N58L00001.eps N58FCCBBC5.eps N58RCCBBB17.eps N58BAAAAA2.eps
N58SJCAAB15.eps N58TCAAAB4.eps N58CAAAAC10.eps N58XDAAAA1.eps
N58YBAAAA4.eps N58I1151.eps W241725001.eps S241725001.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS3HF6JB0 FRS3HF6JQ0 FRS3HF6JW0 FRS3HF6JSB0
Series
R134a
Color
black
Volts
115
Wiring Diagram
241725001
Owner's Guide
241856000
Market
North America North America North America North America
Energy Guide
241868066
Service Data Sheet 240389633
Publication No.
5995510780
08/04/01
(EN/SERVICE/DCS)
R134a
R134a
R134a
bisque
white
stainless
115
115
115
241725001
241725001
241725001
241856000
241856000
241856000
241868066
241868066
241868074
240389633
240389633
240389633
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS3HF6J
137
©
Copyright
2008 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FRS3HF6JSB - 22.6 cu. Ft. Refrigerator
Summary of Contents for Frigidaire FRS3HF6JSB - 22.6 cu. Ft. Refrigerator
- Page 1 Product No. FRS3HF6JB0 FRS3HF6JQ0 FRS3HF6JW0 FRS3HF6JSB0 Series R134a R134a R134a R134a Color black bisque white stainless Volts Wiring Diagram 241725001 241725001 241725001 241725001 Owner's Guide 241856000 241856000 241856000 241856000 Market North America North America North America North America Energy Guide 241868066 241868066 241868066...
-
Page 2: Freezer Door
Publication No: 5995510780 FRS3HF6J FREEZER DOOR Stainless Handle N58FCCBBC5 04/08... - Page 3 FRS3HF6J Publication No: 5995510780 FREEZER DOOR Model Index: A FRS3HF6J (FRS3HF6JB0) B FRS3HF6J (FRS3HF6JQ0) C FRS3HF6J (FRS3HF6JW0) D FRS3HF6J (FRS3HF6JSB0) POS. NO PART NO. DESCRIPTION 241786008 A - - D Gasket-frzr door, black, magnetic 241786004 - B C - Gasket-frzr door, white, magnetic 240367301 A B C D Bin-door, frzr-upper...
-
Page 4: Refrigerator Door
Publication No: 5995510780 FRS3HF6J REFRIGERATOR DOOR Stainless Handle N58RCCBBB17 04/08... - Page 5 FRS3HF6J Publication No: 5995510780 REFRIGERATOR DOOR Model Index: A FRS3HF6J (FRS3HF6JB0) B FRS3HF6J (FRS3HF6JQ0) C FRS3HF6J (FRS3HF6JW0) D FRS3HF6J (FRS3HF6JSB0) POS. NO PART NO. DESCRIPTION 241786007 A - - D Gasket-refr door, black, magnetic 241786003 - B C - Gasket-refr door, white, magnetic 240363702 A B C D Bin-door, 2-liter...
- Page 6 Publication No: 5995510780 FRS3HF6J CABINET N58BAAAAA2 04/08...
- Page 7 FRS3HF6J Publication No: 5995510780 CABINET Model Index: A FRS3HF6J (FRS3HF6JB0) B FRS3HF6J (FRS3HF6JQ0) C FRS3HF6J (FRS3HF6JW0) D FRS3HF6J (FRS3HF6JSB0) POS. NO PART NO. DESCRIPTION 240435911 A B C D Cover-air duct 240475910 A B C D Cover-evap coil, lower 5303208309 A B C D Plug-hole, factory test 14 #...
- Page 8 Publication No: 5995510780 FRS3HF6J SHELVES N58SJCAAB15 04/08...
- Page 9 FRS3HF6J Publication No: 5995510780 SHELVES Model Index: A FRS3HF6J (FRS3HF6JB0) B FRS3HF6J (FRS3HF6JQ0) C FRS3HF6J (FRS3HF6JW0) D FRS3HF6J (FRS3HF6JSB0) POS. NO PART NO. DESCRIPTION 241657601 A B C D Shelf, flip up, wire 241657501 A B C D Shelf, fixed, freezer 241657503 A B C D Shelf, fixed upper, freezer...
