  • Page 1 English US User Manual Pocket LOOX N100 Series...
  • Page 2 Support in the case of technical problems or questions, please contact: • your retailer or NAVIGON at 1-888-848-0701. • or visit the NAVIGON website at www.NAVIGON.com/PocketLOOX.
  • Page 4 This manual was produced by Xerox Global Services Published by Fujitsu Siemens Computers GmbH Issue 1 AG 01/07 Order no.: A26391-K197-Z126-1-7619...
  • Page 5 Pocket LOOX N100 Series User Manual Your Pocket LOOX Important notes Using your Pocket LOOX Troubleshooting and tips Technical data Index...
  • Page 6 Windows Mobile CE is a trademark of Microsoft Corporation. The mini SD Logo is a trademark of Secure Digital. All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged. Copyright © Fujitsu Siemens Computers GmbH 2007 All rights reserved, including rights of translation, reproduction by printing, copying or similar methods, in part or in whole.

  • Page 7: Table Of Contents

    Contents Contents Your Pocket LOOX ..............Notational conventions .
  • Page 8 Contents Removing an SD card ............. . . 31 Changing the front cover .

  • Page 9: Your Pocket Loox

    Your Pocket LOOX Your Pocket LOOX Your Pocket LOOX is equipped with the Windows CE 5.0 operating system. It combines the functions of a high quality GPS navigation system and an MP3 player plus photo and video viewers. Connect the Pocket LOOX to your computer using the USB cable and you’ll be able to exchange data easily between your computer and your Pocket LOOX.

  • Page 10: Important Notes

    NOTICE TO DRIVERS IN CALIFORNIA AND MINNESOTA: State law prohibits drivers in California and Minnesota from using mounts on their windshields while operating motor vehicles. NAVIGON does not take any responsibility for any fines, penalties, or damages that may be incurred as a result of disregarding this notice.
  • Page 11 Proper operation is understood to be operation of the product under the conditions described in this operating manual or other NAVIGON documentation. Observe the safety notes in the "Safety" manual and the following safety notes to prevent damage to your device, data loss or injuries.

  • Page 12: Traveling With The Pocket Loox

    Important notes Traveling with the Pocket LOOX Please observe the following information when you travel with your Pocket LOOX. Transporting your Pocket LOOX Transport Pocket LOOX ► Switch the Pocket LOOX off ► Disconnect the cables from the Pocket LOOX ►...

  • Page 13: Cleaning Your Pocket Loox

    Important notes Cleaning your Pocket LOOX Cleaning Notes Your Pocket LOOX Screen ► Switch the Pocket LOOX off. ► Pull the power plug out of the outlet. ► Disconnect the USB charging cable from the Pocket LOOX. The device surface can be cleaned with a dry cloth. If it is very dirty, you can clean the device and the screen with a damp cloth.

  • Page 14: Using Your Pocket Loox

    Using your Pocket LOOX Using your Pocket LOOX Your Pocket LOOX In this section you will find a description of the operating controls of your Pocket LOOX and how you operate the Pocket LOOX. Please refer to the notes in the chapter "Important notes", Page Overview of controls, ports and displays Headphone port...

  • Page 15: Getting Started

    Using your Pocket LOOX Getting started Getting started It will only take a few moments to have your Pocket LOOX up and running, ready for use. The steps you will need to work through include: • inserting the battery • connecting the power adapter •...

  • Page 16: Charging The Battery

    Using your Pocket LOOX Charging the battery Preparation for use Please observe the safety information in the "Important notes", Page 2 chapter. Your Pocket LOOX is equipped with a powerful battery. When you’re on the road your Pocket LOOX is powered by the built-in battery. Battery The battery is not charged on delivery and should be charged for 12 hours prior to the first mobile use.

  • Page 17: Battery Charging Via A Usb Port

    Using your Pocket LOOX Battery charging via a USB port Battery ► Connect the USB cable to your Pocket LOOX. ► Connect the USB cable to the computer’s USB port. The computer’s USB port must deliver no less than 500 mh of power. Because of the low charging current, the charging process will take longer than it does using the power adapter.

  • Page 18: Start Screen (Device Dependent)

    Using your Pocket LOOX Start screen (device dependent) Initial start-up Start screen The default display on your Pocket LOOX is "Portrait" format. Screenshots are shown in landscape format in the manual since they provide a better display. Information on switching between displays can be found in chapter "Set the display to portrait or landscape format.", Page Following the introduction the start screen appears.
  • Page 19 Using your Pocket LOOX A26391-K197-Z126-1-7619, edition 1...

