Summary of Contents for MicroNet SP906GK
- Page 1 User’s Manual Wireless LAN PCI Adapter Model No.: SP906GK http://www.micronet.info...
-
Page 2: Table Of Contents
CONTENTS 1 INTRODUCTION ..............1 1.1 Features....................1 1.2 Specifications................... 1 1.3 Package Contents..................2 2 HARDWARE INSTALLATION ..........3 3 CONFIGURATION UTILITY ............. 6 3.1 Site Survey ....................9 3.2 Profile....................... 9 3.2.1 Configure the Profile ..............11 3.2.1.1 Base Configuration ............... 11 3.2.1.2 Wireless network security ............. -
Page 3: Introduction
1 Introduction Thank you for purchasing the SP906GK. It complies with IEEE 802.11g standard and supports up to 54Mbps high-speed wireless network connections. It can also work with IEEE 802.11b devices. When SP906GK is connected to 11b devices, the link speed will be up to 11Mbps. -
Page 4: Features
1.1 Features • Comply with the IEEE 802.11b and IEEE 802.11g standards. • High-speed wireless transfer data rate - up to 54Mbps. • Provide high level of security with 64/128-bit WEP, WPA (TKIP with IEEE 802.1x), WPA2 (AES with IEEE 802.1x) functions •... -
Page 5: Package Contents
1.3 Package Contents Before you begin the installation, please check the items in your package. The package should include the following items: • Micronet SP906GK Wireless LAN PCI Adapter • Driver and Manual CD • Quick Installation Guide • Detachable Antenna If any of the above items is missing, contact your supplier as soon as possible. -
Page 6: Hardware Installation
2 Hardware Installation Before you proceed with the installation, please read the following notes carefully: Note1: Please do not install SP906GK into your laptop computer before installing the software program from the CD. Note2: The following installation was performed under Windows XP. (Procedures are similar for Windows 98SE/Me/2000.) Note3: If you have installed the SP906GK Wireless PCI Adapter driver &... - Page 7 D. After selecting the country domain, click “Next” to process the installation.. E. Warning: Selecting incorrect region may result in a violation of applicable law dialog window will pop-up. If you have selected the correct region, click “Yes” continue the process. F.
- Page 8 G. The system will automatically detect SP906GK and display the “Hardware Installation” screen. Click “Continue Anyway” to continue. H. Click “Finish” to complete the installation. - 5 -...
-
Page 9: Configuration Utility
3 Configuration Utility The Configuration Utility is a powerful application that helps you configure SP906GK and monitor the link status and the statistics during the communication process. If SP906GK is installed successfully, the configuration utility will automatically pop up. It will automatically connect to the wireless device, which has better signal strength and no wireless security setting. - Page 10 Right click the icon to find the items in configuration utility for you to perform. Launch Config Utilities Select “Open Config Utility” to open the Configuration Utility tool. Use Zero Configuration as Configuration Utility Select “About” to describe the Wireless Card information. Hide Select “Hide”...
- Page 11 B. Click “Advanced”. C. Uncheck “Use Windows to configure my wireless network settings” to enable the utility for the card. Note: If “Wireless Zero Configuration” is enabled, you can only configure the advance setting or check the link status and statistics from the configuration utility of the card. - 8 -...
-
Page 12: Site Survey
Site Survey When you open the Configuration Utility, the system will scan all the channels to find all the access points/stations within the accessible range of SP906GK and automatically connect you to the wireless device with the greatest signal strength. The “Available Network”... - Page 13 Add/Delete/Edit/Activate a profile. Parameter Description Profile List The profile list displays all the profiles and their relative settings including Profile Name, SSID. This sign indicates the activated profile is connecting. This sign indicates the activated profile is disconnected. Add/Remove/Edit/Duplicate/ Click these buttons to Add / Remove / Edit / Set Default Button Duplicate / Set Default the selected profiles.
-
Page 14: Configure The Profile
3.2.1 Configure the Profile 3.2.1.1 Base Configuration Parameter Description Profile Name Define a recognizable profile name for you to identify the different networks. SSID The SSID (up to 32 printable ASCII characters) is the unique name identified in a WLAN. The ID prevents the unintentional merging of two co-located WLANs. -
Page 15: Wireless Network Security
3.2.1.2 Wireless network security Parameter Description Network Authentication Type This setting has to be consistent with the wireless networks that SP906GK intends to connect. Open System – No authentication is needed in the wireless network. Shared Key – Only wireless devices using a shared key (WEP Key identified) are allowed to connect to each other. - Page 16 password in their access point or gateway, as well as in each wireless station in the network. WPA-PSK takes over automatically from that point, keeping unauthorized users that don't have the matching password from joining the network, while encrypting the data traveling between authorized devices. WPA2 –...
