Summary of Contents for Enviro Alert EA800

  • Page 1 Electronic Multi-Zone Environmental Alarm System Installation/Owner’s Manual D-011-0152...
  • Page 2 Limitations of the Alarm System or Device While your alarm system or device is reliable and sophisticated, it does not offer guaranteed protection against burglary, fire or other emergency. Any security product, whether commercial or residential, is subject to compromise or failure-to-warn for a variety of reasons. These include: •...

  • Page 3: Table Of Contents

    Preparation... 17 Installation ... 21 Tools and Supplies Required... 21 Power Requirements ... 21 Mounting the EA800 Rear Plate ... 21 Install the Wired Sensors ... 22 EA800 Base Unit Power Connections ... 22 Install the Wireless Sensors... 22 Connecting Wired Temperature, Contact Closure, and Water Bug Sensors... 24 Connecting Wired HA-III+ Humidity Sensors ...
  • Page 4 Viewing the Sensor Log ... 53 Viewing Firmware Information ... 53 Viewing RF Information... 54 Maintenance ... 55 Locking and Unlocking the EA800 ... 55 Pausing Monitoring and Cancelling Pause ... 56 Adding a Sensor ... 57 Replacing a Sensor... 57 Editing Sensor Parameters ...

  • Page 5: General Information

    Any sensor with a 4-20mA interface ■ The EA800 base unit may be mounted directly to a 3-gang electrical enclosure or to walls. The wireless sensors are easily mounted to the wall. Figure 1 shows the base unit and a wireless sensor.

  • Page 6: How To Use This Manual

    This manual is organized into sections that guide you through the installation process, then describe how to use the EA800 and change its programmed settings if necessary. Some troubleshooting guidelines are provided, and the appendices contain forms for you to photocopy and use to record the programmed settings of the EA800 and the monitoring system setup.

  • Page 7: Block Diagrams

    Figure 2 EA800 Environmental Alarm System Block Diagram The EA800 can be made part of a larger security system as shown in Figure 3. In a security system there may be more than one EA800 installed along with other components such as the Winland EA200 or EA400 multi-zone environmental alarm systems.

  • Page 8: Symbols On The Product Or Manual Labeling

    • FCC ID: device must accept any interference received, including interference that may cause V5SEA800-031108 undesired operation. • IC: 7635A-EA800 Caution Statement (per CFR 15.21): Changes or modifications not expressly approved by the party responsible for compli- Models: EA-WMFS, ance could void the user’s authority to operate the equipment.

  • Page 9: Monitoring Screens

    Monitoring Screens The EA800 user interface is menu-based. During normal system monitoring, one of the following three screens is displayed depending on the current state of the programmed sensors: The MONITORING (home) screen is displayed when there are no active alarms. The screen lists all programmed sensors connected to the base unit and their current reading or state.

  • Page 10: Keys

    If a new alarm originating from a different sensor occurs within this 10-minute period, the audible alarm and aux relay are reactivated, and require another key press to silence the audible alarm. Figure 4 EA800 Base Unit Keys Function D-011-0152...

  • Page 11: Base Unit Connections

    Base Unit Connections Figure 5 shows the EA800 base unit's connections and Table 3 describes the functions of each connection. Note: The base unit has four wired sensor inputs and four wireless RF sensor inputs. Power Power Output 1 Output 2...

  • Page 12: Access Control And Passwords

    Access Control and Passwords The EA800 base unit is normally locked to prevent unauthorized use. The currently active function of the F1 soft key (UNLOCK or LOCK) is displayed above the key. The locked and unlocked states are described below.

  • Page 13: System Configuration Parameters

    System Configuration Parameters The EA800 base unit requires certain system level information as outlined in Table 4. Table 4 System Configuration Parameters Parameter Selections Date Format • MM/DD/YYYY • DD/MM/YYYY Time Format • 12-hour • 24-hour Data Collec- • 30 seconds tion Fre- •...

  • Page 14: Sensors

    Sensors Sensors A variety of sensors may be used with the EA800 base unit to provide environmental status and information. These include the following: Wired Sensors: Relays 1 through 4 are for use with sensors wired to the base unit. Wired sensors can be any ■...

