolby ® Digital 2ch stereo Microphone/Speaker Built-in Microphone/Monoral Speaker Mic Level Control...
  • Page 4 © 2012 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited.
