Nady Audio MM-14FX Owner's Manual

4 channel mini mixer with echo effects

Advertisement

Quick Links

S P E C I F I C AT I O N S
Input Impedance................................................................................................5K Ohms
Maximum Input......................................................................................-13dBm (200mV)
Sensitivity ..................................................................................................-45dBm (8mV)
Output Impedance ..........................................................................................800 Ohms
Maximum Output........................................................................................+6.5dBm (2V)
Max Gain ................................................................................................................49.1dB
Frequency Response ..................................................................20Hz - 18KHz (+/-3dB)
THD+Noise ..............................................................................................................0.09%
S/N ............................................................................................................................-78dB
Noise Floor ............................................................................................................300uV
Current Drain ..........................................................................................................35mA
9V Battery Life ..........................................................................................up to 20 hours
Power Requirements ................................9V battery or optional PAD-1 AC/DC adapter
Dimensions ....................................................6" x 3.3" x 2" (152 mm x 84 mm x 52 mm)
Weight ......................................................................................................0.9 lbs (0.4 Kg)
SERVICE FOR YOUR NADY AUDIO PRODUCT
(U.S.) Should your NADY AUDIO product require service, please contact the Nady
Service Department via telephone at (510) 652-2411, or e-mail at service@nady.com.
(International) For service, please contact the NADY AUDIO distributor in your country
through the dealer from whom you purchased this product.
DO NOT ATTEMPT TO SERVICE THIS UNIT
YOURSELF AS IT CAN BE DANGEROUS AND
WILL ALSO VOID THE WARRANTY.
Pantone 185 Red/Black/Cool Gray 40%
BLACK
NADY SYSTEMS, INC. • 6701 SHELLMOUND STREET, EMERYVILLE, CA 94608
Tel: 510.652.2411 • Fax: 510.652.5075 • www.nady.com
BLACK
O W N E R ' S M A N U A L
MM-14FX
4 Channel Mini Mixer with Echo Effects

Advertisement

loading
Need help?

Need help?

Do you have a question about the MM-14FX and is the answer not in the manual?

Questions and answers

Summary of Contents for Nady Audio MM-14FX

  • Page 1 Weight ......................0.9 lbs (0.4 Kg) SERVICE FOR YOUR NADY AUDIO PRODUCT (U.S.) Should your NADY AUDIO product require service, please contact the Nady Service Department via telephone at (510) 652-2411, or e-mail at service@nady.com. (International) For service, please contact the NADY AUDIO distributor in your country through the dealer from whom you purchased this product.
  • Page 2 — you have purchased one of the finest microphone mixers on the market today. This unit was developed using the expertise of professional sound engineers and working musicians. You will find that your new NADY MM-14FX has superior performance and greater flexibility than any other mini mixer in its price range.
