Page 1 LBI-39224 Operations Guide ® EDACS CEC/IMC MANAGER ® Version 5.0 for Windows NT...
Page 3: Software License Agreement
FURNISHED UNDER A LICENSE AND MAY BE USED ONLY IN ACCORDANCE WITH THE FOLLOWING LICENSE TERMS. Ericsson Inc., hereafter referred to as COMPANY, grants to you, hereafter referred to as USER, a non-exclusive, paid up license to use the accompanying Software, the media on...
Page 4 Pentium is a registered trademark of Intel Corporation NETCLOCK/2 is a trademark of Spectracom Corporation. NOTICE This manual covers Ericsson and General Electric products manufactured and sold by Ericsson Inc. NOTICE Repairs to this equipment should be made only by an authorized service technician or facility designated by the supplier.
Page 5 LBI-39224 This manual is published by Ericsson Inc. without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Ericsson Inc. at any time and without notice. Such changes will be incorporated into new editions of this manual.
Page 6 LBI-39224 This page intentionally blank...
Page 7: Table Of Contents
LBI-39224 Contents INTRODUCTION................ xiii 1. CHAPTER 1 GETTING STARTED ........1.1 ABOUT CEC/IMC MANAGER V5.0......1.2 ABOUT THIS MANUAL..........1.2.1 System Configuration ..........1.2.2 System Monitoring ..........1.2.3 Help ................ 1.3 DATA LOGGING FEATURE........2. CHAPTER 2 INSTALLATION..........2.1 UNPACKING..............2.2 CEC/IMC MANAGER REQUIREMENTS ....
Page 8 LBI-39224 3.11 CONSOLE CONFIGURATION ......... 3-104 3.11.1 CIM Channel Configuration ......... 3-105 3.11.2 Console User Profile Configuration...... 3-112 3.11.3 C3 Maestro Console Hardware Configuration..3-121 3.11.4 Console Privilege Lists ......... 3-123 3.11.5 C3 Modular/Desktop Console Configuration ..3-127 3.11.6 View Patch/Simulselect ........3-130 3.12 DIGITAL VOICE CHANNEL CONFIGURATION..............
Page 9 LBI-39224 4.2 NODE DATA ..............4.2.1 Node Matrix............4.2.2 Board Identification..........4.3 FEATURE DATA ............4.3.1 Licensed Features ........... 4.3.2 Licensed Capacities ..........4.4 DIAGNOSTICS ............. 4.4.2 Diagnostic Options ..........4-10 4.5 STATISTICS..............4-18 4.5.1 HDLC Statistics ............4-18 4.5.2 GSC Node Statistics ..........4-21 4.5.3 NIM Statistics ............
Page 10 LBI-39224 List of Figures Figure 1 CEC/IMC Manager Main Window and Menu Bar ..Figure 2 CEC/IMC Manager Login ..........Figure 3 CEC/IMC Manager Configuration Menu ..... Figure 4 CEC/IMC Manager Configuration User Menu..... Figure 5 Add/Modify/Delete Users Dialog Box ......Figure 6 Font Selection Dialog Box..........
Page 11 LBI-39224 Figure 28 C3 Maestro Hardware Configuration Dialog Box ..3-121 Figure 29 Console Privilege List Dialog Box ....... 3-125 Figure 30 C3 Modular/Desktop Console Configuration Dialog Box..............3-127 Figure 31 Patch and Simulselect View Dialog Box ...... 3-131 Figure 32 DVIM Channel Configuration List Dialog Box.... 3-135 Figure 33 DVIM Channel Configuration Dialog Box....
Page 12 LBI-39224 Figure 58 NETCLOCK/2 Configuration........Figure 59 NETCLOCK/2 T-CMD Interconnections..... Figure 60 NETCLOCK/2 Remote Output Connections....List of Tables Table 1 Configured/Active Sites Prefix Definitions....3-25 Table 2 Subrate Port Assignments for Analog/Modem Mode ..3-43 Table 3 Synchronous Subrate Port Packing Arrangement ..3-44 Table 4 Console Individual Call Levels........
Page 13: Introduction
Welcome Ericsson welcomes you to the world of mobile communications. We believe there is no equal to Ericsson products and have made a commitment to our customers to ensure that product satisfaction and reliable service is our number one priority.
Page 14 LBI-39224 Conventions ® Those users already familiar with Windows will feel quite at home with the graphical aspects of CEC/IMC Manager for Windows NT. For those users who are not very familiar with Windows, or are a bit rusty, a brief review follows.
Page 15 LBI-39224 – appears, scroll bars are provided if there are more choices than can fit in the box. – Check boxes present non-exclusive options, you can select as many options as needed, when a check box is selected it contains an X, names of unavailable options appear dimmed. Option 1 (unselected) Option 1...
Page 16 LBI-39224 This page intentionally blank...
Page 17: Appendix C - Snmp Agent And Proxy For Cec/Imc (Optional)
LBI-39224 1. CHAPTER 1 GETTING STARTED 1.1 ABOUT CEC/IMC MANAGER V5.0 Starting with release (version) 5.0 the CEC/IMC Manager is a 32 bit Windows NT application. To provide remote management capability the architecture of the CEC/IMC Manager is Client/Server. application is divided into two executables; GUI_SRVR.exe is the Server application that runs as a Windows NT service, and W_GUI.exe is the Graphical User Interface (GUI) application run from the ICON selected in the WINMOM program group.
Page 18: System Configuration
LBI-39224 and viewing interface module status data. The various screens and terms the user may encounter are walked through and explained in full detail. The following sub-sections highlight the major functions of the CEC/IMC Manager. 1.2.1 System Configuration CEC/IMC Manager Configuration –...
Page 19 LBI-39224 and EDACS Data Gateway (EDG) interface. In release 5.0 CEC/IMC Manager TDM bus time slots are allocated from each site, console, or DVIM interface audio configuration dialog box. System Options – Auxiliary I/O – Program auxiliary I/O events. – Multisite Unit Logout –...
Page 20: System Monitoring
LBI-39224 Console Configuration – Console Hardware Configuration – Perform special console hardware configurations for C3 Maestro™ consoles. – Console User Profiles – Configure console user-specific parameters. Up to ten (10) different console user profile set-ups (shifts) are available for each console. –...
Page 21: Data Logging Feature
LBI-39224 1.3 DATA LOGGING FEATURE One of the most important features of the CEC/IMC Manager (MOM PC) is its ability to log data. All data that is placed on the GSC Bus in the CEC/IMC is logged at the MOM Controller Board. The MOM Controller Board then periodically dumps its data log buffer to the CEC/IMC Manager through their serial link.
Page 22 LBI-39224 This page intentionally blank...
Page 23: Chapter 2 Installation
LBI-39224 2. CHAPTER 2 INSTALLATION 2.1 UNPACKING After opening this package, verify you have received the following: – CEC/IMC Manager Version 5.0 for Windows NT software— located on 3-1/2 inch diskettes; this software will be already installed on the computer's hard drive for a new system –...
Page 24: Diskette Handling
LBI-39224 2.3 DISKETTE HANDLING While working with your diskettes you should consider the following handling procedures: – Always store diskettes in their envelope – Insert diskettes into the drive carefully – Use only felt tipped pens to write on a diskette label –...
Page 25: Multiple Remote Clients
LBI-39224 NOTE It is important to use the DISKCOPY command when making a backup and not the COPY or XCOPY commands. The diskette contains a volume label that is required for the installation process and COPY and XCOPY do not copy volume labels.
Page 26 LBI-39224 VERIFY that the MIGRATE.BAT utility has been executed to save the original (DOS) CEC/IMC Manager configuration. Insert the "Install" CEC/IMC Manager V5.0 for Windows NT diskette and execute SETUP.EXE. This setup utility will: – Copy all necessary Executables and DLLs –...
Page 27 LBI-39224 The TDM Bus/Slots must be read from the CEC/IMC in the Console Audio Configuration screens. a) Select Menu Option Configure System / CEC/IMC Configuration / CIM. b) Select ALL consoles that are displayed in the Configured/Active Consoles list box. c) Choose the Modify button.
Page 28 LBI-39224 c) Choose the Modify button. d) For each PIM choose the CEC/IMC to Disk button. e) Verify the Slots match in the Upper and Lower list boxes for ALL channels. 11. The TDM Bus/Slots must be read from the CEC/IMC in the NIM Audio Configuration screens.
Page 29: System Hook-Up
LBI-39224 14. Any T1/E1 node databases must be defined or converted from analog to T1 or E1. See the T1/E1 Installation Instructions for more details on setting the T1/E1 databases. 2.7 SYSTEM HOOK-UP Connect all peripheral equipment to your computer prior to configuring the software items described in Chapter 3 of this manual.
Page 30 LBI-39224 This page intentionally blank...
Page 31: Chapter 3 Operation And Configuration
LBI-39224 3. CHAPTER 3 OPERATION AND CONFIGURATION The primary intent of this chapter is to describe CEC/IMC Manager program operation, and valid CEC/IMC Manager and CEC/IMC Digital Audio Switch configuration settings. In some cases detailed system- level information is presented where necessary. This chapter is arranged in the order recommended for the set-up of a new CEC/IMC Digital Audio Switch.
Page 32: Figure 1 Cec/Imc Manager Main Window And Menu Bar
LBI-39224 Figure 1 CEC/IMC Manager Main Window and Menu Bar Selecting any of the choices from the CEC/IMC Manager menu bar (Configure System, Monitor System, Help) will display the Login dialog box. You will be prompted to enter a user name and password before execution of the program will continue.
Page 33: User Account Configuration
LBI-39224 Choose the OK button to save any new settings, activate those settings, and exit the current dialog box. Exit Program Choose the Exit Program button to exit the CEC/IMC Manager program and return to the Windows NT Program Manager. 3.2 USER ACCOUNT CONFIGURATION Up to twelve (12) different user accounts can be configured for the CEC/IMC Manager.
Page 34: Figure 3 Cec/Imc Manager Configuration Menu
LBI-39224 NOTE Certain menu selections may be "grayed-out," indicating that those menu selections (functions) are not available to that access level. See User Access Level (later in this section) for those functions available to the various access levels. From the CEC/IMC Manager menu bar select Configure System / CEC/IMC Manager Configuration display CEC/IMC Manager Configuration menu, shown in Figure 3.
Page 35: Set Up Accounts
LBI-39224 Figure 4 CEC/IMC Manager Configuration User Menu 3.2.1 Set Up Accounts This option is used to add a new user account. Adding a new user account involves adding the new user name, selecting a password, and establishing access level. This done Add/Modify/Delete Users dialog box, Figure 5, by selecting...
Page 36: Figure 5 Add/Modify/Delete Users Dialog Box
LBI-39224 Figure 5 Add/Modify/Delete Users Dialog Box Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Add User Enter the new user in the New Username text box. When a new user name is entered (typed) in this text box the Add button appears, taking the place of the Save and Delete buttons.
Page 37: Modify Accounts
LBI-39224 User Password Select (no password required) or unselect (password required) the No Password check box as required for the new user. If selected, no further action is required. If unselected, enter the password in the New Password text box, then re-enter the password in the Verify New Password text box.
Page 38: Cec/Imc Manager Font Selection
LBI-39224 Cancel Choose the Cancel button to immediately exit the current dialog box without saving or activating any new settings. Login As New User Selected users may be able to login to the CEC/IMC Manager program as a new (different) user, this "new" user must be a currently existing user in the system.
Page 39: Figure 6 Font Selection Dialog Box
LBI-39224 another platform when the user logs in; in such instances a user may need to have accounts at each platform under different user names with a font selection for that particular platform. Because there is variation between platforms font selection may be somewhat of a "trial-and- error"...
