Summary of Contents for Eurotech An0038
- Page 1 EmbeddedDNA ® PC/104 CPU Module An0038 CPU-1220; Ethernet Aapter Rev. 1.0 Apr 2004 COPYRIGHT 1994-2005 Eurotech S.p.A. All Rights Reserved.
- Page 2 Application Note ABOUT THIS MANUAL This application note is intended to help users detecting which Ethernet interface is installed over the CPU-1220. Via J. Linussio 1 33020 AMARO (UD) ITALY Phone: +39 0433 485 411 Fax: +39 0433 485 499 web: http://www.eurotech.it e-mail:...
-
Page 3: Conventions
Application Note Conventions The following table lists conventions used throughout this guide. Icon Notice Type Description Important features or Information note instructions Information to alert you to potential damage to a program, Warning system or device or potential personal injury... - Page 4 (This page is intentionally left blank.)
-
Page 5: Table Of Contents
Contents Conventions ..............................3 Contents ................................5 Chapter 1 CPU-1220 Ethernet interface ....................7 Detecting the Realtek chipset version installed into your CPU-1220 ............7 Ethernet interface............................8 J4: CPU-1220 Ethernet connector ......................8 J9: Status LEDs............................9 Ethernet physical adapter ..........................9 Related Documents ............................ - Page 6 (This page is intentionally left blank.)
-
Page 7: Chapter 1 Cpu-1220 Ethernet Interface
Chapter 1 CPU-1220 Ethernet interface The CPU-1220 Ethernet interface features a single-chip Fast Ethernet controller Realtek RTL8139 that provides 32-bit performance, 10/100Mbps auto-sensing, and full compliance with IEEE 802.3u 100Base-T specifications and IEEE 802.3x Full Duplex Flow Control. The versions of the Relatek RTL8139 chipset installable over the CPU-1220 board are: RTL8139 B RTL8139 C Between the two devices there are only different electrical characteristics. -
Page 8: Ethernet Interface
Application Note Comparing the CPU-1220 serial number with the following table is possible to detect the installed chipset version: Table 1. CPU-1220 RTL8139 chipset version CPU-1220 Eurotech s/n Realtek RTL8139 version Till S.N. 229904389 Starting from 03M241 S.N. 229904390 Ethernet interface The CPU-1220 module provides the following interfaces: J4 for a 10/100 Ethernet (LAN) connection. -
Page 9: J9: Status Leds
Application Note Ground signal LED2 On receiving packets Ground signal 100/10Base-T transmit data 100/10Base-T transmit data J9: Status LEDs The HDD and Ethernet activity LEDs are implemented on the J9 connector. It is a 3x2 pin - 2mm step. The following table shows the J9 connector pinout: Table 3. - Page 10 Application Note Important Note. Connection to a 100BASE-TX hub for 100 Mbps operation requires Cat. 5 Unshielded Twisted-Pair (UTP) cable or Cat. 5 Shielded Twisted-Pair (STP) cable. The maximum length between the 100BASE-TX hub and the adapter is 100 meters. Connection to a 10BASE-T hub for 10 Mbps operation requires a Cat.
- Page 11 Application Note Generic Ethernet adapter Eurotech has developed a fail-safe circuitry that can be installed to prevent faulty and damages. To prevent wrong connections between the CPU-1220 and the Ethernet adapter Eurotech has developed a generic adapter that can be used together with the CPU-1220 for installing both the Realtek chips. The following drawing describes the solution for a generic Ethernet adapter tolerant regarding the supply voltage present on pin 1 of J4 CPU-1220 Ethernet connector and based on the version of the Realtek RTL8139 chipset installed, and that may be integrated into a carrier board.
- Page 12 Application Note Chapter 2 Drivers Visit the Eurotech web site for the latest driver availability.
-
Page 13: Related Documents
Application Note Related Documents For detailed information on the CPU-1220 board please refer to the User Manual. For further information about the Realtek RTL8139X please refer to the technical Data Sheet.