  • Page 15: Humidity Sensors

    4-20mA Sensors Theory of Operation Industry standard 4-20mA sensors can be used with the EA800. However, it is important to verify that this type of sensor will operate properly over the entire output range. Figure 6 shows an example of the loop circuit for a 4-20mA sensor whose minimum operating voltage is 8V or less when connected to an EA800 base unit that is powered with 12VDC.

  • Page 16: Power Supply / Sensor Voltage Selection

    Figures 6 and 7 show an EA800 drop of 4.0 VDC. This value accounts for the voltage drop generated by connecting the 4-20mA sensor to the EA800 using 1000 feet of 22 AWG wire.

  • Page 17: Water Sensors

    Part Number Wireless PN M-001-0127 Multi-Function Contact Closure Sensors Table 10 lists the contact closure sensors compatible for use with the EA800 Alarm System. Table 10 EA800 Compatible Closure Sensors Sensor NO closure Normally open contact closure such as door contacts, motion detectors,...

  • Page 18: Sensor Parameter Descriptions

    Sensors Sensor Parameter Descriptions This section provides a description of each sensor parameter. Table 11 Sensor Parameter Descriptions Parameter Applicable to Sensors Sensor Name All Unit of • Blue, Red and White Measure temperature sensors • 4-20mA sensor • Wireless temperature sensors Resolution 4-20mA sensor...

  • Page 19: Relay Operation

    Relay State: Energized Alarm: Power is removed from the relay coil as shown below. This provides for a default alarm if the EA800 loses power in addition to the sensors' alarms. Active Condition: Sets the alarm to be active when an alarm condition exists.
  • Page 20 Relay Operation D-011-0152...

  • Page 21: Preparation

    EA800 alarm system installation you are currently working on. Draw a floor plan for the facility where you will install the EA800 alarm system. Identify important details such as the coolers, doors, computer rooms, etc. An example is shown below.
  • Page 22 Enter the sensor information in the copy of the EA800 Wiring Diagram you made. It is a good idea to name each sensor on this diagram and use that name in both the EA800 Wiring Diagram and the System Configuration Record.
  • Page 23 Figure 9 Typical Alarm Loop Wiring Configuration (External Power) From 11-26VDC J8 Output 1 NO COM NC To "alarm-on-closed" To alarm + supplied via EA800) Figure 10 Typical Alarm Loop Wiring Configuration (Self-Powered) D-011-0152 Input 1 Input 2 Input 3 Input 4 Power Output 3...
  • Page 24 System Configuration for a description of each system level parameter. When you have completed the previous steps you are ready to proceed to physically install the EA800 base unit and its associated sensors using the documentation you have just created.

  • Page 25: Installation

    The base unit has a removable rear plate that may be attached to a 3-gang electrical enclosure or directly to a wall. Remove the rear mounting plate from the base unit as follows: Pull the rear mounting plate down and away from the EA800 main chassis. The retainer tabs on the main ■...

  • Page 26: Install The Wired Sensors

    If Aux Power Out is to be used, connect + and - leads to AUX POWER OUT (+) and (-) on J5 using a terminal block adapter. Install the Wireless Sensors If the EA800 base unit will be connected to a remote alarm panel, do not connect CAUTION the base unit to the alarm panel until after sensor connection and configuration is complete.
  • Page 27 Temporarily mount the front panel of the base unit to the mounted rear panel. Connect power to the EA800. The EA800 completes its boot process and the MONITORING or NO SENSORS INSTALLED (if there are currently no wireless sensors installed) screen is displayed.

  • Page 28: Connecting Wired Temperature, Contact Closure, And Water Bug Sensors

    Strip the ends of each of the sensor's wires as indicated by the gauge on adapter you just removed. Insert the stripped wire ends into screw terminals of the adapter as indicated by the EA800 Wiring Diagram you completed in the preparation phase. There is no need to observe polarity when connecting sensor wires. See Figure 14.