Page 40: Initial Cec/Imc Manager And Mom Controller Board Configuration
LBI-39224 3.4 INITIAL CEC/IMC MANAGER AND MOM CONTROLLER BOARD CONFIGURATION The CEC/IMC Manager Configuration dialog box, shown in Figure 7, is the configuration point for several CEC/IMC Manager and CEC/IMC MOM Controller Board-related parameters. From the CEC/IMC Manager menu select Configure System CEC/IMC Manager Configuration / Hardware (see Figure 3) to display the CEC/IMC Manager Configuration dialog box.
Page 41 LBI-39224 COM 1, COM 2, COM 3 or COM 4, as required using the respective option button in the dialog box. The selected serial port interrupt request line (IRQ) and base I/O port address settings are established from the Microsoft Windows NT Control Panel program settings.
Page 42: System Time And Date
LBI-39224 GSCMOM.EXE off-line programs as described in Chapter 5, OFF- LINE DIAGNOSTIC FUNCTIONS. If data logging is desired, select the Enable Datalog check box. With this feature enabled the CEC/IMC Manager will log GSC traffic such as channel assignments and drops. The datalog delete threshold feature automatically deletes old datalog files which are stored on the CEC/IMC Manager's hard disk drive.
Page 43: Figure 8 System Options Menu
LBI-39224 Figure 8 System Options Menu Figure 9 Configure System Clock Synchronization Dialog Box Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Current Time and Date The system's current time and date is displayed in this field, the time is in a 24-hour format (11:00:00 PM would be 23:00:00).
Page 44: System Manager Database Uploads
LBI-39224 Output CEC/IMC Manager Time to CEC/IMC Select (enable) this check box to cause the CEC/IMC Manager time to update the CEC/IMC time. The default is "selected"—"Output CEC/IMC Manager Time to CEC/IMC." Unselect (disable) to force the CEC/IMC to run on its own internal clock. This box should be selected (enabled) if using the NETCLOCK/2 option.
Page 45 LBI-39224 Manager user is able to select unit, group, and site data from the System Manager; or unit, group, and site data, along with conventional and console unit ID databases from the CEC/IMC Manager hard disk, and broadcast (transfer) this data to all interface modules. If the data is transferred from the System Manager it is also stored on the CEC/IMC Manager hard disk.
Page 46: Figure 10 System Mgr/Network Mgr Entity Database Dialog Box
LBI-39224 Figure 10 System Mgr/Network Mgr Entity Database Dialog Box Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Close Close System Mgr/ Choose button exit Network Mgr Entity Database dialog box and return to the CEC/IMC Manager main window.
Page 47: Transfer From System Manager
LBI-39224 down list box: whether it was full or partial, status, and number of records in the database file that were updated. Entity The Entity box allows the user to select the entity database to be updated. Transfers from the System Manager may be Unit, Group, or Site.
Page 48: Transfer From Cec/Imc Manager
LBI-39224 3.6.2 Transfer From CEC/IMC Manager If a "Transfer From CEC/IMC Manager" is desired, all upload data will originate from the CEC/IMC Manager's hard disk. This is data stored from a previous System Manager upload. In addition, conventional and console unit ID databases can be uploaded from the CEC/IMC Manager.
Page 49 LBI-39224 Close Close Choose button exit System Mgr/Network Mgr Entity Database dialog box, if no other database transfers are desired, and return to the CEC/IMC Manager main window. 3.7 TDM BUS CONFIGURATION The CEC/IMC Digital Audio Switch is equipped with a Time Division Multiplexed (TDM) network which transfers audio signals, modem data signals, and user data signals throughout the switch.
Page 50: Figure 11 Tdm Bus Configuration Dialog Box
LBI-39224 TDM bus allocations are performed from the TDM Bus Configuration dialog box, shown in Figure 11. From the CEC/IMC Manager menu bar select Configure System / CEC/IMC Configuration / TDM Bus to display the TDM Bus Configuration dialog box. Figure 11 TDM Bus Configuration Dialog Box Current TDM Bus Configuration When the TDM Bus Configuration dialog box is first opened this field...
Page 51: Site-Type Interface Module Channel
LBI-39224 will greatly increase the number of slots available, and decreasing the number of buses will greatly decrease the number of slots available. Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Cancel Choose the Cancel button to exit the TDM Bus Configuration dialog box without saving or activating any new settings.
Page 52 LBI-39224 NOTE In most cases, the term "site" in this program does not refer to an EDACS trunked site or any other type of radio system. It refers instead to a site-type interface module within the CEC/IMC or StarGate Controller Digital Audio Switch. The number that follows is the interface module's site assignment number.
Page 53: Mim Channel Configuration
LBI-39224 Figure 12 CEC/IMC Configuration Menu 3.8.1 MIM Channel Configuration Interfacing between the CEC/IMC and an EDACS trunked site is accomplished with a MASTR™ II/III Interface Module (MIM). The MIM consists of a Controller Board and up to eight Audio or T1/E1 Interface Boards.
Page 54: Figure 13 Site Channel Configuration List Dialog Box
LBI-39224 Figure 13 Site Channel Configuration List Dialog Box (MIM Shown) Each Site Channel Configuration List dialog box displays the configurable "sites" and configured/active "sites." An active "site" represents an active Controller Board control data link. For example, in the case of a MIM this represents an operating link between an EDACS trunked site and the MIM Controller Board.
Page 55: Table 1 Configured/Active Sites Prefix Definitions
LBI-39224 All selected MIMs in this list will also be included in the "Save As…" dialog box that is accessed from the Site Channel Configuration dialog box or T1/E1 Digital Site Configuration dialog box. particular state is indicated by a prefix as defined in the following table. Table 1 Configured/Active Sites Prefix Definitions PREFIX MEANING...
Page 56 LBI-39224 Interface Board will activate the T1/E1 Digital Site Configuration dialog box. These options are discussed in detail in subsequent sections. Delete Choose the Delete button to remove ("delete") a selected configured or unconfigured site from the Configured/Active Sites list box to the Configurable Sites list box.
Page 57: Figure 14 Audio Interface Type Dialog Box (Audio Board Selected)
LBI-39224 Figure 14 Audio Interface Type Dialog Box (Audio Board selected) T1/E1 Interface option If T1/E1 Interface Card was selected (Figure 15), a new set of option buttons will appear. T1 is a digital transmission facility operating at 1.544 Mbps (million bits per second) in a full-duplex, time-division-multiplexing mode.
Page 58 LBI-39224 T1/E1 Digital Site Configuration dialog box will appear. Continue with channel configuration as described in "T1/E1 Interface Card Equipped Configuration." Figure 15 Audio Interface Type Dialog Box (T1/E1 Interface Card selected) Audio Board-Equipped MIM Channel Configuration This section describes configurations for channels within Audio Board- equipped site-type interface modules.
Page 59: Figure 16 Site Audio Channel Configuration Dialog Box (Mim Shown)
LBI-39224 Figure 16 Site Audio Channel Configuration Dialog Box (MIM Shown) Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) View Current CEC/IMC Manager Channel Configuration The upper list box in the Site Channel Configuration dialog box, labeled "CEC/IMC Manager,"...
Page 60 LBI-39224 by comparing the CEC/IMC Manager and CEC/IMC list boxes in the Site Channel Configuration dialog box. Ensure that the CEC/IMC configuration is correct, then choose the CEC/IMC to Disk button to restore the CEC/IMC Manager configuration database (for the selected interface module).
Page 61 LBI-39224 Channel Signaling This drop-down list box specifies the type of channel signaling sent out by the selected channel for control of external equipment such as an EDACS trunked site or co-located mux equipment. Valid settings are "NONE" for no signaling, "TONE" for tone control signaling, "E&M" for M-lead control signaling, and "BOTH"...
Page 62 LBI-39224 For example, if the currently selected site-type interface module is a 20-channel MIM with five (5) Audio Boards addressed 1 thru 5, Bus/Slots Equipped for channels 1 thru 20 must be "YES." NOTE earlier CEC/IMC firmware/software releases, slot allocations could only be made contiguously starting with channel one (1).
Page 63 LBI-39224 the selected channel by entering "YES" in the ALC text box or disable it by entering "NO." Save and Send MIM Audio Board Configurations When channel configuration of the selected interface module is complete, the Site Channel Configuration dialog box changes must be sent to the CEC/IMC before the changes will take effect.
Page 64: Figure 17 "Save As..." Dialog Box
LBI-39224 Figure 17 "Save As…" Dialog Box For example, if "Site 8" is the currently selected site-type interface module and "Site 12" requires similar configuration settings, this button may be used to save the "Site 8" configuration as "Site 12" (save to "12").
Page 65 LBI-39224 MOM Controller Board receives this new data it will send an acknowledgment message back to the CEC/IMC Manager, which will then display the confirmation box: "Do you want to activate TDM Bus Slots? OK - will cause all CTRL boards to reset." Choose OK to activate TDM Bus Slots (resetting Controller Boards) with the new Bus Slot configuration data, choose Cancel to not activate TDM Bus Slots with the new Bus Slot configuration data (keeping the previous...
Page 66 LBI-39224 NOTE T1/E1 selection is performed at the CEC/IMC Manager on a CEC/IMC wide basis. Changing the Line Type will cause the complete T1/E1 database to be reset (lost). The Line Type shown as the "default" when the Audio Interface Type dialog box appears is how the system is configured and Line Type should not be changed.
Page 67 LBI-39224 Master - Redundant Clock Circuits generated by the Clock Board in a FREE RUN mode. This allows any CEC/IMC to become the master source of Network timing. All nodes connected to this CEC/IMC will be in the slave mode. This mode is established by setting the Clock Board DIP switches to "Master"...
Page 68 LBI-39224 1. One node in the system must be the MASTER source of network timing. The CEC/IMC will support a primary and redundant (or alternate) MASTER sources of timing as indicated above. 2. A MASTER node can be defined as a site, a Jessica, a T1/E1 link, or a CEC/IMC.
Page 69 LBI-39224 Figure 18 T1/E1 Digital Site Configuration Dialog Box (T1 Line Type Selected) Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Analog or Digital Voice In addition to T1 or E1 selection, T1/E1 Interface Card configuration includes selecting one of three primary board operating modes: –...
Page 70 LBI-39224 one full duplex 4-wire 600-ohm audio channel provided by the Audio Board. The T1/E1 Interface Card extracts a signal from one bus slot and sends it out on a T1/E1 channel. Accordingly, signals received on this same T1/E1 channel are applied to a different CEC/IMC TDM bus slot.
Page 71 LBI-39224 E1), Robbed Bit for T1, and CAS-CC for E1. Select the signaling type from the drop-down list box. Line Length This is the distance between the CEC/IMC and the device at the other end of the T1 line, which could be a microwave transceiver, a mux in co-located site equipment, CSU, etc.
Page 72 LBI-39224 should be the same as the configuration stored on the CEC/IMC Manager hard disk. If the CEC/IMC Manager hard disk data was cleared or reset to undesired values, Read MSC followed by Save will restore the CEC/IMC Manager hard disk configuration. Set Defaults Choose the Set Defaults button to select the pre-programmed default values from the CEC/IMC Manager hard disk.
Page 73: Table 2 Subrate Port Assignments For Analog/Modem Mode
LBI-39224 T1/E1 Channel Assignment T1/E1 logical channels are assigned starting with channel 1, these are the channels used to transmit voice, data, and image signals from one system node to another. E1 channel 16 is used for signaling if signaling is enabled.
