Altec Lansing Professional SLS6221 Specification Sheet

SLS6221
System Specifications
Frequency Response:
Maximum Output:
System Power:
Satellite Power:
Subwoofer Power:
System THD (Input to Amplifier Output):
Signal-to-Noise Ratio:
Channel Separation:
Input Impedance:
Input Sensitivity:
Maximum Input Level:
Volume Control:
Treble Level Control:
Bass (Subwoofer) Level Control:
Recommended Headphone Load Impedance:
Headphone Output:
Drivers (per satellite):
Subwoofer Driver:
Cables (Supplied with SLS6221)
AC Power Requirements:
Input Connections:
Controls:
Enclosure Material & Finish:
Satellite Dimensions:
Subwoofer Dimensions:
Weight:
P
R O F E S S I O N A l
32 Hz – 18 kHz (-10 dB)
101 dB SPL (1m)
58 watts RMS @ 1% THD
7 watts RMS @ 1% THD
44 watts RMS @ 1% THD
<0.6% THD @ 1 kHz
> 78 dB
> 55 dB
10 k ohm
-11.76 dBu (200 mV RMS)
+12 dBu (3.08 V RMS)
70 dB attenuation maximum
+/- 9 dB @ 10 kHz
+/- 10 dB @ 100 Hz
32 ohms, each channel
7mW into 32 ohms, both channels driven
Six 1" / 25 mm full-range 8 ohm micro drivers
One 6.5" / 165 mm long-throw 4 ohm woofer
• Satellite: 4-pin DIN cable (3 m / 9.8 ft.) with extension (2 m / 6.6 ft.)
• Controller: 9-pin DIN cable (3 m / 9.8 ft.)
• RCA input cable (5 m / 16.3 ft.)
• 120 V AC @ 60 Hz (USA, Canada and applicable Latin American and Asian countries).
• International versions with 220 V & 230 V power supplies are available.
• Stereo RCA inputs Red (right) and White (left) on rear panel of subwoofer.
• One 3.5 mm stereo input on rear panel of subwoofer.
• One 3.5 mm auxiliary input is located on the wired control pod.
• Wired Control Pod: Rotary Up/Down Volume, Bass, Treble, and On/Standby
• Infrared Wireless Remote: Up/Down Volume, Bass, Treble, and On/Standby
• Satellites: Black injection-molded plastic with painted metal grill
• Subwoofer: Black painted 9 mm MDF with injection-molded front panel
and painted metal grill
• 2.5" (W) x 1" (D) x 14.4" (H)
• 64 mm (W) x 26 mm (D) x 365 mm (H)
• 8.5" (W) x 7.9" (D) x 16" (H)
• 216 mm (W) x 198 mm (D) x 406 mm (H)
• Shipping: 22.5 lbs (10.2 kg)
• Net weight of satellites, subwoofer and control pod: 19 lbs (8.6 kg)
AUDIO INPUT
RIGHT LEFT CONTROLLER INPUT R L
in the United States www.electrograph.com 1-800-776-5768
© 2004 Altec Lansing Professional. All rights reserved.
1000 W. Wilshire Blvd., Suite 362, Oklahoma City, OK 73116
Tel. 405-848-3108 / Fax. 405-848-3216 / proinfo@alteclansing.com
Visit www.altecpro.com
P
R O F E S S I O N A l
Proudly distributed by
Introducing a Sound Solution
for All Flat Panel Displays
Visual communication is a powerful thing, but nothing adds to the overall impact like
high-fidelity audio. Flat panel displays (FPDs) are the video communication media of choice
for corporate, institutional, retail, and commercial clients – anyone who wants to present
high-impact, high-resolution visual information.
Unfortunately, choices for FPD audio playback have been limited to low-performance,
poor-quality speaker systems. Until now.
Introducing the Altec Lansing SLS6221 system. The first professional-quality 2.1 powered
audio system specifically designed for use with FPDs. Now you can provide your clients
with high-fidelity, high-definition audio to match the quality of their video presentations.
