PRESENTER UNIT
PR921-24-A
SPECIFICATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PR921-24-A and is the answer not in the manual?

Questions and answers

Summary of Contents for Star Micronics PR921-24-A

  • Page 1 PRESENTER UNIT PR921-24-A SPECIFICATION MANUAL...
  • Page 2 All efforts have been made to ensure the accuracy of the contents of this manual at the time of going to press. However, should any errors be detected, STAR would greatly appreciate being informed of them. • The above notwithstanding, STAR can assume no responsibility for any errors in this manual. Copyright 2002 Star Micronics Co., LTD.

  • Page 3: Table Of Contents

    CONTENTS 1. GENERAL DESCRIPTION ........................ 1 Model Name Display Directions ..................... 1 2. PRINTER CONFIGURATION ......................2 3. PAPER SPECIFICATIONS (HEAT SENSITIVE PAPER) ............. 3 4. PRESENTER SPECIFICATIONS ...................... 4 Basic Operations ........................4 Operating Sequence ......................... 4 Paper Detector General Specifications ..................8 Presenter Motor General Specifications ..................

  • Page 4: General Description

    1. GENERAL DESCRIPTION The PR921 is a paper (receipts, etc.) discharging device that uses a built-in thermal printer system employed in electronic devices such as game machines, ATM and unmanned information kiosk terminals, etc. This model carries a paper (receipts, etc.) recovery function after discharge, as a standard. 1.1 Model Name Display Directions PR : Presenter...

  • Page 5: Printer Configuration

    2. PRINTER CONFIGURATION The presenter mechanism is composed of the following devices. Presenter Mechanism Drive Unit PF Roller Detector Paper Detector 1 (Reflective Photo-interrupter) Paper Detector 2 (Reflective Photo-interrupter) Paper Detector 3 (Reflective Photo-interrupter) – 2 –...

  • Page 6: Paper Specifications (Heat Sensitive Paper)

    3. PAPER SPECIFICATIONS (HEAT SENSITIVE PAPER) (1) Paper Width : 79.5 0.5 mm to 111.5 0.5 mm (2) Allowable Sheet Length : 75 to 300 mm (3) Recommended Heat Sensitive Paper : According to product specifications for TMP942-24-A. (4) Paper Thickness : 0.065 mm to 0.150 mm (5) Shaft Core Diameter : When paper thickness is Min.

  • Page 7: Presenter Specifications

    4. PRESENTER SPECIFICATIONS 4.1 Basic Operations a. Paper is not discharged from the printer while printing. b. After printing is completed, the presenter roller rotates to discharge the paper. c. The roller stops when the detector has detected the trailing edge of the paper. (Paper discharge completed) d.
  • Page 8 (1) Paper is discharged and the trailing edge of the paper is stopped in front of the PF roller. Presenter Inlet Presenter Outlet Paper Position 200 ms DC Motor Terminal Shorted and Motor Stopped Sensor 1 Sensor 2 Sensor 3 No Discrimination 1 Sensor 1 detects leading edge of paper and sensor 1 turns ON.
  • Page 9 (2) Paper Discharge Until Paper Trailing Edge is Stopped Before PF Roller Presenter Inlet Presenter Outlet Paper Position 200 ms DC Motor Terminal Shorted and Motor Stopped Sensor 1 Sensor 2 Sensor 3 No Discrimination 5 DC motor rotates clockwise by the paper discharge instruction. 6 Sensor 1 detects trailing edge of paper and sensor 1 turns OFF.
  • Page 10 (3) Paper Recovery Operation If the sensor 2 and sensor 3 detection signals are ON after a determined amount of time has passed, the paper recovery operation is performed. Presenter Outlet Presenter Inlet Paper Position 200 ms DC Motor Terminal Shorted and Motor Stopped Sensor 1 Sensor 2...

  • Page 11: Paper Detector General Specifications

    4.3 Paper Detector General Specifications The paper detector is composed of a reflective sensor and generates a set/reset signal. Absolute Maximum Rating (at 25 C) Items Symbol Rating Units Reverse Voltage Forward Current Tolerance Loss Voltage Between Collector - Emulator VCE0 Collector Current Collector Loss...

  • Page 12: Presenter Motor General Specifications

    4.4 Presenter Motor General Specifications Model: Mabuchi Motor FK-180SH Rated Voltage: 24.0 V Voltage Range for Use: 21.6 V to 26.4 V (24.0 V ±10%) Peak Current: Approximately 1.0 A (24 VDC, 25 C) Average Current: Approximately 0.2 A (24 VDC, 25 C, including at startup.) Current (A) Time (T) Usage Temperature Range: -15 C to +60 C...

  • Page 13: Connector

    4.5 Connector 4.5.1 Paper Detector and Motor Connector 2 Connector 2 Presenter Intermediate Board Pin #8: GND Black Pin #7: Sensor 3 Detection signal Black DC Motor Pin #6: Motor(+) Black Pin #5: Motor(-) Black Sensor PCB Pin #4: Sensor 2 Sensor 3 Detection signal Black...
  • Page 14 4.5.2 Example Circuit B8B-PH-K-S TA8428K HS601 VDD: 3.3V 47U_35V PRM1 IN1 OUT A PRM2 IN2 OUT B SIG 1 SIG 2 SIG 3 VDD: 3.3V M-GND HS601 4.7K PRS0 VDD: 3.3V 4.7K PRS1ADJ VDD: 3.3V HA1 7339 M-GND VDD: 3.3V PRS1 0.1U VDD: 3.3V...