  • Page 29: Connecting Wired Ha-Iii+ Humidity Sensors

    Strip the ends of each of the sensor's wires as indicated by the gauge on adapter you just removed. Insert the stripped wire ends into screw terminals of the adapter as indicated by your EA800 Wiring Diagram you completed in the preparation phase. Observe proper polarity. See Figure 15.

  • Page 30: Connecting Wired 4-20Ma Sensors

    Strip the ends of each of the sensor's wires as indicated by the gauge on adapter you just removed. Insert the stripped wire ends into screw terminals of the adapter as indicated by your EA800 Wiring Diagram you completed in the preparation phase. Observe proper polarity. See Figure 15.

  • Page 31: Connecting The Ea800 Alarm Outputs

    To prevent the System Alarm from going off, you must program at least 1 connected sensor into the EA800 base unit prior to the end of the 30-minute alarm time-out. If the alarm buzzer sounds press the Alarm Silence key to temporarily silence the alarm buzzer.

  • Page 32: Accessing The Main Menu For Programming

    Note: Because there are no sensors programmed into the EA800 base unit the buzzer will sound when the timer reaches 00:00 seconds. Press You can now access the MAIN MENU programming functions.
  • Page 33 Enter the SYSTEM menu and then select the CONFIGURATION menu as shown below. The default date format is MM/DD/YYYY. If you prefer DD/MM/YYYY format, from the CONFIGURATION menu, set the DATE FORMAT as appropriate for your region. Press F3 to confirm your selection. When the CONFIGURATION menu is displayed, skip TIME FORMAT if you want to use the default time format of 24-hour clock.
  • Page 34 Press F3 to confirm your selection. When the CONFIGURATION menu is displayed, press F1 to return to the MAIN MENU. You have configured the EA800 system settings. Proceed to the next section to set the time and date. Choose appropriate setting.

  • Page 35: Setting The Current Date

    Setting the Current Date Unlock the EA800 to continue programming if necessary. See “Accessing the MAIN MENU for Programming” on page 28. From the MAIN MENU, use the arrow keys to select SYSTEM, then select Set Date and set the current date as shown below.

  • Page 36: Setting The Time

    Note: time in 24-hour (military time) format. You have set the time for the EA800. Proceed to the next section to add wireless sensors. If you are not adding wireless sensors, skip to “Adding Wired Sensors” on page 43. Example shown, set values as appropriate for your system.

  • Page 37: Adding Wireless Sensors

    Select SENSORS from the MAIN MENU and follow the steps in the following diagram. After you press the ENTER key, the NEW WIRELESS SENSOR screen is displayed. The EA800 searches for new wireless sensors, indicated by an arrow that moves from left to right across the screen. When an available wireless sensor has been detected, it is listed in the SELECT SENSOR screen as shown below.
  • Page 38 Adding Wireless Sensors Note: To enter numeric values, use the arrow keys. To advance the cursor to the next digit when entering numeric values, press the NEXT soft key (F3). To return to a previous digit, press the PREV soft key (F2). The Hysteresis setting helps prevent alarms from being set and reset continually if the environment is at or near the alarm set point by providing an acceptable variance.

  • Page 39: Adding A Wireless Multi-Function Sensor Using A Wired Temperature Sensor

    Select SENSORS from the MAIN MENU and follow the steps in the following diagram. After you press the ENTER key, the NEW WIRELESS SENSOR screen is displayed. The EA800 searches for new wireless sensors, indicated by an arrow that moves from left to right across the screen. When an available wireless sensor has been detected, it is listed in the SELECT SENSOR screen as shown below.
  • Page 40 Adding Wireless Sensors When setting numeric values, use the arrow keys to change the value. Use the PREV and NEXT soft keys to move the cursor to the next or previous digit. Press the ENTER key to enter the value. Example shown, set values as appropriate for your system.

  • Page 41: Adding A Wireless Humidity Sensor

    Select SENSORS from the MAIN MENU and follow the steps in the following diagram. After you press the ENTER key, the NEW WIRELESS SENSOR screen is displayed. The EA800 searches for new wireless sensors, indicated by an arrow that moves from left to right across the screen. When an available wireless sensor has been detected, it is listed in the SELECT SENSOR screen as shown below.

