- Page 1 VM22TSLCD User’s Manual Speco Technologies 200 New Highway Amityville, NY 11701 800-645-5516 www.specotech.com...
- Page 3 PRECAUTION The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insulated dangerous Voltage within the product’s enclosure that may be sufficient magnitude to constitute risk of electrical shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operation and maintenance (servicing) instructions in...
- Page 4 8. Damage Requiring Service – The unit should be serviced by qualified service personnel when: The power cord or the plug has been damaged; or Objects have fallen or liquid has been spilled into the unit; or the unit has been exposed to rain or water;...
- Page 5 Touch Panel LCD: Key define AUTO: Auto-optimize displaying picture under PC mode. This “ Auto” Button can be either “Enter” function in OSD Menu) Enter: MENU: OSD menu ON / OFF control. (EXIT Item) ADJUST: Increase or decrease the value on OSD menu. Increase value or turn ON / OFF function.
- Page 6 Touch Panel LCD: Connection define ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ VGA input DVI input PC audio in VIDEO1 Video input Out: Video loop output S-VIDEO:Y/C input Audio: Audio input VIDEO2 Video input Out: Video loop output Audio: Audio input Port 1 / Port 2 (Touch setting) RS-485 connector...
- Page 7 Touch Panel LCD: OSD-Video Setting Brightness: Adjusts the overall picture shade and brightness. Contrast: Permits adjustment of contrast between light and dark areas of the picture. Saturation: Adjusts the intensity of the color. Hue: To determine the lightness and colorfulness of the picture. Sharpness: Sets the desired sharpening enhancement to the picture.
- Page 8 Touch Panel LCD: OSD-DVI(VGA) Setting Brightness: Adjusts the overall picture shade and brightness. Contrast: Permits adjustment of contrast between light and dark areas of the picture. Auto Adjustment: Picture adjustment automatic correction, like clock and phase. Image H Position: Allows adjustment for horizontal position. Image V Position: Allows adjustment for vertical position.
- Page 9 Touch Panel LCD: OSD-Audio Setting Volume: Controls built-in speakers’ output volumes. Bass: Adjusts the tone to low frequency part of the sound. Treble: Adjust the high or acute of the sound. Balance: Adjusts the softness of loudness of notes in the sound. Mute: To disable the audio function.
- Page 10 Touch Panel LCD: OSD-PIP Setting PIP Mode: This function allows the PIP mode to be selected. PIP Source: This function allows the source of the PIP to be selected. PIP Swap: This function allows the position of PIP to be exchanged. POP Zoom: Only Operate under POP (Side By Side) mode.
- Page 11 Touch Panel LCD: System Setting Aspect Ratio: To change the display mode. Auto Source Detection: The monitor will auto detect the video source when power ON. Color Temperature: Selects color temperature of either 6500°K or 9300°K. Channel Display: This function is to allow the channel title to be displayed on the monitor.
- Page 12 Touch Panel LCD: OSD-Touch Setting Left Hander: Left hander mode control. Set to ON, left hander / Set to OFF, right hander Touch Function Source: Touch mode under AV1 / AV2 / AV1:AV2. Select AV1:AV2, user can touch the AV1 or AV 2 block icon to switch AV1 or AV2 source. 4:3 Mode: LCD display ratio always 4:3 and touch icon table is always on.
- Page 13 Control mode SINGLE mode: Only one control keyboard in the system. Single mode can be includes these systems below. System A: Video RS-485 Touch panel LCD Port 1 P/T/Z Dome System B: Video Touch panel LCD RS-485 Port 2 ...
- Page 14 PTZ control mode - Single mode 1. Touch any position on the panel 2. Touch number page button into number table 3. Select PTZ(CAM) ID and call PTZ(CAM), ex: Main control Touch Icon Icon Mode Notice CAM: 000 Camera ID Call camera ID status DVR: 000 DVR ID...
- Page 15 PTZ control with number table Touch Icon Icon Mode Notice CAM: 000 Camera ID Call camera ID status DVR: 000 DVR ID Call DVR ID status MON: 000 Monitor ID Call monitor ID status AV 1 Channel 1 Video 1 input source display AV 2 Channel 2...
- Page 16 PTZ Preset Function ID corresponding table Preset ID ID + Call ID + Set count to 3 seconds 180 degree rotating Speed dome return to zero Start auto pan Set line scan left stop Set line scan right stop Speed dome OSD Menu Stop line scan Start line scan Pan / Tile Control Mode: Center / Finger.
- Page 17 DVR control mode - Single mode 1. Touch any position on the panel 2. Touch number page button into number table 3. Select DVR ID and call DVR, ex: Main control - Normal page Touch Table Icon Mode Notice CAM: 000 Camera ID Call camera ID status DVR: 000...
- Page 18 Extension page Touch Icon Icon Mode Notice CAM: 000 Camera ID Call camera ID status DVR: 000 DVR ID Call DVR ID status MON: 000 Monitor ID Call monitor ID status AV 1 Channel 1 Video 1 input source display AV 2 Channel 2 Video 2 input source display...
- Page 19 DVR control with number table Touch Icon Icon Mode Notice CAM: 000 Camera ID Call camera ID status DVR: 000 DVR ID Call DVR ID status MON: 000 Monitor ID Call monitor ID status AV 1 Channel 1 Video 1 input source display AV 2 Channel 2...
