How the keycard protection works:
Hard Drive unlock Hard Drive
Secure locked Secure with keycard
over the sensor in the
front side of the drive
To configure the 2 keycards using the "Freecom Hard Drive Keycard Protection" software
assistant, see chapter 4.
1. Front view
1. RFID sensor (invisible, is placed behind the black front bezel)
2. Left LED (green/red)
3. Right LED (white)
1. RFID sensor
This is the position where the keycard needs to be held to unlock the drive.
2. Left LED (green/red)
LED off:
LED red, flashing quickly:
Hard Drive Secure
unlocked
1. 2.
keycard protection not configured
waiting for initial recognition of the first
Keycard
Hardware Installation
Move keycard over
the sensor
Hard Drive Secure
locked
3.