  • Page 42: Adding A Wireless Multi-Function Sensor Using A Wired Waterbug Sensor

    Select SENSORS from the MAIN MENU and follow the steps in the following diagram. After you press the ENTER key, the NEW WIRELESS SENSOR screen is displayed. The EA800 searches for new wireless sensors, indicated by an arrow that moves from left to right across the screen. When an available wireless sensor has been detected, it is listed in the SELECT SENSOR screen as shown below.
  • Page 43 Example shown, set values as appropriate for your system. D-011-0152 This is the start screen for the next sensor to be added, if any. Installation...

  • Page 44: Adding A Wireless Multi-Function Sensor Using A Wired Contact Closure Sensor

    Select SENSORS from the MAIN MENU and follow the steps in the following diagram. After you press the ENTER key, the NEW WIRELESS SENSOR screen is displayed. The EA800 searches for new wireless sensors, indicated by an arrow that moves from left to right across the screen. When an available wireless sensor has been detected, it is listed in the SELECT SENSOR screen as shown below.
  • Page 45 Example shown, set values as appropriate for your system. N.O. Contact N.C. Contact Select as appropriate. D-011-0152 This is the start screen for the next sensor to be added, if any. Installation...

  • Page 46: Verify Wireless Signal Strength

    Adding Wireless Sensors Verify Wireless Signal Strength After temporarily mounting the wireless sensors in the desired location, verify the signal strength at the base unit by performing the following procedure to verify the signal strength of each programmed wireless sensor. It may take as long as 30 seconds to acquire the current signal strength.

  • Page 47: Adding Wired Sensors

    Adding Wired Sensors Low temperature sensors - Blue Thermistor Probes: See “Adding a Wired Temperature Sensor” on page 43. ■ High temperature sensors - Red Thermistor Probes: See “Adding a Wired Temperature Sensor” on page 43. ■ Ultra Low temperature sensors - White Thermistor Probes: See “Adding a Wired Temperature Sensor” on ■...

  • Page 48: Adding A Wired Ha-Iii+ Humidity Sensor

    Adding Wired Sensors Adding a Wired HA-III+ Humidity Sensor To add an HA-III+ humidity sensor perform the following procedure. Example shown, set values as appropriate for your system. NOTE: The sensor number must match the input number (J6 ) used by the sensor or an alarm may result.

  • Page 49: Adding A Wired Waterbug Sensor

    Adding a Wired WaterBug Sensor To add a WaterBug sensor perform the following procedure: Note: A supervised WaterBug sensor must be used. Example shown, set values as appropriate for your system. NOTE: The sensor number must match the input number (J6 ) used by the sensor or an alarm may result.

  • Page 50: Adding A Wired Contact Closure Sensor

    Adding Wired Sensors Adding a Wired Contact Closure Sensor The following procedure shown adds a N.O. contact closure sensor but is the same for N.C. contact closure sensor. Example shown, set values as appropriate for your system. NOTE: The sensor number must match the input number (J6 ) used by the sensor or an alarm may result.

  • Page 51: Adding A 4-20Ma Sensor

    Adding a 4-20mA Sensor To add a 4-20mA sensor, perform the following procedure. There are some additional parameters to configure with this type of sensor, including Unit of Measure and Resolution. 4-20mA sensors can be used for monitoring a variety of conditions because the measured value corresponds to a current level, which is configured to represent the conditions being monitored.

  • Page 52: Configuring The Relays

    Configuring the Relays Configuring the Relays When all sensors have been added, you must configure the relays so that the outputs indicate the monitored conditions correctly. Perform the following procedure to configure all relays used: Note: The default relay settings are: •...

  • Page 53: Operation

    ■ Monitoring Environmental Conditions The current environmental conditions measured by each sensor connected to the EA800 base unit are shown on the home screen. Depending on the current sensor status the home screen may be one of the following screens: MONITORING screen: This screen is shown when there are no active alarms or pending alarms.