Page 74: Table 3 Synchronous Subrate Port Packing Arrangement
LBI-39224 subchannel 1 subchannel 2 subchannel 3 subchannel 4 subchannel 5 Table 3 Synchronous Subrate Port Packing Arrangement Save And Send MIM T1/E1 Configurations T1/E1 Digital Site Configuration dialog T1/E1 Interface Card Auto-configuration dialog box changes must be sent before the changes will come into effect at the CEC/IMC. This reprograms the MIM Controller Boards and T1/E1 Interface Cards.
Page 75 LBI-39224 "Send to Site Successful" message will be received to confirm that the data was received by the interface module Controller Board. Bus Slot configuration data is based on the channel assignment in the Set Site Channel Disbursement field (one bus slot per channel assigned) and is compared to the current configuration at the CEC/IMC Manager;...
Page 76: Nim Channel Configuration
LBI-39224 will appear to warn of the unsaved changes and the user will be given the opportunity to save and exit (Save) or exit without saving the changes (Cancel). Site Channel Configuration List dialog box Send Choose the Send button to send the T1/E1 site channel configuration data to the respective interface module.
Page 77 LBI-39224 Each NIM is assigned a unique site assignment number (1 thru 32) within the CEC/IMC. This number corresponds to and matches the site assignment number set via the 5-bit DIP switch setting on the interface module’s Controller Board. A NIM may be either Audio Board equipped or T1/E1 Interface Card equipped, both situations will be discussed.
Page 78: Figure 20 Nim Site Channel Configuration List Dialog Box
LBI-39224 LBI-38938, CEC/IMC Digital Audio Switch Installation, Set-up, and Troubleshooting. NIM "Site" Selection Prior to actual channel configuration, the interface module to be configured must be selected. From the CEC/IMC Manager menu bar select Configure System / CEC/IMC Configuration / NIM to display the Site Channel Configuration List dialog box for that module.
Page 79 LBI-39224 Configured/Active Sites: The Configured/Active Sites list box displays NIMs which have been added but not yet channel-configured, NIMs which have had previous channel configurations performed, and NIMs which have been previously channel-configured and have an active Controller Board control data link. Before a site-type interface module can be channel- configured, it must be listed in the Configured/Active Sites list box.
Page 80: Figure 21 Nim Site Channel Configuration Dialog Box
LBI-39224 selecting T1/E1 Interface will activate T1/E1 Digital Site Configuration dialog box. These options are discussed in detail in subsequent sections. Audio Board Equipped NIM Configuration This section describes configurations for channels within Audio Board- equipped NIMs. All channel parameters are configured from the (NIM) Site Channel Configuration dialog box, Figure 21.
Page 81 LBI-39224 View Current CEC/IMC Manager Channel Configuration The upper list box in the Site Channel Configuration dialog box, labeled "CEC/IMC Manager," displays current channel configurations stored on the CEC/IMC Manager hard disk for the currently selected NIM. As the edit fields above this list box are modified for a selected channel, the changes will appear also in this list box for the selected channel.
Page 82 LBI-39224 NOTE If Automatic Level Control (ALC) is disabled for the selected channel, subtract 1.5 dBm from the required Input Signal Level setting. For example, if the required input signal level is -10 dBm, enter -11.5 dBm. ALC is disabled by setting the ALC text box to "NO."...
Page 83 LBI-39224 Save and Send NIM Audio Board Configurations When channel configuration of the selected NIM is complete, the Site Channel Configuration dialog box changes must be sent to the CEC/IMC before the changes will take effect. This reprograms the NIM Controller Boards. However, it is important to save the new configuration prior to sending it to the CEC/IMC because a send will send the last configuration saved to disk;...
Page 84 LBI-39224 selecting it via the selection list box, changing the configuration as required, and then choosing Save. Close Choose the Close button to exit this dialog box and return to the Site Channel Configuration List dialog box. If any changes have been made saved,...
Page 85 LBI-39224 T1/E1 Equipped NIM Configuration This section describes configuration for channels of T1/E1 Interface Card-equipped NIMs. Channel configurations are performed from the T1/E1 Digital Site Configuration dialog box, shown in Figure 18 on page 3-39, and from the T1/E1 Interface Card Auto-configuration dialog box, Figure 19 on page 3-42.
Page 86 LBI-39224 depending upon board configuration, can provide modem-less data links over spare T1/E1 channels to either internal or external devices. Some, all, or none of these ports can be utilized depending on board configuration. Five of the subrate ports support synchronous or asynchronous data links and the remaining three are synchronous-only ports.
Page 87 LBI-39224 Slave to external 1.544 MHz - Redundant Clock Circuits generated by the Clock Board synchronized to 1 (or 2 with redundancy) external clock source. Any CEC/IMC can be synchronized to the timing output from a T1/E1 multiplexer, microwave radio, fiber network, etc. Connect the external timing source to both Clock Boards in the CEC/IMC for redundancy.
Page 88 LBI-39224 Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Analog or Digital Voice In addition to T1 or E1 selection, T1/E1 Interface Card configuration includes selecting one of three primary board operating modes: –...
Page 89 LBI-39224 – Digital voice/data using subrate ports mode (currently not supported) – Digital voice/data using T1/E1 mode (currently not supported) Line Type This is a read-only field which indicates which type of line (T1 or E1) that the system is configured for. Frame Format Framing deals with how the digitized data stream is configured (formatted), a data stream with one framing format would not be...
Page 90 LBI-39224 slightly, and the changes become more pronounced the further the signal travels down the line. The outgoing original signal is modified based upon line length so that the signal arriving at the destination closely resembles an ideal signal. Select the line length from the drop- down list box for T1 applications.
Page 91 LBI-39224 Set Defaults Choose the Set Defaults button to select the pre-programmed default values from the CEC/IMC Manager hard disk. These values will replace any currently displayed values; however, these "new" values must be saved and sent before they will become the new configuration. T1/E1 Interface Card Auto-configuration Subrate ports and channel assignments are auto-configured by the CEC/IMC Manager according to the number of free T1/E1 channels.
Page 92 LBI-39224 Asynchronous (async) ports, up to 5, are assigned first and then synchronous (sync) ports are assigned. Save And Send NIM T1/E1 Configurations T1/E1 Digital Site Configuration dialog T1/E1 Interface Card Auto-configuration dialog box changes must be sent before the changes will come into effect at the CEC/IMC. This reprograms the NIM Controller Boards and T1/E1 Interface Cards.
Page 93 LBI-39224 action is taken by the system) and when the MOM Controller Board receives this new data it will send an acknowledgment message back to the CEC/IMC Manager, which will then display the confirmation box: "Do you want to activate TDM Bus Slots? OK - will cause all CTRL boards to reset."...
Page 94: Pim Channel Configuration
LBI-39224 Site Channel Configuration List dialog box Send Choose the Send button to send the T1/E1 site channel configuration data to the respective interface module. This procedure must be performed before the interface module will operate with the new configuration. Only configured and configured-and-active (C and C/A prefixes) configurations may be sent.
Page 95 LBI-39224 PIM "Site" Selection Prior to actual channel configuration, the interface module to be configured must be selected. From the CEC/IMC Manager menu bar select Configure System / CEC/IMC Configuration / PIM to display the Site Channel Configuration List dialog box for that module. Each Site Channel Configuration List dialog box displays the configurable PIMs and configured/active PIMs.
Page 96 LBI-39224 available PIMs may be selected at one time for modification in the Site Channel Configuration dialog box. All selected PIMs in this list will also be included in the "Save As…" dialog box that is accessed from Site Channel Configuration dialog T1/E1 Digital Site Configuration dialog box.
Page 97 LBI-39224 Configured/Active Sites list box will be removed and returned to the Configurable Sites list box. Audio Board-Equipped PIM Configuration This section describes configurations for channels within Audio Board- equipped site-type interface modules. All channel parameters are configured from the Site Channel Configuration dialog box. Only those PIMs which...
Page 98 LBI-39224 View Current CEC/IMC Channel Configuration The lower list box in the Site Channel Configuration dialog box, labeled "CEC/IMC," displays the current channel configurations stored at the CEC/IMC for the currently selected site-type interface module. Information within this box updates only after Send is performed from the preceding Site Channel Configuration List dialog box.
Page 99 LBI-39224 NOTE If Automatic Level Control (ALC) is disabled for the selected channel, subtract 1.5 dBm from the required Input Signal Level setting. For example, if the required input signal level is -10 dBm, enter -11.5 dBm. ALC is disabled by setting the ALC text box to "NO."...
Page 100 LBI-39224 NOTE earlier CEC/IMC firmware/software releases, slot allocations could only be made contiguously starting with channel one (1). In some systems this produced slot allocation inefficiencies—some slots had to be allocated but were never used. CEC/IMC software/firmware release 5.0 (and later) provides non-contiguous slot allocations.
Page 101 LBI-39224 Site Channel Configuration dialog box Save Choose the Save button to perform an immediate save of the currently selected PIM channel configuration. Other PIMs displayed in the list box located at the top of the dialog box are not saved. This channel configuration is saved on the CEC/IMC Manager's hard disk drive.
Page 102 LBI-39224 Site Channel Configuration List dialog box Send Choose the Send button to send the site channel configuration data to the respective interface module. This procedure must be performed before the interface module will operate with the new configuration. Only configured and configured-and-active (C and C/A prefixes) configurations may be sent.
Page 103 LBI-39224 NOTE Like the CEC/IMC Audio Board, each T1/E1 Interface Card within a CEC/IMC interface module must have a unique board address setting. This address is 1 - 8 (addresses 2 - 8 are currently not available). NOTE T1/E1 selection is performed at the CEC/IMC Manager on a CEC/IMC wide basis.
Page 104 LBI-39224 T1/E1 Digital Site Configuration Networked Systems Considerations Any system nodes that are connected using T1/E1 Interfaces must remain frequency locked at all times. The T1/E1 Interface design allows for total network synchronization by offering the following CEC/IMC Configuration options. Each of these options are selectable by configuration of both the Clock Boards and the T1/E1 Interface Cards.
Page 105 LBI-39224 Slave to external 2.048 MHz (E1 mode only) - Redundant Clock Circuits generated by the Clock Board synchronized to 1 (or 2 with redundancy) external clock source. CEC/IMC can be synchronized to the timing output from a T1/E1 multiplexer, microwave radio, fiber network, etc. Connect the external timing source to both Clock Boards in the CEC/IMC for redundancy.
Page 106 LBI-39224 Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Analog or Digital Voice In addition to T1 or E1 selection, T1/E1 Interface Card configuration includes selecting one of three primary board operating modes: –...
Page 107 LBI-39224 – Digital voice/data using subrate ports mode (currently not supported) – Digital voice/data using T1/E1 mode (currently not supported) Line Type This is a read-only field which indicates which type of line (T1 or E1) that the system is configured for. Frame Format Framing deals with how the digitized data stream is configured (formatted), a data stream with one framing format would not be...
Page 108 LBI-39224 slightly, and the changes become more pronounced the further the signal travels down the line. The outgoing original signal is modified based upon line length so that the signal arriving at the destination closely resembles an ideal signal. Select the line length from the drop- down list box for T1 applications.
Page 109 LBI-39224 Set Defaults Choose the Set Defaults button to select the pre-programmed default values from the CEC/IMC Manager hard disk. These values will replace any currently displayed values; however, these "new" values must be saved and sent before they will become the new configuration. T1/E1 Interface Card Auto-configuration Subrate ports and channel assignments are auto-configured by the CEC/IMC Manager according to the number of free T1/E1 channels.
Page 110 LBI-39224 (async) ports, up to 5, are assigned first and then synchronous (sync) ports are assigned. Save And Send PIM T1/E1 Configurations T1/E1 Digital Site Configuration dialog T1/E1 Interface Card Auto-configuration dialog box changes must be sent before the changes will come into effect at the CEC/IMC. This reprograms the PIM Controller Boards and T1/E1 Interface Cards.
Page 111 LBI-39224 action is taken by the system) and when the MOM Controller Board receives this new data it will send an acknowledgment message back to the CEC/IMC Manager, which will then display the confirmation box: "Do you want to activate TDM Bus Slots? OK - will cause all CTRL boards to reset."...
Page 112: Vmim Channel Configuration
LBI-39224 Site Channel Configuration List dialog box Send Choose the Send button to send the T1/E1 site channel configuration data to the respective interface module. This procedure must be performed before the interface module will operate with the new configuration. Only configured and configured-and-active (C and C/A prefixes) configurations may be sent.
Page 113: Figure 22 Vmim Configuration Menu
LBI-39224 two VMIM/CIA sets thus providing up to a total of sixty-four conventional channel interfaces per CEC/IMC. A VMIM is formed by a Controller Board and up to eight Audio Boards. VMIM-related channel configurations are performed from the Site Channel Configuration dialog box. Although not required, it is recommended that VMIM channel configurations be accomplished prior to CIA rack-related conventional channel configurations which are described later in CONVENTIONAL CHANNEL CONFIGURATION...
Page 114 LBI-39224 VMIM, this represents an operating link between a CIA rack and the VMIM Controller Board. Help Choose the Help command button to access the Help function. (Help is also available by pressing the F1 key.) Configurable Sites: The Configurable Sites list box displays all inactive unconfigured VMIM interface modules.
Page 115 LBI-39224 Choose the Add button to move a selected VMIM from the Configurable Sites list box and "add" it to the Configured/Active Sites list box where it can be selected for configuration. If upon adding a VMIM, a configuration data file exists on the CEC/IMC Manager's hard disk drive from a previous add and delete, it will be added to the Configured/Active Sites list box with its configuration data file (with a ** prefix).
Page 116 LBI-39224 VMIM Audio Board Channel Configuration channel parameters configured from Site Channel Configuration dialog box. Only those VMIMs which were selected in the Site Channel Configuration List dialog box are available for channel configuration. The selected VMIMs are displayed in a list box at the top center of the dialog box. Help Choose the Help button to access the Help function.
Page 117 LBI-39224 CEC/IMC to Disk Choose the CEC/IMC to Disk button to write the current CEC/IMC configuration data to the CEC/IMC Manager hard disk. This action will overwrite the current CEC/IMC Manager configuration for the selected interface module. This function is useful if the CEC/IMC Manager configuration database is lost for any reason.
Page 118 LBI-39224 Output Signal Level (dBm) This setting establishes the signal level in dBm (600-ohm impedance; 0 dBm = 1 milliwatt) sent out by the selected channel's line output. The setting specifies the voice peak (test tone) level sent out by the channel. The valid range is -25.0 dBm to +13.0 dBm in 0.5 dBm increments.
Page 119 LBI-39224 CAUTION DO NOT enable ALC for any channel if the respective Audio Board part number is 19D903302P1 (any revision). Automatic Level Control (ALC) provides compensation for signal level variances in a channel line input signal. As required, enable ALC for the selected channel by entering "YES"...
Page 120 LBI-39224 choosing Save As… a small dialog box (see Figure 17 on page 3-34) will appear which allows selection of a new VMIM number. Select the desired VMIM from one of the choices in the drop-down list box, the choices listed are the selected VMIMs in the Configured/Active Sites list box.
Page 121: Ctim Channel Configuration
LBI-39224 "**" (unconfigured and unsaved) VMIMs appearing in the Configured/Active Sites list box will be removed and returned to the Configurable Sites list box. 3.8.5 CTIM Channel Configuration The interface between the CEC/IMC and a Centralized Telephone Interconnect System (CTIS) is accomplished with a Centralized Telephone Interconnect Module (CTIM).
Page 122 LBI-39224 Configurable Sites: The Configurable Sites list box displays all unconfigured site-type interface modules. If a CTIM appears in this box, no channel configuration exists at the CEC/IMC Manager and no active Controller Board control data link exists at the CEC/IMC for the corresponding site assignment number.
Page 123 LBI-39224 files from the CEC/IMC Manager's hard disk drive. Therefore, if the deleted CTIM is subsequently added back to the Configured/Active Sites list box via the Add button, the previous channel configuration is lost (this configuration data must saved Site Channel Configuration dialog box before it can be resent to the CEC/IMC).
Page 124 LBI-39224 Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) View Current CEC/IMC Manager Channel Configuration The upper list box in the Site Channel Configuration dialog box, labeled "CEC/IMC Manager," displays current channel...
Page 125 LBI-39224 restore the CEC/IMC Manager configuration database for the selected interface module. Channel Selection Select a channel (1 thru 32) for configuration from the CEC/IMC Manager channel list box, only one channel may be selected at a time. The selected channel and its configuration data will be displayed in the edit fields above the CEC/IMC Manager list box.
Page 126 LBI-39224 Channel Signaling This drop-down list box specifies the type of channel signaling sent out by the selected channel for control of external equipment such as an EDACS trunked site or co-located mux equipment. Valid settings are "NONE" for no signaling, "TONE" for tone control signaling, "E&M" for M-lead control signaling, and "BOTH"...
Page 127 LBI-39224 NOTE earlier CEC/IMC firmware/software releases, slot allocations could only be made contiguously starting with channel one (1). In some systems this produced slot allocation inefficiencies – some slots had to be allocated but were never used. CEC/IMC software/firmware release 5.0 (and later) provides non-contiguous slot allocations.
Page 128 LBI-39224 the selected channel by entering "YES" in the ALC text box or disable it by entering "NO." Save and Send CTIM Configurations When channel configuration of the selected CTIM is complete, the Site Channel Configuration dialog box changes must be sent to the CEC/IMC before the changes will take effect.
Page 129 LBI-39224 Close Choose the Close button to exit the Site Channel Configuration dialog box and return to the Site Channel Configuration List dialog box. If any changes have been made and not saved, you will be prompted (Write Changes to Disk?) to save and exit (Yes), exit without saving (No), or cancel the Close command and remain in the dialog box (Cancel).
Page 130: Confirmed Call
LBI-39224 3.9 CONFIRMED CALL If confirmed call is enabled for the group/unit at the System Manager, a unit that performs a confirmed call will not be allowed to transmit on a wide area (multisite) call until all sites that should pick up the call have responded with a working channel assignment or until a time-out period expires.
Page 131: Figure 23 System Options Dialog Box
LBI-39224 Figure 23 System Options Dialog Box Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Close Choose the Close button to exit the System Options dialog box and return to the CEC/IMC Manager main window. If any changes have been made saved,...
Page 132 LBI-39224 will continue to fail (10 second delay on every call) until the failed site is restored (normal Confirm Call operation). DVIM Confirmed Call DVIM Confirmation/Console Tracking allows the DVIM to filter radio originated digital group calls if those groups are programmed at consoles or logging recorders.
Page 133: Telephone Interconnect
LBI-39224 Read Disk Choose the Read Disk button to view the current configuration stored at the CEC/IMC Manager hard disk. Read CEC/IMC Choose the Read CEC/IMC button to view the current Confirm Call configuration at the CEC/IMC. 3.10 TELEPHONE INTERCONNECT Telephone Interconnect options...
Page 134: Console Configuration
LBI-39224 Caller ID This feature allows Caller ID on inbound interconnect calls. This is done by assigning a "LID" to each telephone line. The NIM will now track phone calls by searching the channels for the active phone line to pick up radio keys/unkeys.
Page 135: Cim Channel Configuration
LBI-39224 Figure 24 Console Configuration Menu 3.11.1 CIM Channel Configuration The CEC/IMC is connected to the EDACS C3 Maestro, C3 Maestro for Windows NT, and C3 Modular/Desktop dispatch consoles by the Console Interface Module (CIM). Each CIM is assigned a unique console assignment number (1 thru 32) within the CEC/IMC.
Page 136: Figure 25 Console Channel Configuration List Dialog Box
LBI-39224 Figure 25 Console Channel Configuration List Dialog Box Each Console Channel Configuration List dialog box displays the configurable consoles and configured/active consoles. An active console represents an operating link between a dispatch console and the CIM Controller Board. Help Choose the Help button to access the Help function.
Page 137 LBI-39224 consoles from this list will also be listed in the "Save As…" dialog box that is accessed from the Console Channel Configuration dialog box. The particular state indicated by the prefix is defined in Table 1, Configured/Active Sites Prefix Definitions on page 3-25. Choose the Add button to move a selected console from the Configurable Consoles list box and "add"...
Page 138: Figure 26 Console Channel Configuration Dialog Box
LBI-39224 CIM Audio Board Channel Configuration channel parameters configured from Console Channel Configuration dialog box, Figure 26. Only those consoles which were selected Console Channel Configuration List dialog box are available for channel configuration. Select the desired console interface modules to configure from the Configured/Active Consoles list, or add the desired modules from the Configurable Consoles list, if not already listed.
Page 139 LBI-39224 at the CEC/IMC for the currently selected console interface module. Information within this box updates only after Send is performed from the preceding Console Channel Configuration List dialog box. CEC/IMC to Disk Choose the CEC/IMC to Disk button to write the current CEC/IMC configuration data to the CEC/IMC Manager hard disk.
Page 140 LBI-39224 LBI-38938 contains a line level adjustment overview section which contains general information and general recommendations for both input and output level settings. Bus/Slot Equipped Only one TDM bus time slot is normally required for each console since there is only one transmit channel per console. However, if the Call Director option will be used with the console two slots are required (see Note below).
Page 141 LBI-39224 configuration prior to sending it to the CEC/IMC because a send will send the last configuration that was saved to disk; saving first ensures that the actual CEC/IMC channel configuration will be the same as the channel configuration stored on the CEC/IMC Manager hard disk. To save and send configurations, action is required first in the Console Channel Configuration dialog box and then in the Console Channel Configuration List dialog box.
Page 142: Console User Profile Configuration
LBI-39224 Console Channel Configuration List dialog box Send Choose the Send button to send the console channel configuration data to the respective interface module. This procedure must be performed before the interface module will operate with the new configuration. Only configured and configured-and-active (C and C/A prefixes) configurations may be sent.
Page 143: Figure 27 Console User Profile Configuration Dialog Box
LBI-39224 Figure 27 Console User Profile Configuration Dialog Box Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Console Profiles The Type and Version fields in the upper right corner of the Console User Profile Configuration dialog box identify the currently selected console type and software version number.
Page 144 LBI-39224 16382 range and must not conflict with other unit ID numbers in the System Manager's LID database. Number 16383 is the default for uninitialized consoles and indicates to the MOM Controller Board that the console is not configured. The Console Alias field defines an 8- character alias for each console.
Page 145 LBI-39224 (Console) Setup Number This drop-down list box displays which console user setup is currently being displayed on-screen. Select from this list box to view or configure specific console user setup data for each console. Ten (10) different set-ups are supported at each console. Delete Choose the Delete button to remove ("delete") a console user profile database from the CEC/IMC Manager hard disk.
Page 146 LBI-39224 for definitions of the three (3) possible levels of Individual Call functionality each C3 Maestro console may have. Visual Indicators Trunked/Failsoft Display Select this check box to enable the trunked operational status indicators and Failsoft tones at the console. Selecting this check box will also display the Audible Trunked/Failsoft Tone check box in the Audio Indicators group, see the discussion of the Audible Trunked/Failsoft Tone check box under Audio Indicators for function of this checkbox.