- Page 10 Publication No: 5995510780 FRS3HF6J CONTROLS N58TCAAAB4 04/08...
- Page 11 FRS3HF6J Publication No: 5995510780 CONTROLS Model Index: A FRS3HF6J (FRS3HF6JB0) B FRS3HF6J (FRS3HF6JQ0) C FRS3HF6J (FRS3HF6JW0) D FRS3HF6J (FRS3HF6JSB0) POS. NO PART NO. DESCRIPTION 5308000010 A B C D Fan Blade, red, evaporator fan 215474201 A B C D Washer, "slinger", nylon, evap fan shaft 241563601 A B C D Bushing-motor mtg, (2)
- Page 12 Publication No: 5995510780 FRS3HF6J SYSTEM N58CAAAAC10 04/08...
- Page 13 FRS3HF6J Publication No: 5995510780 SYSTEM Model Index: A FRS3HF6J (FRS3HF6JB0) B FRS3HF6J (FRS3HF6JQ0) C FRS3HF6J (FRS3HF6JW0) D FRS3HF6J (FRS3HF6JSB0) POS. NO PART NO. DESCRIPTION 240333602 A B C D Condenser 218679606 A B C D Block-evap coil, styrofoam, (2) 218944001 A B C D Drier-filter, R134a System 241586801...
-
Page 14: Ice And Water Dispenser
Publication No: 5995510780 FRS3HF6J ICE & WATER DISPENSER 04/08... - Page 15 FRS3HF6J Publication No: 5995510780 ICE & WATER DISPENSER Model Index: A FRS3HF6J (FRS3HF6JB0) B FRS3HF6J (FRS3HF6JQ0) C FRS3HF6J (FRS3HF6JW0) D FRS3HF6J (FRS3HF6JSB0) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube, water, door 218976418 A B C D Tube-water inlet, inlet valve, to filter 218976419 A B C D...
-
Page 16: Ice Container
Publication No: 5995510780 FRS3HF6J ICE CONTAINER 37A 34 34 33 N58YBAAAA4 04/08... - Page 17 FRS3HF6J Publication No: 5995510780 ICE CONTAINER Model Index: A FRS3HF6J (FRS3HF6JB0) B FRS3HF6J (FRS3HF6JQ0) C FRS3HF6J (FRS3HF6JW0) D FRS3HF6J (FRS3HF6JSB0) POS. NO PART NO. DESCRIPTION 241716101 A B C D Auger-ice 241685201 A B C D Cam-drive 241734001 A B C D Container-ice, bucket only 241685101 A B C D...
-
Page 18: Ice Maker
Publication No: 5995510780 FRS3HF6J ICE MAKER 04/08... - Page 19 FRS3HF6J Publication No: 5995510780 ICE MAKER Model Index: A FRS3HF6J (FRS3HF6JB0) B FRS3HF6J (FRS3HF6JQ0) C FRS3HF6J (FRS3HF6JW0) D FRS3HF6J (FRS3HF6JSB0) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube, water, door 218976418 A B C D Tube-water inlet, inlet valve, to filter 218976419 A B C D Tube-water inlet, valve to door...
- Page 20 Publication No: 5995510780 FRS3HF6J ICE MAKER 04/08...
- Page 21 FRS3HF6J Publication No: 5995510780 ICE MAKER Model Index: A FRS3HF6J (FRS3HF6JB0) B FRS3HF6J (FRS3HF6JQ0) C FRS3HF6J (FRS3HF6JW0) D FRS3HF6J (FRS3HF6JSB0) POS. NO PART NO. DESCRIPTION 218709101 A B C D Screw, hex head, 10-32 x 0.500 240363602 A B C D Screw-shoulder 240542901 A B C D...
-
Page 22: Wiring Schematic
Publication No: 5995510780 FRS3HF6J WIRING SCHEMATIC AIR FILTER B E T A C O N T R O L FF THERMISTOR FRZ THERMISTOR 04/08... -
Page 23: Wiring Diagram
FRS3HF6J Publication No: 5995510780 WIRING DIAGRAM WHITE WHITE GRAY GRAY 04/08 # Functional Parts * Non-Illustrated Parts...