  • Page 54: Viewing Sensor Settings

    To view the current readings of a sensor with an active alarm: There are six conditions that may be shown in the alarm screen: Comm: Indicates that the wireless sensor is not communicating with the EA800. ■ High: The sensor's current reading is greater than the programmed high threshold.

  • Page 55: Viewing The Alarm Log

    Viewing the Alarm Log This alarm log is a quick view of the 20 most recent alarms. Up to 100 alarms can be reviewed by selecting Data Log from the MAIN MENU, then selecting View Alarm Log. To review the alarm history and review a specific alarm stored in the log, perform the following procedure.

  • Page 56: Viewing Limit Settings

    To view the current readings and the limits of a sensor that is not in an alarm state perform the following procedure: Viewing the Event Log The EA800 Alarm System logs up to 100 events in its Event Log. At the minimum, the following events are logged: System power on: the date and time when the EA800 was powered on.

  • Page 57: Viewing The Sensor Log

    100 data sets are stored in the sensor log. To view the sensor log, perform the following procedure: Viewing Firmware Information The About EA800 menu item displays the currently running firmware version. To view the firmware version, do the following: Note: The firmware revision number shown indicates the firmware version currently installed.

  • Page 58: Viewing Rf Information

    Viewing RF Information Viewing RF Information The ABOUT RF screen displays the EA800 base unit’s MAC address, the RF channel currently in use, the RF communications protocol version, and the RF subsystem’s firmware version. To view the RF settings, perform the following procedure: Note: The firmware revision number shown indicates the firmware version currently installed.

  • Page 59: Maintenance

    The current state of the EA800 is indicated by the text above the F1 soft key when the home screen is displayed: When UNLOCK is displayed, the base unit is locked. Press F1, use the PREV and NEXT soft keys to advance ■...

  • Page 60: Pausing Monitoring And Cancelling Pause

    To prevent false alarms when performing maintenance, pause sensor monitoring. Pausing stops monitoring and ignores active alarms for a 30-minute period. When the pause function times out, monitoring automatically starts. To pause the EA800 perform the following procedure: Unlock as shown in “Locking and Unlocking the EA800”...

  • Page 61: Adding A Sensor

    Update the system’s Configuration Worksheets to document any changes. Replacing a Sensor The EA800 allows you to replace an existing, programmed wireless sensor with another of the same type. When replaced, the original sensor’s programmed settings and parameters are retained and applied to the new sensor. If you need to change settings other than those provided in the Edit Sensor screen, you must delete the existing sensor and then add the replacement sensor.

  • Page 62: Editing Sensor Parameters

    The unit of measure. If unit of measure must be changed, the sensor must be deleted and re-added to the system. ■ Note: Update the system’s Configuration Worksheets to document changes. Unlock the EA800 as shown in “Locking and Unlocking the EA800” on page 55 Select the sensor to edit.

  • Page 63: Reprogramming A Relay

    48 to reprogram any relay in the system. Deleting a Sensor Note: Update the system’s Configuration Worksheets to document any changes. To delete a sensor perform the following procedure: Unlock the EA800 as shown in “Locking and Unlocking the EA800” on page 55 D-011-0152 Maintenance...

  • Page 64: Changing The Date Format

    Update the system’s Configuration Worksheets to document any changes. Note: The default date format is MM/DD/YYYY. To change the date format perform the following procedure: Unlock the EA800 as shown Unlock the EA800 as shown in “Locking and Unlocking in “Locking and Unlocking the EA800”...

  • Page 65: Changing The Date Or Time Setting

    To change the date see “Setting the Current Date” on page 31. If your region uses Daylight Savings Time and you want the EA800 to display the correct time, you must change the time setting manually when Daylight Savings Time starts and ends. See “Setting the Time” on page 32.

  • Page 66: Changing The Buzzer Setting

    The default buzzer configuration is ENABLED and the active condition of the on-board buzzer mirrors what Note: is assigned to the Auxiliary Relay. To change the buzzer setting perform the following procedure: Unlock the EA800 as shown in “Locking and Unlocking the EA800” on page 55 D-011-0152...

  • Page 67: Changing The Password

    (0800) cannot be changed or deleted. One user-configurable password may be set in addition to the default 0800 password. To set or change the user-configurable password perform the following procedure: Unlock the EA800 as shown in “Locking and Unlocking the EA800” on page 55...

  • Page 68: Clearing The Alarm Log

    Clearing the Alarm Log To clear all stored alarm records perform the following procedure: Note: You cannot clear the Event Log. Unlock the EA800 as shown in “Locking and Unlocking the EA800” on page 55 Clearing the Sensor Log To clear all stored sensor records perform the following procedure: Note: You cannot clear the Event Log.

  • Page 69: Updating The Firmware

    The file name is limited to 15 characters or less (not includ- ing the file extension “.UPD”). File names greater than 15 characters are not supported and will not be displayed on the EA800. The EA800 reboots with the new firmware. Maintenance UPDATING...

  • Page 70: Saving Configuration Settings

    Saving Configuration Settings You can export the configuration settings from the EA800 to serve as an archive for the system or as a template for quickly programming other systems. The configuration data is stored in a machine-readable format. To export configuration to a USB drive perform the following procedure: Unlock as shown in “Locking...

  • Page 71: Loading Configuration Settings

    Loading Configuration Settings You can load configuration settings from a previously installed EA800 to serve as the template for the system being installed or updated. To load a configuration from a USB drive, insert the USB drive into the USB port and perform...

  • Page 72: Exporting The Stored Logs

    Remove USB drive when export is complete. The EA800 stores the log files on the USB drive in comma separated value (CSV) format. The files are named in the format XYYMMDD-HHMMSS.txt where: X = A, E, or D: ■...

  • Page 73: Exported Event Data

    Exported Event Data The following is an example of exported event data: 12/24/2007 07:06:03 PM,Sensor deleted,1 12/24/2007 07:10:50 PM,Sensor added,1 12/25/2007 02:27:14 PM,System power on,1 12/25/2007 02:27:50 PM,Sensor deleted,1 12/25/2007 02:36:02 PM,Sensor added,1 12/25/2007 03:08:55 PM,Sensor deleted,1 12/25/2007 03:11:19 PM,Sensor added,1 The data presented provides the following event information: Date and time of event 12/24/2007 07:06:03 PM...
  • Page 74 Exporting the Stored Logs D-011-0152...

  • Page 75: Troubleshooting

    Operating or setup errors are indicated by flashing data on the display. Often, a programming error also results in an alarm for the misprogrammed relay. The table below shows and describes common error displays, along with corrective action. For updated information, go to the EA800 page at www.winland.com and look for the troubleshooting section.

  • Page 76: Verifying Rf Signal Strength

    Verifying RF Signal Strength Verifying RF Signal Strength Viewing Signal Strength for a Wireless Sensor To verify the RF signal strength received by the EA800 perform the following procedure: Unlock the EA800 as shown in “Locking and Unlocking the EA800” on page 55 If the remote sensor transmitter you are verifying is battery powered, it may take up to 30 seconds for the base unit to receive a transmission from the remote sensor.

  • Page 77: Specifications

    Base Unit and Sensor Specifications The following table lists the specifications for the EA800 base unit, sensors, and accessories. Table 14 Specifications Item Dimensions Weight Mounting Case Material EA800 Input (Operating) Volt- age 1, 2, 3 EA800 Aux Power Out...