Page 147 LBI-39224 console originated calls. This field is used only for C3 Modular/Desktop consoles. Caller Label Delay Time delay, in seconds, that the CALLER is displayed after the call has dropped. This delay allows the dispatcher to see who made the call for a short time after the call was dropped.
Page 148 LBI-39224 Default Module Volume This is the default volume setting on the unselect speaker (selected above) for incoming calls. Use the drop-down list box to select a value from 0 thru 32. NOTE For C3 Maestro for Windows NT the volume settings are 0 - 10, however, the actual volume range is the same.
Page 149: Table 4 Console Individual Call Levels
LBI-39224 Emergency Clear Silences Alarm Select this check box to enable the EMERGENCY tone to be silenced when the EMERGENCY is cleared by anyone. Unselect to disable, the tone will remain until cleared by dispatcher. Minimum Alarm Volume This is the minimum level at which an emergency tone will be heard. The greater of the module volume or this volume will be used for the emergency tone level.
Page 150 LBI-39224 performed from the Console User Profile Configuration dialog box. It is important to save the new configuration to the CEC/IMC Manager hard disk prior to sending it to the CEC/IMC because a send will send the last configuration that was saved to disk. However, if after making changes, a send is performed prior to a save, the CEC/IMC Manager will automatically save the new configuration to disk;...
Page 151: C3 Maestro Console Hardware Configuration
LBI-39224 procedure must be performed before the console will operate with the new configuration. Close Choose Close button exit Console User Profile Configuration dialog box and return to the CEC/IMC Manager main window. If any changes have been made and not saved, you will be prompted (Write Changes to Disk?) to save and exit (Yes), exit without saving (No), or cancel the Close command and remain in the dialog box (Cancel).
Page 152 LBI-39224 and its software version will be displayed in the upper right corner of the dialog box. Total Number of Speakers Select the number of speakers that the selected console is equipped with from the drop-down list box. Most consoles have two speakers, the select speaker and the unselect speaker.
Page 153: Console Privilege Lists
LBI-39224 replaced with the current configuration. If the CEC/IMC Manager is running remotely or as a part of the EDACS Network Manager, this configuration is saved on the CEC/IMC Manager server, typically local to the CEC/IMC; it is not saved at the remote location. Save As...
Page 154 LBI-39224 is used to define the units, groups, and conventional channels that the console is allowed to program. CAUTION Currently dedicated SAID entries are shown in the Group list. These entries should not be privileged for any console. It is recommended that these entries are given a name in the form SAIDXXXX.
Page 155: Figure 29 Console Privilege List Dialog Box
LBI-39224 Figure 29 Console Privilege List Dialog Box Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Configure Privilege Lists Although only Unit privilege list definition is discussed in the following paragraph, Group and Conventional privileges are defined the same way as Unit privileges.
Page 156 LBI-39224 Select All Choose the Select All button to enable all units to be programmed. All the asterisks on the right should be displayed. This allows the dispatcher to program any unit. This function is handy when only a few units will not be allowed to be programmed.
Page 157: C3 Modular/Desktop Console Configuration
LBI-39224 without saving (No), or cancel the Close command and remain in the dialog box (Cancel). 3.11.5 C3 Modular/Desktop Console Configuration A special configuration procedure must be performed to set-up each C3 Modular/Desktop console's Translator. This procedure configures the console's module database stored in the Translator Controller Board. Configurable parameters for each module are module type (trunked or conventional), display type (alphanumeric or fixed), unselect speaker number, and module present (yes or no).
Page 158 LBI-39224 box, the selected module and its parameters will be displayed in the text boxes above this list box. Change any or all of the parameters as required. Module Type The Module Type may be either TRUNKED or CONVENTIONAL. TRUNKED means that a trunked unit or group may be programmed into that module.
Page 159 LBI-39224 Module Present The Module Present indicates whether the module actually exists. Each C3 Modular/Desktop console can support up to 64 modules, but the Module Present should only have a YES for those modules actually present. Select this text box using either the Enter (or Tab) key or selection cursor and enter "y"...
Page 160: View Patch/Simulselect
LBI-39224 configuration information in NOVRAM and will not require another download unless the configuration changes. Close Choose Close button exit C3 Modular/ Desktop Console Configuration dialog box. Any configurations not saved and sent to will be lost unless Send and Save are performed first.
Page 161: Figure 31 Patch And Simulselect View Dialog Box
LBI-39224 Figure 31 Patch and Simulselect View Dialog Box Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Type The type is either PATCH or SIMUL (Simulselect). SAID The SAID is the special group ID assigned to a "soft" or console patch or simulselect.
Page 162: Digital Voice Channel Configuration
LBI-39224 Caller The Unit ID of the console currently utilizing this patch/simulselect. Site Mask The sites currently involved in this patch/simulselect. This is a 32 bit value in hex format, where each bit corresponds to one of the 32 possible sites, i.e. bit 1 site 1, bit 2 site 2, etc. The rightmost bit is bit 1.
Page 163: Dvim Selection
LBI-39224 allow the CEC/IMC and associated consoles to process clear voice as well as Aegis™ digital and Aegis encrypted calls. DVIM channels are either pooled (dynamically assigned) or dedicated to a particular group. Each DVIM channel should be programmed for either pooled or dedicated operation.
Page 164: Figure 32 Dvim Channel Configuration List Dialog Box
LBI-39224 Figure 32 DVIM Channel Configuration List Dialog Box Each DVIM Channel Configuration List dialog box displays the configurable DVIMs and configured/active DVIMs. An active DVIM represents an operating link between a DVIU and the DVIM Controller Board. Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Configurable DVIM: The Configurable DVIM list box displays all unconfigured DVIM...
Page 165: Dvim Configuration
LBI-39224 Configured/Active Sites Prefix Definitions, on page 3-25 for an explanation of the different prefixes if necessary. Choose the Add button to move a selected DVIM from the Configurable DVIM list box and "add" it to the Configured/Active DVIM list box where it can be configured. If upon adding a DVIM, a configuration data file exists on the CEC/IMC Manager's hard disk drive from a previous add and delete, the DVIM will be added with a "C"...
Page 166: Figure 33 Dvim Channel Configuration Dialog Box
LBI-39224 be changed at the CEC/IMC. Input and output signal levels are set to 0 dBm, ALC is always disabled, and channel signaling is always off. The remaining channel parameters configured from DVIM Channel Configuration dialog box, Figure 33. Only those DVIMs which were selected in the DVIM Channel Configuration List dialog box are available for channel configuration.
Page 167 LBI-39224 this box updates only after Send is performed from the DVIM Channel Configuration List dialog box. Channel Selection Select a channel (1 thru 32) for configuration from the CEC/IMC Manager channel list box, only one channel may be selected at a time. The selected channel and its configuration data will displayed in the edit fields above the CEC/IMC Manager list box.
Page 168 LBI-39224 Dynamic Channels In this mode of operation, the DVIM processes Aegis calls that are not assigned to dedicated channels. The DVIM assigns the call to the first available non-dedicated channel. The only limitation with this mode of operation is all dynamic channels must have the same DVIU key. To configure a dynamic channel, change the channel equipped field for that channel to a "Y"...
Page 169 LBI-39224 DVIM Channel Configuration List dialog box is required to save and send DVIM configurations. DVIM Channel Configuration dialog box Save Choose the Save button to perform an immediate save of the currently selected DVIM channel configuration. Other DVIMs displayed in the list box located at the top of the dialog box are not saved.
Page 170: Digital Causeway (Causeway Default To Digital)
LBI-39224 Controller Board; the Audio configuration is sent directly out from there to the respective interface module Controller Board. A "Send to Site Successful" message will be received to confirm that the data was received by the interface module Controller Board. Bus Slot configuration data is compared to the current configuration at the CEC/IMC Manager;...
Page 171: Distributed Multisite / Stargate Configuration
LBI-39224 3.13 DISTRIBUTED MULTISITE / STARGATE CONFIGURATION A common or central network switch known as a "StarGate Controller" has three or more switches linked to it via NIMs. Users select network operation on a wide area fleet/group basis at the System Manager. Each NIM is assigned a unique site assignment number (1 thru 32) within the CEC/IMC.
Page 172: Figure 34 Stargate / Remote Cec / Nim Configuration Dialog Box
LBI-39224 Figure 34 StarGate / Remote CEC / NIM Configuration Dialog Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Options and Controller Configuration Group call console tracking, remote CEC interface operation, and NIM baud rates for the network are set on a per NIM basis.
Page 173 LBI-39224 This option should only be disabled (unselected) in special circumstances in which routing all calls would cause excessive NIM traffic. In general, StarGate/NIM networks which require large amounts of console dispatch operations will require enabling of this option. Remote CEC Interface This function allows all call traffic being monitored by a console or logging recorder on a remote CEC system to be routed by the NIM link.
Page 174 LBI-39224 Close Choose the Close button to exit this dialog box and return to the CEC/IMC Manager main window. If any changes have been made and not saved, you will be prompted (Write Changes to Disk?) to save and exit (Yes), exit without saving (No), or cancel the Close command and remain in the dialog box (Cancel).
Page 175: Conventional Channel Configuration
LBI-39224 3.14 CONVENTIONAL CHANNEL CONFIGURATION The VMIM interface module and CIA secondary interface rack couple conventional tone or DC controlled base stations and conventional voting systems to the CEC/IMC switch. Each VMIM/CIA set can provide thirty-two CEC/IMC conventional channel interfaces, and a CEC/IMC may be equipped with two VMIM/CIA sets, providing up to sixty-four conventional channel interfaces per CEC/IMC.
Page 176 LBI-39224 channel at one CEC/IMC), or eight (8) CEC/IMCs in a StarGate network may each contain up to a maximum of thirty-two (32) conventional channels. In both of the preceding examples the highest conventional channel in this configuration would actually be 256; however, channel 256 cannot be used due to CEC/IMC call message formats.
Page 177: Table 5 Switch Assignment Number-To-Conventional Channel Allocation Mapping For Stargate Networks (Max. Conv. Channels Per Cec/Imc = 64)
LBI-39224 match the switch assignment number set by the DIP switches on the MOM Controller Board. See CEC/IMC Digital Audio Switch Installation, Set-Up And Troubleshooting (LBI-38938) for MOM Controller Board DIP switch configuration details. Table 5 maps the conventional channel allocation numbers in a StarGate network when the maximum number of conventional channels per CEC/IMC is set to sixty-four (64).
Page 178 LBI-39224 CEC/IMC SWITCH CONVENTIONAL CHANNEL ASSIGNMENT NUMBERS ALLOCATIONS 36, 44, 52, 60 97 – 128 37, 45, 53, 61 129 – 160 38, 46, 54, 62 161 – 192 193 – 224 39, 47, 55, 63 40, 48, 56, 64 225 –...
Page 179: Figure 35 Conventional Channel Configuration Dialog Box
LBI-39224 Figure 35 Conventional Channel Configuration Dialog Box A CEC/IMC Manager can only program/configure its (local) conventional channels. When local conventional channel programming is saved at a CEC/IMC Manager, the channel aliases and channel LIDs of the changed channels are sent to all other CEC/IMCs in the StarGate network.
Page 180: Table 7 Conventional Channel Locations (Example With Max. Conv. Channels Per Cec/Imc = 64) (Non-Inclusive Listing)
LBI-39224 It is recommended that a conventional channel LID stored in the CEC/IMC Manager be given the same alias as the corresponding conventional channel LID at the System Manager, i.e. if a System Manager exists, changing a conventional channel alias at the CEC/IMC Manager is possible but not recommended.
Page 181: Appendix B - Logged Warning Definitions
LBI-39224 CEC/IMC CIA RACK CIA RACK NETWORK SWITCH NUMBER CHANNEL CONV. ASSIGNMENT NUMBER CHANNEL NUMBER NUMBER 255* * Channel 256 is not available. Remote Conventional Channel Logged Warnings As previously stated, when conventional channel programming is saved at a CEC/IMC Manager, conventional channel data is sent to all other CEC/IMCs in the StarGate network (the remote CEC/IMCs).
Page 182: Causeway Patch / Simulselect
LBI-39224 Local/Remote Conventional Channel Dispatch After a console has received the System Manger conventional channel database information and its privilege list, local and remote conventional channel communications operate almost identically. The console operator can program the channel to a communication module, dispatch to the channel, exercise any available conventional channel relay function (local/remote, main/standby, etc.), or patch/simulselect the channel to other conventional channels or trunked groups.
Page 183 LBI-39224 – reduced audio delay for a console PTT – consoles may pre-empt Causeway patches and Causeway simulselects – patch/simulselect update time is minimized when a trunked radio roams/logs into a new trunked site – eliminates the single-point-of-failure (MOM Controller Board) experienced with "soft"...
Page 184 LBI-39224 – A console-originated conventional channel call is routed only to the conventional channel. This is because the consoles know nothing about the Causeway patch stored in the CCI and VMIM. The Logical ID (LID) assigned to the conventional channel handles this call. Causeway Simulselect Operation Causeway simulselect operation is summarized as follows: –...
Page 185: Conventional Channel Configuration
LBI-39224 3.14.3 Conventional Channel Configuration NOTE After all conventional channels have been configured, saved, and sent, a CEC/IMC Manager-based System Manger database transfer conventional channel information recommended. See SYSTEM MANAGER DATABASE UPLOADS on page 3-14 for details. After completing the transfer, privilege lists of consoles which may require access to conventional channels should be updated by adding the required conventional channels to each console's privilege list.
Page 186 LBI-39224 Conventional Channel Configuration dialog box. Unless otherwise stated, all information applies to both local and remote conventional channels. From the CEC/IMC Manager menu bar select Configure System CEC/IMC Configuration VMIM Conv. Interface Adapter Configuration (see Figure 22) to display the Conventional Channel Configuration dialog box.
Page 187 LBI-39224 Conventional Channel Configuration dialog box displays the first local conventional channel high-level configuration. The displayed configuration is a CEC/IMC Manager-stored configuration, not a CEC/IMC-stored configuration. Channel Selection range = 1 – 255. To select a different channel, click in the text box, enter (type) the new channel number, and then select elsewhere within the dialog box, or press the Tab key to advance to the next text box.
Page 188 LBI-39224 NOTE At the System Manager, all conventional channel LIDs must be programmed with a "Unit Type" equal to "Other." Channel Alias This text box displays the alias (name) for the entered LID as defined at the System Manager (if present). It is recommended that a conventional channel's LID stored in the CEC/IMC Manager be given the same alias as the corresponding conventional channel's LID at the System Manager.
Page 189 LBI-39224 numbers representative of bold-face numbers in the tables are displayed for a given max. conventional channels per CEC/IMC.) Switch Number range = 33 – 48. Channel Range Range of conventional channels that current Switch Number is allocated. Channel Range = 1 – 255; maximum of 64 sequential channels per CEC/IMC.
Page 190 LBI-39224 Line Type Select 2-wire (simplex) or 4-wire (duplex) line interfacing by selecting the respective option button within this group. Selection must match the line connection requirements to/from the conventional base station for the currently selected channel. Default is 4-wire. Coupling Select Tx/Rx Coupled or No Coupling by selecting the respective option button.
Page 191 LBI-39224 NOTE The VOX threshold and 2175 Hz hold tone level settings are now also stored at the CEC/IMC Manager's hard disk. This is a change from previous versions, which stored the VOX threshold and 2175 Hz hold tone level settings only at the CEC/IMC.
Page 192 LBI-39224 Remote Control Select this option if the currently selected conventional channel is connected through a Conventional Concentrator Card and the card is wired in remote controller enable/disable configuration and consoles should be allowed to toggle the relays by sending remote enable/disable commands (for example, F1 function key from the C3 Maestro console's conventional function note card).
Page 193 LBI-39224 Tone (E&M PTT) Standard tone signaling on all but PTT (station transmit) commands, E&M M-lead signaling on PTT commands. Standard tone signaling can be modified per State Table (low- level) configuration on a per command basis. Tone (Tone/E&M PTT) Standard tone signaling on all commands, PTT commands also include E&M M-lead signaling.
Page 194 LBI-39224 NOTE The maximum number of conventional channels configurable for Causeway operation may be limited by EDACS license privileges. See FEATURE DATA in Chapter 4 for more information. None Select this option button if no Causeway operation is desired for the currently selected conventional channel. Patch Select this option button if the currently selected conventional channel requires Causeway patch operation.
Page 195 LBI-39224 reprograms the CCI and VMIM Controller Boards. If after making changes, a save is performed but a send is not, the actual CEC/IMC conventional channel operation will differ from the displayed settings upon re-entering the Conventional Channel Configuration dialog box.
Page 196: Table 8 Conventional Base Station Commands
LBI-39224 Close Close Choose button exit Conventional Channel Configuration dialog box and return to the CEC/IMC Manager main window. Any configuration changes not saved will be lost; there is no prompt to save any changes before exiting. Tone Control/DC Control Configuration ("State Tables," Etc.) Conventional channel...
Page 197 LBI-39224 COMMAND DEFINITION Set receive frequency to frequency 7. SET RX FREQ 7 SET RX FREQ 8 Set receive frequency to frequency 8. REPEAT ENABLE Enable Repeater. Disable Repeater. REPEAT DISABLE CG ENABLE Enable Channel Guard. CG DISABLE Disable Channel Guard. CG MON ENABLE Enable Channel Guard Monitor (disabled on PTTs).
Page 198: Figure 36 Tone Controlled Station State Table Mapping Dialog Box
LBI-39224 Figure 36 Tone Controlled Station State Table Mapping Dialog Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Tone Controlled Station State Table Mapping (low level configuration) dialog box maps to a state table located on the CI Board for the selected channel.
Page 199 LBI-39224 2175 Hz Hold Tone Level The 2175 Hz hold tone level should be set in accordance with the level required at the conventional base station and line loss between the CEC/IMC and the base station. Each conventional channel can be individually set to the required level.
Page 200 LBI-39224 Close Close Choose button exit Tone Controlled Station State Table Mapping dialog box and return to the Conventional Channel Configuration dialog box. If any changes have been made and not saved, you will be prompted (Write Changes to Disk?) to save exit (Yes), exit without saving (No), or cancel Close command (Cancel) and remain in the Tone Controlled Station State Table Mapping dialog box.
Page 201: Figure 37 Dc Controlled Station State Mapping Dialog Box
LBI-39224 Figure 37 DC Controlled Station State Mapping Dialog Box Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) DC Controlled Station State Table Mapping (low level configuration) dialog box maps to a state table located on the CI Board for the selected channel.
Page 202: Table 9 Dc Controlled Station State Configuration
LBI-39224 State Table The State Table list box contains all of the possible programmable commands for a base station. Select the required commands to program from this list box, the selected command will be displayed in the Selected Command text box. Current State The Current State field displays the control current levels used to control the DC control base station.
Page 203 LBI-39224 CG ENABLE – CG DISABLE -2.5 -2.5 – The columns beneath the DC Control Current heading represent the next state the station must go to implement a new command; for example, if the station is presently at the -11 mA state and receives a DC control current of -2.5 mA, the station will know that this is a command to "SET RX FREQ 1 WITH CG ENABLED"...
Page 204: Logging Recorder Configuration
LBI-39224 (No), or cancel the Close command (Cancel) and remain in the DC Controlled Station State Table Mapping dialog box. 3.15 LOGGING RECORDER CONFIGURATION The Logging Recorder Interface Module (LRIM) interface is used to record audio for selected units, groups and conventional channels. The CEC/IMC supports four (4) LRIM devices, each device supporting up to 64 modules and 32 channels.
Page 205: Lrim Module Configuration
LBI-39224 displayed in this list box. Above this list box is a read-only field which identifies the database source. Read CEC/IMC Choose the Read CEC/IMC button to read the programming database from the selected LRIM. Read Disk Choose the Read Disk button to display the current configuration stored on the CEC/IMC Manager hard disk for the selected LRIM.
Page 206 LBI-39224 The Selected Module text box displays the module number selected in the Logging Recorder Configuration dialog box, this is read-only information. Select the database (unit, group, or conventional) for the entity you wish to program by selecting the appropriate option button at the top of dialog box.
Page 207: Save And Send Lrim Module Configurations
LBI-39224 choosing the Program LRIM button (changed data must be – saved to disk prior to programming). A "No" indicates the module is NOT programmed, a module is "de- programmed" (deleted) by choosing the Delete Mod button in the Logging Recorder Configuration dialog box. If the ID number of the entity to program is known, enter this ID in the Manual ID text box to immediately select that entity without having to scroll through what may be a rather lengthy list in the above drop-down...
Page 208: Edacs Data Gateway (Edg) Configuration
LBI-39224 Send Mod Choose the Send Mod button to send the selected module configurations (more than one module may be selected) to the CEC/IMC MOM. This action will program the selected module. NOTE This function can be very important during software upgrades. Part of the upgrade procedure is to clear NOVRAM on all boards in the CEC/IMC.
Page 209: Centralized Activity Logger (Cal) Configuration
LBI-39224 3.17 CENTRALIZED ACTIVITY LOGGER (CAL) CONFIGURATION The Centralized Activity Logger (CAL) computer uses the call activity information provided by the Centralized Activity Module (CAM) to generate usage and billing information. The CAL is connected to the CAM Controller Board (the CAM consists of this single Controller Board) by a synchronous high-speed HDLC serial control data link.
Page 210: I/O Event Configuration
LBI-39224 Configure System / System Options / Auxiliary I/O to display the Auxiliary I/O Event Configuration dialog box. Figure 40 Auxiliary I/O Event Configuration Dialog Box Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key). 3.18.1 I/O Event Configuration The I/O event is displayed in the drop-down list box along the top of the dialog box.
Page 211 LBI-39224 error/warning triggered outputs are assigned to consoles by use of a console mask. Type (Device) and Assign (Device) Each event is assigned to a specific interface module (device) within the CEC/IMC. The Device Type and Assignment fields uniquely identify the Controller Board to which the I/O equipment will be wired.
Page 212 LBI-39224 for details on the wiring of the I/O ports/bits. Select the event type (Input or Output) from the Event Type drop-down list box. Input Event If Input is selected several other fields are affected and require configuration as described in the following paragraphs. –...
Page 213 LBI-39224 Output Event If Output is selected several other fields are affected and require configuration as described in the following paragraphs. The Activate and Deactivate buttons will be displayed – below the Event Type field, replacing the Console Tone Alarm drop-down list box.
Page 214 LBI-39224 Maestro uses Alt+F1 - Alt+F8 (press and hold the Alt key and then press the F1 - F8 key). The C3 Modular console uses the ALARM 1 - 4 and AUX 1 - 4 keys for the same purpose. Each event can be specified to either deactivate upon release of the key (momentary) or toggle on each subsequent key press (hold).
Page 215 LBI-39224 Warning Trigger A warning trigger will set the output event active on receipt of a warning with the specified group/sub-group at the MOM. Since warnings are never cleared (one-shot event) all warning triggers will require manual deactivation using the CEC/IMC Manager's I/O configuration screen Deactivate button.