  • Page 20: Switching The Pocket Loox On And Off

    Using your Pocket LOOX Switching the Pocket LOOX on and off Pocket LOOX Pocket LOOX Switch the Pocket LOOX on or off with the Suspend/Resume button. After certain applications or the use of certain cards, it may be necessary to restart the Pocket LOOX with the soft reset. 1 = Suspend/Resume button Switching the Pocket LOOX on and off during normal use (Suspend mode)

  • Page 21: Resetting The Pocket Loox

    Using your Pocket LOOX Resetting the Pocket LOOX Soft reset After certain applications, it may be necessary to restart the Pocket LOOX with the soft reset. Unsaved data will be lost. Shut down all programs before you restart the Pocket LOOX. ►...

  • Page 22: Using The Hold Switch

    Using your Pocket LOOX Using the hold switch Hold switch Music player Using the hold switch, you can lock the keys and the display of your Pocket LOOX to prevent entries being made inadvertently. ► To set the lock, move the hold switch (a) in the direction of the arrow (1). The keys and display of the Pocket LOOX are now locked.

  • Page 23: Multimedia

    Using your Pocket LOOX Multimedia Music player Multimedia Photo viewer Video player A number of different multimedia programs may be installed on the Pocket LOOX: • music • photo (on some models) • video (on some models) Connecting headphones or external loudspeakers Headphones Connecting Loudpspeakers...

  • Page 24: Using The Music Player

    Using your Pocket LOOX Using the music player Using Music player ► To start the music player, tap the music player symbol. The music player is started. Below are descriptions of the most important symbols for operating the music player and their respective functions: Music player: Symbols Symbol Function...

  • Page 25: Managing Music Tracks

    Using your Pocket LOOX Symbol Function Plays the last track Starts playing Stops playing Plays the next track Managing music tracks All available music titles are in the library and sorted by play lists. Titles are are displayed by play list type: all, artist, album, genre, and personal favorites. The most important symbols in the library and their respective functions are described below: Symbol Function...
  • Page 26 Using your Pocket LOOX Selecting the play list ► Select the symbol for the library: ► Tap on the desired play list, e.g. a certain album. ► Tap on to play the music tracks in the play list. The music tracks in the play list are played. A26391-K197-Z126-1-7619, edition 1...

  • Page 27: Using Photo Viewer (On Some Models)

    Using your Pocket LOOX Using Photo Viewer (on some models) To start Photo Viewer: ► Tap the Photo Viewer symbol. Photo Viewer is launched. Descriptions of the most important symbols for operating Photo Viewer and its respective functions are given below: Symbol Function Goes up one directory level...
  • Page 28 Using your Pocket LOOX Descriptions of the most important symbols for operating Photo Viewer and its respective functions are given below: Symbol Function Last photo Next photo Zoom out 1/2 , 1/3 , 1/4 ...1/8 times Zoom in 2 , 3 , 4 ...8 times Normal view of photo View of photo if rotated 90°...

  • Page 29: Using Video Player (On Some Models)

    Using your Pocket LOOX Symbol Function View of photo if rotated 90° (counter-clockwise) Closes application Rotating images does not change the image data! Only pictures stored on the Flash disk or on the inserted min SD card can be displayed. Using Video Player (on some models) Using Video Player...
  • Page 30 Using your Pocket LOOX Descriptions of the most important symbols for operating Video Player and its respective functions are given below. Video Player, symbols Symbol Function Opens the library for displaying and selecting all video tracks available on the Pocket LOOX.

  • Page 31: Managing Video Tracks

    Using your Pocket LOOX Managing video tracks In the library, all available video tracks are displayed, sorted into different types of play lists. The most important symbols in the library and their respective function are described below: Symbol Function Closes the window and applies the setting Matches the library with the expansion card.
  • Page 32 Using your Pocket LOOX ► Tap the utilities symbol. The utilities are opened: ► To start the world clock, tap the world clock symbol: ► To start the calculator, tap the calculator symbol: ► To start the Bricks game, tap the symbol for that game: A26391-K197-Z126-1-7619, edition 1...

  • Page 33: Setting Date And Time

    Using your Pocket LOOX ► To start the Smart Pixie game, tap on the corresponding symbol: Setting date and time Setting Date Setting Time ► In utilities, tap on the clock symbol: The world clock is displayed: ► Tap on the clock symbol in the upper left-hand corner: The window for setting the time and date will be opened.

  • Page 34: Data Transfer Using Usb

    Using your Pocket LOOX Data transfer using USB Data transfer You can exchange data between your Pocket LOOX and your computer using your Pocket LOOX’s mini USB connection. Pocket LOOX connecting with computer Pocket LOOX ► Switch the computer on. ►...