  • Page 15: External Specifications

    5. EXTERNAL SPECIFICATIONS (1) External Dimensions See Figure 5-1 (2) Weight: 285 ±10g (Excluding peripheral devices) (3) External View See Figure 5-2 – 12 –...
  • Page 16 Unit: mm Figure 5-1 – 13 –...
  • Page 17 Figure 5-2 – 14 –...

  • Page 18: Ambient Specifications

    6. AMBIENT SPECIFICATIONS (1) During Operation Ambient Test (For Evaluation) Room Temperature : 23 C at 50% RH High Temperature : 50 C High Temperature/High Humidity : 37 C at 85% RH Low Temperature : Specifications Temperature : 0 C to 50 C Humidity : 10% to 80% RH (No condensation) However, 80% RH assumes 34 C.

  • Page 19: Reliability Specifications

    7. RELIABILITY SPECIFICATIONS (1) Life Presentation System: 1 million times Note 1: If not using our recommended paper type, reliability cannot be guaranteed. Therefore, you should always use the recommended paper type. Note 2: This reliability is guaranteed for receipt lengths of 100 mm or less. (2) Vibrations/Shocks from Drops (In the order of drop, vibrations) 1 Drop Shock Test Height of Drop :...

  • Page 20: Setting Paper

    8. SETTING PAPER AND USING THE ACCESSORIES 8.1 Setting Paper (See Figure 8-1) 1) Cut the leading edge of paper to be set straight across the end. 2) Insert the paper straight along the paper mounted thermal mechanism and between the presenter paper guide and paper holder.

  • Page 21: Using The Accessories (Weight Shaft And Loop Guide)

    8.2 Using the Accessories (Weight Shaft and Loop Guide) Paper thickness: Min. 0.065 to Max. 0.10 mm. (See Figure 8-2) 1) No shaft is used so fasten the 3 hooks in the 3 positions on the rear guide so that they do not get lost. 2) Fasten the loop cutter to the cutter with the 2 accessory screws.
  • Page 22 3) Rotate the paper holder and set after checking that it does not interfere with the loop guide. Note: Floating therebetween the cutter can occur because of deformation in the loop guide caused by sudden environmental changes. (See fig. 8-3) If that should occur, follow the directions above for the mounting of the loop guide and remount it so that it does not float.
  • Page 23 Paper thickness: Min. 0.10 to Max. 0.15 mm. (See Figure 8-4) 1) Fasten the shaft with the left and right hooks positioned on the Paper Holder. 2) Check that the shaft is securely fastened to the Paper Holder hooks to set it. Note 1: The 2 positions of the Paper Holder should be adjusted for the thickness of the record- ing paper, the length thereof and the environment of use.

  • Page 24: Recovering From Errors (Paper Jams)

    9. RECOVERING FROM ERRORS (PAPER JAMS) Remove jammed paper according to the directions shown in Figure 9-1 and 9-2 to recover from non-recov- erable paper jams. When doing so, always verify that the power has been turned OFF. (Procedure 1) 1) Rotate the knob in the clockwise or counterclockwise direction.
  • Page 25 (Procedure 2: When Paper Cannot be Removed with Procedure 1) 1) Remove the screws on both sides of the presenter, shown in the figure below. 2) Rotate the rear guide and remove the jammed paper. 3) After removing the jammed paper, reverse the procedure 2), then fasten the screws in their original positions.

  • Page 26: Precautions Regarding Outer Cover Designs

    10. PRECAUTIONS REGARDING OUTER COVER DESIGNS To prevent jams at the presenter discharge outlet, consider designing the casing so that recording paper does not enter between the presenter unit and the case. 1 Gap of *1 must be a maximum of 1 mm. (See Figure 10-1) 2 The dimensions of *2 must be larger than the presenter discharge outlet (2 mm), but it should be small enough that it does not block the paper discharge outlet.(See Figure 10-1) If it is too large, interfering light (from the sun, etc.) will enter from outside of the apparatus from the recording...
  • Page 27 Mechanism Presenter Storage Space Depth: Max. Approx. 100 mm Figure 10-2 – 24 –...

  • Page 28: Maintenance

    11. MAINTENANCE Perform the following maintenance periodically. Maintenance Periods: Every six months or after a million lines of printing. Location of Maintenance: Each detector and the vicinity Content of Maintenance: Clean away and paper dust or dirt and dust adhering to the detectors in the presenter.

  • Page 29: Other Precautions

    12. HANDLING THE PRESENTER 12.1 Precautions in Handling 1) Do not store or use the printer in locations that are dusty, oily or exposed to metallic dust. 2) Do not apply an unreasonable amount of force on the body. (This can disfigure the frame and lead to the printer not functioning properly.) 3) Avoid sudden changes even if the ambient temperature and humidity are within standard conditions.
  • Page 30 Figure 12 – 27 –...
  • Page 31 ELECTRONIC PRODUCTS DIVISION OVERSEAS SUBSIDIARY COMPANIES STAR MICRONICS CO., LTD. STAR MICRONICS AMERICA, INC. STAR MICRONICS U.K. LTD. 536 Nanatsushinya, 1150 King Georges Post Road, Edison, Star House, Peregrine Business Shimizu, Shizuoka, 424-0066 Japan NJ 08837-3729 U.S.A. Park, Gomm Road, High Wycombe,...