Page 216 LBI-39224 prevent overburdening the CEC/IMC Manager's warning system with auxiliary I/O state change warnings. An output event state change will be logged with the following warning: mm/dd/yy hh:mm:ss FF MIM 1 W17-130 Auxiliary I/O - State Change Output 1 Active [Bit 0 High] Trig: E02-22 The output number, active/inactive state, bit value, absolute state (high/low) and trigger description will match the current event's data.
Page 217: Activate Tdm Bus Slots
LBI-39224 data is not successfully broadcast to all required devices a "MOM Communication Error" or "Device not active" notify box will be displayed. The assigned Controller Board (device type and assignment in the I/O definition) must be installed and active for the event definition to operate.
Page 218: Multisite Unit Logout Configuration
LBI-39224 Activate TDM Bus Slots function. From the CEC/IMC Manager menu bar select Configure System / CEC/IMC Configuration / Activate TDM Bus Slots to display the TDM Bus Slots dialog box. This dialog box allows the CEC/IMC Manager user to command the MOM to automatically reset all other Controller Boards in the CEC/IMC.
Page 219: Figure 42 Unit/Group Location And Unit Logout Dialog Box
LBI-39224 Figure 42 Unit/Group Location and Unit Logout Dialog Box Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Close Choose Close button exit Unit/Group Location and Unit Logout dialog box and return to the CEC/IMC Manager main window.
Page 220 LBI-39224 The following terms are used to describe unit logout functions. – Activity: A PTT or Radio Login. – PTT: Push-To-Talk, keying a radio. – Radio Login: Site message generated when units auto login. This can occur when a unit powers up or changes groups/sites and the unit is programmed for auto login capability.
Page 221 LBI-39224 System Options dialog box (Configure System / System Options / Multisite Settings). This does not reset unit timers or change unit timer reset values, so if "Multisite Unit Logout" is selected (enabled) the unit timers will again decrement from the previously set values.
Page 222: Unit Timed Logout Configuration
LBI-39224 – Unit Timers set to No Timeout never log off. This is used for units that show very little activity. – Unit Timers decrement each minute but reset when a unit shows activity. – ACTIVITY is defined as a PTT or radio login. –...
Page 223 LBI-39224 listed in 15-minute increments from 15 minutes to 24 hours, including No Timeout. Manual Entry For timer based unit logout manual entries also can be made. These allow the operator to immediately jump to a unit or group that has a known ID or ALIAS by typing the ID or ALIAS in the appropriate Manual Entry text box instead of scrolling through the list of Aliases.
Page 224: Command Unit Logout
LBI-39224 3.20.2 Command Unit Logout The command logout function allows the operator to logoff a specified unit instantly, without waiting for the inactivity logout. The unit can be selected from the list box or manually entered (see below). This procedure can be repeated for as many units as necessary. Manual Entry Manual entries also can be made for command unit logout.
Page 225 LBI-39224 search parameters for location requests, and the display of "Last Known Location" will be limited by this filter. Manual Entry NOTE The Group and Unit information displayed in their respective fields are not related to each other, the Unit Alias and LID are linked to the list box directly above these fields, the Group Alias and GID are linked to the drop-down list box above and to the right of these fields.
Page 226 LBI-39224 narrower search parameters. Choose the Send Location Request button to execute the specified search. The Unit Locations will be displayed in the list box with their Last Known Location—Group Alias, GID, Site Alias, and (Site) ID. Unit Location by Site When the site is known but the unit is unknown this option can be used to obtain a list of all units on a particular site.
Page 227: Multisite Settings
LBI-39224 Choose the Apply Grp/Site Filter button to initiate the specified search parameters. Choose the Send Location Request button to execute the specified search. The Group Locations (units located) will be displayed in the list box. 3.20.4 Multisite Settings Multisite options Timer Master Enable/Disable, Multisite Monitor, and Multisite Logout Polling are selected from the System Options dialog box;...
Page 228 LBI-39224 Read Disk Choose the Read Disk button to view the current configuration stored at the CEC/IMC Manager hard disk. Read CEC/IMC Choose the Read CEC/IMC button to view the current Multisite configuration at the CEC/IMC. Close Choose the Close button to exit the System Options dialog box and return to the CEC/IMC Manager main window.
Page 229: Wwvb Time Standard Configuration
LBI-39224 devices to disable secondary drops. If the Multisite Channel Monitoring function is disabled, secondary drops will not be put on the GSC bus and the Network Manager will receive simulated secondary drops from the CAL. Enable the Multisite Monitoring function by selecting (checking) the Multisite Monitor check box, unselect the check box to disable this function.
Page 230 LBI-39224 the Backplane. The MOM Controller Board controls clock selection by sending clock select command signals to all other Controller Boards within the CEC/IMC. Each Controller Board then controls the clock select circuitry on its respective Audio Boards. NOTE The redundant clock feature should only be enabled if the CEC/IMC is equipped with Audio Boards 19D903302P1 Rev.
Page 231 LBI-39224 Clock Boards can be installed. Generally, two Clock Boards are installed per CEC/IMC to allow uninterrupted operation when one Clock Board must be removed for servicing. If two Clock Boards are installed and the redundant clock feature is enabled, the toggle switches are normally set at the factory as follows.
Page 232 LBI-39224 basis from the CEC/IMC Manager. The Local CEC/IMC ID is displayed at the top center of the dialog box. Unselect the check box to disable this feature. Help Choose the Help button to access the Help function. (Help is also available by pressing the F1 key.) Save and Send Choose the Save and Send button to save the new Redundant Clock...
Page 233: Prosound Configuration
LBI-39224 If only one Clock Board is installed, turn both clocks ("A" and "B") ON using the panel-mounted toggle switches. If multiple Clock Boards are installed, turn OFF all but one "A" clock and turn OFF all but one "B" clock. Clear the MOM Controller Board's non-volatile RAM (NOVRAM).
Page 234: Figure 43 Prosound-Site Adjacency Configuration Dialog Box
LBI-39224 matrix includes one special site—the "priority system." The priority system is given an extra bit error rate threshold tolerance which favors the priority system during roaming operations. The threshold tolerance is programmed into the radio. ProSound configuration is done from the ProSound–Site Adjacency Configuration dialog box.
Page 235 LBI-39224 Repeat the sequence for all necessary sites. A more detailed description of the fields and configuration process follows. NOTE!! The CEC/IMC ID ("switch assignment number") must be set at the MOM Controller Board before ProSound will operate correctly. The CEC/IMC firmware automatically displays a CEC/IMC ID number even if one is not set at the MOM, so a displayed CEC/IMC ID does not guarantee that the switch assignment number has been set.
Page 236 LBI-39224 Read Disk Choose the Read Disk button to read the currently selected site's ProSound configuration from the CEC/IMC Manager's hard disk drive. This configuration may not be the same as the configuration at the A Read Disk followed by a Send will update the CEC/IMC.
Page 237: Exiting The Program
LBI-39224 configuration is saved at the CEC/IMC Manager server, typically local to the CEC/IMC; it is not saved at a remote client. Save Choose the Save button to save the new ProSound adjacency database information to the CEC/IMC Manger's hard disk drive. Send Choose the Send button to send the new configuration to the site via the CEC/IMC MIM control data link.
Page 238 LBI-39224 This page intentionally blank 3-208...
Page 239: Chapter 4 Monitor System
LBI-39224 4. CHAPTER 4 MONITOR SYSTEM 4.1 SYSTEM MONITORING The CEC/IMC Manager for Windows NT system monitoring capabilities allow the CEC/IMC Manager user to monitor system performance starting from an overall global view all the way down to a board level. The various functions included within system monitoring are Node Data, Feature Data, Diagnostics, and Statistics.
Page 240: Node Matrix
LBI-39224 4.2.1 Node Matrix The Node Matrix screen contains a 16 x 16 matrix of all possible hexadecimal GSC node addresses in the system. Figure 45 CEC/IMC Diagnostics (Node Matrix) Screen Press the F1 key to access the Help function. The available addresses are the range 00h to EFh and FBh, which is the permanent address of the MOM Controller Board.
Page 241 LBI-39224 Show Site Number Select this check box to display the site assignment number of the site- type interface modules as shown above. If this check box is unselected the interface module type (MIM, NIM, etc.,) will be displayed in place of the site assignment number.
Page 242: Board Identification
LBI-39224 4.2.2 Board Identification Selecting (single-click) any of nodes will display the Board Identification dialog box shown below. The information in the upper half of this dialog box—Node ID, Type, Version, Assignment, and Error(s)—is a "snapshot" of the node when selected, it does not update to reflect any changes that may occur while viewing this dialog box.
Page 243 LBI-39224 Node ID This field displays the current hexadecimal GSC address. Type This field displays the interface module type: MIM, MOM, etc. Assignment This field displays the setting of the interface module's Controller Board dip switches (site assignment number). Version This field displays the major and minor version number of the 80C186 software installed in the interface module.
Page 244: Feature Data
Each licensed feature or capacity for a CEC/IMC requires that a license be obtained from Ericsson customer support. Note that the licensed features and capabilities may be different than the maximum capabilities of the CEC/IMC.
Page 245: Licensed Features
Landline Data A customer must have this license in order to install an Ericsson Data Gateway (EDG) product in the CEC/IMC. This license is not required for radio to radio RF Data. This feature is enabled if the check box is selected.
Page 246: Table 11 Licensed Msc Type
LBI-39224 Table 11 Licensed MSC Type License Value MSC Type Description Default value if license is not present, multiple site interface Dispatch Console interface to single trunked site StarGate StarGate controller in StarGate Network Remote CEC Console Only interface, used to remotely connect multiple dispatch consoles to a CEC or IMC Max Sites...
Page 247: Diagnostics
LBI-39224 Max Net Chan This license specifies the number of CEC/IMC TDM Bus slots that are required for NIM devices. Each NIM channel (StarGate or Remote CEC NIM) requires an allocated TDM Bus slot. 4.4 DIAGNOSTICS The Diagnostics function of the CEC/IMC Manager enables the user to generate reports about Errors, current and logged (past), Warnings, Calls Translation, GSC Monitor Data, and GSC Translation on a "global"...
Page 248: Diagnostic Options
LBI-39224 Figure 47 Active Devices Dialog Box 4.4.2 Diagnostic Options Select the report option to view from the Selection field of the Diagnostics dialog box. The options are Errors (option of logged or current, available when Errors is selected), Warnings, Call Translation, GSC Data, and GSC Translation.
Page 249: Figure 48 Diagnostics Dialog Box, Errors Option Selected
LBI-39224 Display Choose the Display button to display the selected report in the Diagnostics dialog box. This information can be sent to a file or to a printer by choosing the Save To File or Print buttons respectively. Save To File Choose the Save To File button to print the entire selected report to a file for later viewing or printing.
Page 250 LBI-39224 location of the error's source. In the case of a global system error, the text "GLOBAL SYSTEM" will be displayed across these 3 columns, since this type of error affects all interface modules (devices/nodes). Global system errors are included in all existing error reports, whether it is a single node, all sites, all consoles, or all nodes report.
Page 251: Figure 49 Diagnostics Dialog Box, Warnings Option Selected
LBI-39224 View Warnings Figure 49 Diagnostics Dialog Box, Warnings Option Selected Each entry in the report consists of two lines of information detailing the time and source of the warning, the related message code number, a short description, a data value, and the source filename and line number where the warning was issued.
