Managing the Software

Control Panel Applications for PCs

Follow Procedure 4-4 for PC Control Panel Applications.
Page 4 - 10
Issue 02 March 02

Procedure 4-4: PC Control Panel Applications

1.
There are two methods to access the ADSL USB Modem control panel:
• From the "Control Panel" window ( Start -> Settings -> Control Panel ), double
click the ADSL USB Modem
• From the PC desktop, double click the
Note: To access the ADSL USB Modem Control Panel, the driver must be
running. Also, make sure the USB cable is plugged into the modem.
2. The "Physical Link" tab of the "ADSL USB Modem" window (Control Panel) allows
you to review the current state of the ADSL USB Modem and connection. The green
indicator in the Link Status field signifies that a connection has been made. This
indicator flashes while a connection is being established. Individual flashing yellow
indicators show the Transmitting and Receiving data activity separately.
In Commercial Confidence
icon, or
ADSL USB Modem
ADSL USB Modem - User Manual
icon in the system tray.