  • Page 78: Accessories

    2. All terminals must be connected to a Class 2 Power Limited Circuit complying with the National Electric Code NFPA 70, Article 725. 3. See “Specifications” on page 46 for power supply requirements. Accessories Accessories available for use with the EA800 Environmental Alarm System are listed below. Table 15 Accessories Item (Winland Part Number)

  • Page 79: Appendix A: Screen Maps

    Appendix A: Screen Maps Appendix A: Screen Maps The figures in this Appendix illustrate the flow of all EA800 screens. The displayed screen is dependent on whether an alarm is active or not. Figure 17. Locked Screen Map D-011-0152...
  • Page 80 The displayed screen is dependent on whether an alarm is active or not. See Figure 19 See Figure 22 See Figure 24 See Figure 23 Figure 18. Unlocked Screen Map - Top Level D-011-0152...
  • Page 81 Appendix A: Screen Maps See Figure 20 See Figure 21 Figure 19. Sensors Screen Map D-011-0152...
  • Page 82 Common Name screen is dependent on the sensor being added. Parameter screens depend on the sensor being installed. Figure 20. Add New Sensor Screen Map If multi-function only D-011-0152...
  • Page 83 Appendix A: Screen Maps Screen displayed is dependent on the sensor type. Figure 21. Edit Sensor Screen Map Figure 22. Relay Screen Map D-011-0152...
  • Page 84 Figure 23. Data Log Screen Map D-011-0152...
  • Page 85 Appendix A: Screen Maps Dependent on format See Figure 25 Figure 24. System Screen Map D-011-0152...
  • Page 86 Figure 25. Configuration Screen Map D-011-0152...

  • Page 87: Appendix B: Planning Worksheet

    Appendix B: Planning Worksheet Appendix B: Planning Worksheet Note: Photocopy and complete a copy of this worksheet for each system. Installation: Environmental Condition to Room Monitor Acceptable Condition/Range Alarm Condition D-011-0152...
  • Page 88 D-011-0152...

  • Page 89: Appendix C: Wiring Diagram

    Appendix C: Wiring Diagram Appendix C: Wiring Diagram Note: Photocopy and complete copy of this diagram for each EA800 to be installed in the system. D-011-0152...
  • Page 90 D-011-0152...

  • Page 91: Appendix D: System Configuration Record

    Appendix D: System Configuration Record Note: Photocopy this appendix and complete a copy for each EA800 base unit in the system. EA800 Environmental Alarm System Configuration Form Date of installation/change: Name of Installation Company: Phone number: Name of installer (print):...
  • Page 92 EA800 Environmental Alarm System Configuration Form Sensor Sensor Model Name Operational Parameters: Notes: Sensor Sensor Model Name Operational Parameters: Notes: Sensor 2 Settings Physical Location Unit of Measure: Resolution: Low Scaled Value: High Scaled Value: Hysteresis: Low Alarm Limit High Alarm Limit:...
  • Page 93 EA800 Environmental Alarm System Configuration Form Sensor Sensor Model Name Operational Parameters: Notes: Sensor Sensor Model Name Operational Parameters: Installed LQI (in bars): MAC Address: Notes: D-011-0152 Appendix D: System Configuration Record Sensor 4 Settings Physical Location Parameter Settings Unit of Measure:...
  • Page 94 EA800 Environmental Alarm System Configuration Form Sensor Sensor Model Name Operational Parameters: Installed LQI (in bars): MAC Address: Notes: Sensor Sensor Model Name Operational Parameters: Installed LQI (in bars): MAC Address: Notes: Sensor 6 Settings (wireless) Physical Location Unit of Measure:...
  • Page 95 EA800 Environmental Alarm System Configuration Form Sensor Sensor Model Name Operational Parameters: Installed LQI (in bars): MAC Address: Notes: D-011-0152 Appendix D: System Configuration Record Physical Location Parameter Settings Unit of Measure: Resolution: Low Scaled Value: High Scaled Value: Hysteresis:...
  • Page 96 D-011-0152...

  • Page 97: Warranty And Service Information

    Warranty and Service Information Winland Electronics, Inc. ("Winland") warrants to the end user/purchaser that each product of its manufacture shall be free from defects in material and factory workmanship for a period of two (2) years from the date of purchase, when properly installed and operated under normal conditions according to Winland's instruction.
  • Page 98 Manufactured in the U.S.A by Winland Electronics 1950 Excel Drive, Mankato, MN, 56001 Outside MN Phone: 1-800-635-4269 Phone: 507-625-7231 Fax: 507-387-2488 ©Winland Electronics, Inc. 2008 www.winland.com D-011-0152 Rev. A...