  • Page 35: Device Settings

    Using your Pocket LOOX Device settings Settings Device settings Calling up device settings ► Tap on the symbol for settings on your Pocket LOOX. The window for device settings will open: Adjusting the volume You can control the volume of headphones, microphones and loudspeakers separately. Adjusting Volume ►...

  • Page 36: Adjusting Screen

    Using your Pocket LOOX Adjusting screen Adjusting Screen Adjusting screen lighting Adjusting Screen lighting You can adjust your Pocket LOOX screen lighting to make it darker or brighter. Reduce the screen brightness to save energy. In addition, you can determine how many minutes the screen lighting will remain lit.

  • Page 37: Energy Management

    Using your Pocket LOOX Set the display to portrait or landscape format. Setting Display Portrait orientation Landscape orientation In addition, you can select whether the user interface is to be displayed in portrait or landscape format. ► In settings, tap on the screen symbol: ►...

  • Page 38: Displaying System Information

    Using your Pocket LOOX Configuring Suspend mode Setting: Suspend mode ► In settings, tap on the power symbol: ► Select the Waiting time icon. ► Using the slide control, set the number of minutes of non-use after which the Pocket LOOX should switch into Suspend mode during battery mode and/or mains mode.

  • Page 39: Inserting An Sd Card

    Using your Pocket LOOX Inserting an SD card ► Carefully slide the SD card into the slot (1). The SD card can protrude by a quarter (.25) of an inch or more (depending on the type of SD card). Removing an SD card SD card ►...

  • Page 40: Changing The Front Cover

    Using your Pocket LOOX Changing the front cover Changing Front cover You can individualize your Pocket LOOX using replaceable front covers. ► Carefully remove the front cover, making sure that the tabs on the front cover do not get damaged. ►...

  • Page 41: Troubleshooting And Tips

    Troubleshooting and tips Troubleshooting and tips Troubleshooting Tips Troubleshooting Troubleshooting If a fault occurs in your Pocket LOOX, try to eliminate it using the steps described in this chapter. If you cannot correct the problem, proceed as follows: ► Make a note of the steps and the circumstances that led to the fault. Also make a note of any error messages displayed.

  • Page 42: The Pocket Loox Does Not Start After Being Switched On

    Troubleshooting and tips The Pocket LOOX does not start after being switched on Cause Troubleshooting The battery is dead. ► Connect the power adapter to the Pocket LOOX to charge the battery. The battery will be charged. The power-on indicator lights up red. The AC adapter is not ►...

  • Page 43: No Sound Or Minimal Volume

    Customer Service Hotline/help desk If you are unable to solve a certain problem, please contact NAVIGON Customer Service at 888-848-0701. Additional details are contained in the "Safety " and "Warranty" manuals. Please have the following information ready when you call: •...

  • Page 44: Technical Data

    Technical data Technical data Technical data Data Pocket LOOX Technical datas General Processor SAMSUNG SC32442 300 MHz Main memory 0 MB – 4 GM ROM (depending on model) 64 Mbyte RAM CE, FCC Part 15 Class B, EN 60950-1, cUL, UL Electrical data Regulations complied with CE, FCC Part 15 Class B, EN 60950-1, cUL, UL...

  • Page 45: Ac Adapter

    Technical data AC adapter Technical data AC adapter Primary: 100 V - 240 V (automatic) • Rated voltage: 50 Hz - 60 Hz (automatic) • Rated frequency: Secondary: 5 V ±5% • Rated voltage: 1.0 A ±5 % • Max. rated current: A26391-K197-Z126-1-7619, edition 1...

  • Page 46: Index

    Index Index setting 29 AC adapter Displaying connecting 8 System information 30 technical data 37 Adjusting screen 28 Energy management 29 screen lighting 28 Energy saving functions 29 volume 27 Exanpable stylus 6 Alarm 25 Expansion card handling 30 Battery capacity 4 Factory default settings 13 charging 8...
  • Page 47 Index removing 31 Mini USB port 6 Setting Multimedia 15 date 25 Music player 15 display 29 Hold switch 14 time 25 using 16 Setting: Music player: Symbols 16 Suspend mode 30 Settings device 27 Smart Pixie 23 No sound 35 Soft reset Notes carrying out 13...
  • Page 48 Index Utilities using 23 World clock 23 Video player 15 Your Pocket LOOX Video Player cleaning 5 using 21 using 6 Video Player, symbols 22 Volume adjusting 27 Volume, minimal 35 A26391-K197-Z126-1-7619, edition 1...
