B-52 MATRIX-600 Connections & Overview Manual

MIXER:
Sensitivity / Impedance (for 1Vrms on PREAMP outputs,
channels' VOLUME controls and MASTER VOLUME in FCW position)
Ch. 1-4: XLR and 1/4" TRS combo MIC inputs (balanced): 5 mV / 2 k OhmsΩ
Ch. 1-4: 1/4" TRS LINE inputs (balanced):
Ch. 5: XLR MIC input (balanced):
Ch. 5: 1/4" TRS INSTRUMENT input (mono, unbalanced): 75 mV / 1 M OhmsΩ
Ch. 5: 1/4" TRS STEREO LINE input (unbalanced):
Ch. 6: Stereo RCA and 3.5mm mini jack MP3/CD input
(unbalanced):
Ch. 7: Stereo RCA HOUSE input
(bypasses MASTER VOLUME):
Phantom power on Ch. 1-4:
Channels' 3-band EQs
Ch. 1-4:
Ch. 5-6:
MASTER 7-band EQ:
SUBWOOFER filter:
SUBWOOFER output:
MONITOR output:
RECORD output:
AMPlIFIER:
