Summary of Contents for SOYO M19GS
-
Page 2: Table Of Contents
19.0 TFT Active Matrix LCD Panel User Manual Getting Start Before You Start....................................2 Unpacking ......................................3 Hardware Installation ..................................3 Precaution......................................4 Troubleshooting ....................................4 Warning ........................................ 4 Cleaning Notices ....................................4 Menu control button.................................... 5 OSD (On-Screen Display) Menu Mode............................5-7 Display Mode ....................................... -
Page 3: Before You Start
19.0 TFT Active Matrix LCD Panel User Manual Before you start Load the two holders and the stand together, and make sure they are secure and tie Put the LCD panel set into the stand, and make sure they are secure and tie LCD monitor can be lay back 0˚... -
Page 4: Unpacking
19.0 TFT Active Matrix LCD Panel User Manual Thank you for your purchase of our LCD product. To ensure safety operation of this product, Please read the following menu carefully before using this product. Unpacking Our 19” LCD monitor shall be content with these following items. Make sure you get all these set ready, otherwise contact to your dealer or store which you purchased it. -
Page 5: Precaution
19.0 TFT Active Matrix LCD Panel User Manual Precaution Do not expose the monitor to direct sunlight or heat. Do not spill liquid on the monitor. Do not attempt to open the monitor. You may be hurt by electric shock. For service, call your place of purchase. Do not use your monitor when magnets or electronic products are operating nearby. -
Page 6: Menu Control Button
19.0 TFT Active Matrix LCD Panel User Manual Monitor Adjusting Menu control button Auto Tune: Auto tune adjust. OSD Menu/Enter: Press the button to OSD menu . Select Up : Increase the option value in OSD menu. Volume<->: Decrease the volume value Select Down: Increase the option value in OSD menu. - Page 7 19.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (Continue) Red : Adjust the pixel of red pixel. Color Adjust : Green : Adjust the RGB color. Adjust the pixel of green pixel. Blue : Adjust the pixel of blue pixel. H.
- Page 8 19.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (Continue) Translucent : OSD Timer : Adjust diaphaneity of the Adjust the timeout of OSD. OSD. D-SUB : Analogy RGB Signal Source : signal. Switch input signal source. DVI : Digital RGB signal.
-
Page 9: Display Mode
19.0 TFT Active Matrix LCD Panel User Manual DISPLAY MODE Incoming Display Mode Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz) 640X350 31.475 70.100 640X480 31.469 59.940 640X480 37.500 75.000 720X400 31.469 70.087 800X600 37.879 60.317 800X600 46.875 75.000 1024X768 48.363 60.004 1024X768 60.023... -
Page 10: Dimensional Drawings
19.0 TFT Active Matrix LCD Panel User Manual Dimensional Drawings English...
