Page 1: Hardware Guide
Roku BrightSign Compact Hardware Guide PCBA: C Version: .1 Saratoga, CA, USA... -
Page 2: Table Of Contents
Table of Contents OVERVIEW ............................. 3 ............................5 ORTS ........................5 OWER ONNECTOR DB9 RS232 ......................5 CONNECTOR DB15 S /LED ....................6 WITCH CONNECTOR ............................ 9 THERNET USB ............................. 9 DB15 VGA ........................ -
Page 3: Overview
The Brightsign Compact is a device that can be used to drive a variety of HDTV and computer monitors for digital sign and kiosk applications. As well as driving the Video Display, the Compact has many different control interfaces built in to allow the sign to be controlled. - Page 4 BrightSign Compact Compact Block Diagram This information applies to a product under development. Its characteristics and specifications are subject to change without notice. Roku assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. www.rokulabs.com © Roku 2008...
-
Page 5: Ports
BrightSign Compact Ports On back of the unit: Power plug for 5V power input at 3A 10/100 Ethernet jack HDMI connector Triple RCA jacks for Component Hi-Def output (Y-Pr-Pb). DB15 VGA video connector. Stereo 1/8” mini plugs for audio output On the side of the unit: ... -
Page 6: Db15 Switch/Led Connector
500mA to an external device. The 3.3V output is polyfuse protected and can source up to 500mA. If a Brightsign is driving the inputs on another Brightsign, then you can at most drive 3 inputs from 1 output. Calculations follow showing why this is: The GPIO outputs have 100 Ohm series resistors, the inputs have 1K pullup resistors to 3.3V, and the... - Page 7 Ground Button 0 I/O DA15 female as viewed from the back of Brightsign Compact: Roku makes a button/LED/IR board that can be used to demonstrate how the GPIO and IR works. Here is the schematic to that board as an example of how to connect things to the GPIO connector: This information applies to a product under development.
- Page 8 BrightSign Compact In this example schematic, we are using a Vishay TSOP39338 IR receiver, which can operate properly on 3.3V. The TSOP39138 will also work. We are using a Honeywell SEP8506-003 IR Diode as the IR blaster output. This information applies to a product under development. Its characteristics and specifications are subject to change without notice. Roku assumes no obligation regarding future manufacturing unless otherwise agreed to in writing.
-
Page 9: Ethernet
RC to ground RC to ground RC to ground RC to ground The Brightsign Compact has a high speed (480 mbit) USB host port. Maximum cable length is 5 Meters. The port has the following pinout: pin Description pin Description... -
Page 10: 1/8" Audio Connectors
1080i video: Y from Green jack, Pr from Red jack, and Pb from Blue jack. 1/8” Audio connectors The Brightsign Compact has one 1/8” female audio connectors. The connector has a stereo audio signal. The full scale voltage output of the audio is 2V RMS, with no load. The minimum load resistance that should be connected to the audio output is 5K Ohms. -
Page 11: Power Usage
USB – 1500mA max (USB spec is 500mA, but we decided to put out more current on the USB connector just like some PCs do, in order to be able to use the Brightsign Expander in some cases without an additional 5V power supply). -
Page 12: Mechanical
BrightSign Compact Mechanical This information applies to a product under development. Its characteristics and specifications are subject to change without notice. Roku assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. www.rokulabs.com © Roku 2008... -
Page 13: Theory Of Operation
SDRAM, 1.8V for the HDMI chip, and 1.2V for the PNX8935 core voltage. Reset The Brightsign Compact has a Low Voltage Reset circuit made up of a ADM809SAKS. This circuit will hold the RESET_L signal low until a valid 3.3V power is present. -
Page 14: Hdmi Encoder
The QVCP5L video is also sent over to the TDA9984B HDMI encoder chip, which drives the HDMI data out of the Brightsign Compact. The HDMI chip is also connected to I2S audio and SPDIF audio, so that audio will be driven out the HDMI connector. The TDA9984A is capable of upscaling video to 1080P. -
Page 15: Nand Flash
BrightSign Compact NAND flash The HD2000 has a built in NAND flash. All the code for the unit is stored on the NAND flash, and it may also be possible to store some content on the NAND flash. The NAND flash is connected to the PCI/XIO bus on the PNX8950. -
Page 16: Appendix A
BrightSign Compact Appendix A Flow Chart: (for Repair Center Use) (1) Power Start No LEDs Replace Power Is the Output power Adapter adapter 5V DC Check D12 & D33 Is the Voltage of for shorts L2 = 5V? Check U17,... -
Page 17: (2) Power Led Comes On, No Serial Port Output
BrightSign Compact (2) Power LED comes on, no serial port output No serial port output Check U18, L5, C212 Is there 2.5V DC at TP18? Check U20, L6, C223 Is there 1.2V DC at TP20? Check U3, Y3, C186, C187,... - Page 18 (fullscale) is 2V RMS, with no load. Check AUD_AVCC5V power supply. D) Connect a Roku Brightsign Compact Test board to the DA15. Run the following script to test the LEDs. If any LED fails to come on, then check U8, U9, U10, U11 and the resistors on the outputs of these.
-
Page 19: General Troubleshooting Notes
BrightSign Compact General troubleshooting notes: 1) •VTT (1.25V) should be half of VDD (2.5V) This information applies to a product under development. Its characteristics and specifications are subject to change without notice. Roku assumes no obligation regarding future manufacturing unless otherwise agreed to in writing.