- Page 17 802.1x Setting When you set the Authentication Type to Open, Shared, WPA or WPA2, you can also enable IEEE 802.1x setting to use the authentication server or certification server to authenticate client users. WPA Pre-Shared Key The WPA-PSK key can be from 8 to 64 characters and can be letters or numbers.
- Page 18 The IEEE 802.1X specification describes a protocol used for authenticating both clients and servers on a network. The authentication algorithms and methods are those provided by the Extensible Authentication Protocol (EAP), a method of authentication that has been in use for a number of years on networks that provide Point-to-Point Protocol (PPP) support as many internet service providers and enterprises do.
-
Page 19: 802.1X Setting-Certification
3.2.1.3 802.1x Setting-Certification Parameter Description Authentication Type The EAP authentication protocols this card supports are listed below. This setting has to be consistent with the wireless APs or Routers that SP906GK intends to connect. PEAP &TTLS – PEAP and TTLS are similar and easier than TLS in that they specify a stand-alone authentication protocol to be used within an encrypted tunnel. -
Page 20: 802.1X Setting-Ca Server
Session Resumption Select from “Disabled”, “Reauthentication”, “Roaming”, “SameSSID” and “Always” options when you want to recover the session in different status. Identity Name the server for server identification. Password Enter the password for server identification. Use Client Certificate A client certificate is required for TLS, and is optional for TTLS and PEAP. - Page 21 Allow Intermediate When the server designates an issuer as a trusted root Certificates authority, it places the issuer's self-signed certificate, which contains the issuer's public key, into the trusted root certification authority certificate store of the host computer. Intermediate or subordinate certification authorities are trusted only if they have a valid certification path from a trusted root certification authority.
-
Page 22: Advanced
Advanced Parameter Description PSM (Power Save Mode) The power saving function is only available when the network type is in Infrastructure. None – Disable the Power Save mode. Min – SP906GK will always set in Minimum mode. Max – SP906GK will always set in Maximum mode Wireless Mode SP906GK can be compatible with both 802.11g and 802.11b wireless stations... - Page 23 Preamble The preamble defines the length of the CRC block for communication among wireless devices. This option is only active in the Ad Hoc network. There are three modes including Auto, Short and Long Preamble. If “Auto“mode is selected, SP906GK will automatically switch the preamble mode depending on the wireless devices SP906GK is connected to.
-
Page 24: Status
Status From the “Status” option, you can view all the information of the network you are connected Parameter Description Manufacturer Display the Chip-set manufacturer. NDIS Driver Version Display Current Driver version. Short Radio Header Display the Short Radio Header. Encryption Display the encryption method used on SP906GK Authenticate Display the Authentication method configured on... -
Page 25: Statistics
Statistics This option enables you to view the statistic information of the connection, including transmit statistics and receive statistics. You may click the “Reset” to reset the SP906GK counters. Easy Config This option offers you two methods to configure SP906GK easily; select Touch-Button Method or Question-Answer Method. - Page 26 compressing the data and decreasing the waiting time for sending the next data to the Routers or APs. This feature (known as Turbo Mode) enables higher throughput than IEEE 802.11g standard (Up to 54Mbps). When SP906GK is connecting to the Routers or APs with the proprietary Turbo Mode feature, the Turbo Mode will be enabled automatically without any configuration.
-
Page 27: Troubleshooting
4 Troubleshooting This chapter provides solutions to problems commonly encountered during the installation and operation of the adapter. 1. What is the IEEE 802.11g standard? 802.11g is the new IEEE standard for high-speed wireless LAN communications which provides up to 54 Mbps data rate in the 2.4 GHz band. 802.11g is quickly becoming the next mainstream in wireless LAN technology for the home, office and public networks. - Page 28 database, or wireless application for mobile workers. 6. What is BSS ID？ A specific Ad hoc LAN is called a Basic Service Set (BSS). Computers in a BSS must be configured with the same BSS ID. 7. What is WEP？ WEP is Wired Equivalent Privacy, a data privacy mechanism based on a 40 bit shared key algorithm, as described in the IEEE 802 .11 standard.
- Page 29 13. What is Spread Spectrum？ Spread Spectrum technology is a wideband radio frequency technique developed by the military for use in reliable, secured, mission-critical communication systems. It is designed to trade off bandwidth efficiency for reliability, integrity, and security. In other words, more bandwidth is consumed than in the case of narrowband transmission, but the trade off produces a signal that is, in effect, louder and thus easier to detect, provided that the receiver knows the parameters of the spread-spectrum signal being broadcast.
- Page 30 Copyright 2006 Micronet Communications, Inc. All rights reserved. No Part of the contents of this guide maybe transmitted or reproduced in any form or by any means without the written permission of manufacturer. Printed in Taiwan. FCC Statement This product has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of FCC Rules.
- Page 31 transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. R&TTE Compliance Statement This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE) R&TTE...