Page 252 LBI-39224 The short description following the message code reflects this format. For example: W02-033 "Out of Range-Audio Channel." – All possible warnings are listed by message code number in this dialog box's Help function. In most instances the short description given will provide enough information to indicate the reason for the warning.
Page 253: Figure 50 Diagnostics Dialog Box, Call Translation Option Selected
LBI-39224 Figure 50 Diagnostics Dialog Box, Call Translation Option Selected Information displayed by this on-line option is identical to the information displayed by the off-line CALLS.EXE program described in Chapter 5 of this manual. See Chapter 5 or the on-line Help function for message group and sub-group definitions.
Page 254: Figure 51 Diagnostics Dialog Box, Gsc Data Option Selected
LBI-39224 GSC Data This option is also accessible from the Diagnostics Options menu. It allows the user to view the CEC/IMC Manager datalog information in a raw hexadecimal format. A typical GSC Data screen is shown below. Figure 51 Diagnostics Dialog Box, GSC Data Option Selected Once displayed, this information can also be sent to a file or printed.
Page 255: Figure 52 Diagnostics Dialog Box, Gsc Translation Option Selected
LBI-39224 GSC Translation This option, also accessible from the Diagnostics Options menu, is similar to the GSC Data option except there is an attempt to translate the messages into a more readable format. This is similar to the Call Translation option, except no messages are filtered out. Messages that cannot be translated are left in the raw hex form.
Page 256: Statistics
LBI-39224 To create a GSC Translation report select the GSC Translation option button and enter date and time ranges in the appropriate text box, then choose the Display button to display the datalog file. Since the datalog file may be quite large, it could take several minutes to finish a translation.
Page 257: Figure 54 Hdlc (Channel B) Statistics Dialog Box
LBI-39224 Figure 54 HDLC (Channel B) Statistics Dialog Box Press the F1 key to access the Help function. Clear Data Choose the Clear Data button to reset the data display and allow a refresh of the display. All counts are from the last reset. Close Choose the Close button to exit the HDLC STATISTICS dialog box and return to the Active Devices dialog box.
Page 258 LBI-39224 the System Errors field and is also counted as a single error in each individual interface module error count. Status Indicates whether the current channel is enabled or disabled (HDLC A and B only). If disabled, no communications are possible on the channel.
Page 259: Gsc Node Statistics
LBI-39224 VFR = 0 (invalid frame received) CRC = 0 (CRC check failed) RAB = 1 (received frame was aborted from transmitting station) U_FRMR Tx/Rx A count of U-frame FRMR (frame reject) responses transmitted and received. S_REJ Tx/Rx A count of S-frame REJ commands/responses transmitted and received. T1 Polls A count of polls issued to the remote station due to its failure to acknowledge an I-frame, U-frame command, or polled S-frame...
Page 260: Figure 55 Gsc Node Statistics Dialog Box
LBI-39224 Figure 55 GSC Node Statistics Dialog Box Press the F1 key to access the Help function. Clear Data Choose the Clear Data button to reset the data display and allow a refresh of the display. All counts are from the last reset. Close Choose the Close button to exit the NODE STATISTICS dialog box and return to the Active Devices dialog box.
Page 261 LBI-39224 individual interface module will be greater that the value displayed in the System Errors field. This will occur whenever a global system error currently exists, each global system error is counted as a single error in the System Errors field and is also counted as a single error in each individual interface module error count.
Page 262: Nim Statistics
LBI-39224 4.5.3 NIM Statistics The NIM STATISTICS dialog box displays various NIM data. The data is updated continuously (about once per second) while the screen is displayed. Figure 56 NIM Statistics Dialog Box Press the F1 key to access the Help function. Clear Data Choose the Clear Data button to reset the data display and allow a refresh of the display.
Page 263 LBI-39224 Errors Displays the number of errors currently existing that affect the selected interface module. This count will include errors that affect only the current interface module plus the number of global system errors. In some cases the sum of all the values displayed in this field for each individual interface module will be greater that the value displayed in the System Errors field.
Page 264: Tec (T1/E1 Interface Card) Status And Statistics
LBI-39224 Link State Indicates the current control link state (UP or DOWN) between the selected NIM and any networks NIMs. If the link state is DOWN this field does not indicate at which end of the link the problem exists. 4.5.4 TEC (T1/E1 Interface Card) Status and Statistics The T1/E1 Card Status and Statistics dialog box displays various information about any T1/E1 Interface Cards that may be installed in...
Page 265 LBI-39224 Device Type This field displays the interface module type: MIM, NIM, etc. (currently only MIMs, NIMs, and PIMs can be equipped with T1/E1 Interface Cards). Device Assign This field displays the setting of the interface module Controller Board dip switches (site assignment number). Status Card Number This field indicates which (active) cards within the interface...
Page 266 LBI-39224 Statistics Card Number This field indicates which (active) cards within the interface module the subsequent data fields reference. Each interface module will eventually be able to support up to eight (currently only one) T1/E1 Interface Cards, with only four cards active at any given time (See Cards Active below).
Page 267 LBI-39224 reset. A Framing Error occurs on the T1/E1 Interface Card in response to several different types of data framing errors. Rem Alarms This field indicates the number of Remote Alarms accumulated at the CEC/IMC since the last Clear Stats command or the last TEC reset.
Page 268 LBI-39224 This page intentionally blank 4-30...
Page 269: Chapter 5 Off-Line Diagnostics
LBI-39224 5. CHAPTER 5 OFF-LINE DIAGNOSTICS 5.1 OFF-LINE DIAGNOSTIC FUNCTIONS ® The CEC/IMC Manager (MOM PC) has two off-line MS-DOS utilities to extract data from the data log buffer stored on the hard disk. CALLS.EXE Used to extract all calls made within the CEC/IMC GSCMON.EXE Used to extract all messages from the log...
Page 270 LBI-39224 Calls - extract channel assignment/drop data from data log buffer Syntax: calls [<options>] Options: /bhh:mm:ss start time of data extraction /ehh:mm:ss stop time of data extraction /dmm-dd-yy date of data log file soft copy output requested display help file then exit The output from the CALLS function displays the time of the assignment/drop, accurate to 480 msec, the TDM bus and slot the call is/was on, the channel the host used to process the call, the host (site or...
Page 271 LBI-39224 AVGTT System All Call VG, Tx trunked AVGMTU System All Call VG Update, msg trunked AVGTTU System All Call VG Update, Tx trunked Indiv Inter (CTIS) CTIVG Indiv Inter (CTIS) VG Group Inter (CTIS) CGGVG Group Inter (CTIS) VG ECTG Emergency Group Inter (CTIS) ECTGVG...
Page 272: Gscmon.exe
LBI-39224 A sample output of the CALLS function using the following command line will look like: calls /d09-12-91 /b14:00:00 /e15:00:00 /s MSG SUB CALL TIME BUS SLOT CHN HOST GROUP GROUP CALLEE CALLER 14:12:01.44 0 CHN ASS CNV 1 IND 45 14:12:01.44 0 CHN DRP DROP...
Page 273 LBI-39224 /dmm-dd-yy date of data log file soft copy output requested suppress node active messages display help file then exit The output from the GSCMON function displays the time of the message and the message contents. The interface module (node) ids seen at the hardware GSC monitor are not output.
Page 274 LBI-39224 gscmon /d12-30-92 /b09:10:00 /e09:11:00 /n TIME DATA 09:10:01.44 66 01 02 17 01 01 0E 31 03 02 00 3A 06 01 00 09:10:03.36 66 05 00 15 01 01 02 31 03 02 00 1E 06 01 00 09:10:04.80 66 05 00 17 01 01 02 31 03 02 00 1E 06 01 00 09:10:07.20...
Page 275: Chapter 6 Netclock/2™ Interface Option
LBI-39224 6. CHAPTER 6 NETCLOCK/2™ INTERFACE OPTION 6.1 OVERVIEW A Coordinated Universal Time (UTC) standard option is available that allows the CEC/IMC to be synchronized to WWVB, operating on a frequency of 60 kHz, in Fort Collins, Colorado. This option uses ®...
Page 276: Netclock Installation
LBI-39224 Figure 58 NETCLOCK/2 Configuration Using the RS-232 serial connection, the CEC/IMC Manager reads the 26-character ASCII time/date data from the receiver and updates the MOM Controller Board. The MOM then provides synchronized time and date messages to the CIMs and consoles. 6.2 NETCLOCK INSTALLATION The following procedures must be performed in order to implement the NETCLOCK/2 time synchronization option:...
Page 277: Hardware Installation Notes
LBI-39224 Connect the NETCLOCK/2 to an unused CEC/IMC Manager COM port. See the cable wiring diagrams that follow. The NETCLOCK/2 has two RS-232 serial ports. One is an output that transmits the 26-character ASCII time/date data once each second in Format 0 or Format 1.
Page 278: Figure 59 Netclock/2 T-Cmd Interconnections
LBI-39224 CEC/IMC NETCLOCK/2 MANAGER SERIAL COMM COMM PORT PORT (DB-9 MALE) (DB-9 FEMALE) 9-Pin CEC/IMC Manager COM Port CEC/IMC NETCLOCK/2 MANAGER SERIAL COMM PORT COMM PORT (DB-9 MALE) (DB-25 FEMALE) 25-Pin CEC/IMC Manager COM Port Figure 59 NETCLOCK/2 T-CMD Interconnections 1/sec (REMOTE OUTPUT) Interconnections The 1/sec (REMOTE OUTPUT) requires a 9-pin male connector at the NETCLOCK/2.
Page 279: Software Installation Notes
LBI-39224 CEC/IMC NETCLOCK/2 MANAGER REMOTE OUTPUT COMM PORT PORT TDATA (N.C.) (DB-9 MALE) (DB-9 FEMALE) 9-Pin CEC/IMC Manager COM Port CEC/IMC NETCLOCK/2 MANAGER REMOTE OUTPUT PORT COMM PORT TDATA (N.C.) (DB-9 MALE) (DB-25 FEMALE) 25-Pin CEC/IMC Manager COM Port Figure 60 NETCLOCK/2 Remote Output Connections 6.2.2 Software Installation Notes The NETCLOCK/2 interface is integrated into the Microsoft Windows NT operating system.
Page 280: Installation Verification
LBI-39224 – Time Zone Switches – Baud Rate Switches – Antenna Installation 6.3 INSTALLATION VERIFICATION Before connecting the NETCLOCK/2 to the CEC/IMC Manager, the operator should verify the status of the three LED indicators on the front panel. All three should be illuminated green. A red "ANTENNA"...
Page 281 LBI-39224 7. APPENDIXES 7.1 APPENDIX A - LOGGED ERROR DEFINITIONS LOGGED LOGGED CAUSE/ ERROR ERROR CORRECTIVE MESSAGE DATA ACTION E00-xxx: An error has been generated within UNKNOWN ERROR the CEC/IMC, but the CEC/IMC Manager cannot determine what it is. This is usually a result of a Controller Board residing in the system with firmware prior to version 2.00 or with a firmware...
Page 282 LBI-39224 LOGGED LOGGED CAUSE/ ERROR ERROR CORRECTIVE MESSAGE DATA ACTION E01-020: Lower byte is the An Audio Board has detected a HW FAIL - CLOCK clock which failed: failed clock circuit. If three (3) of BANK 00h = A clock, 01h = these errors are generated by three B clock.
Page 283 LBI-39224 LOGGED LOGGED CAUSE/ ERROR ERROR CORRECTIVE MESSAGE DATA ACTION E02-022: Lower byte contains No poll response is being received, BUS FAIL - GSC BUS the bus number that via the GSC bus, from a Controller failed, either 0 or 1 Board set up to be an end node.
Page 284 LBI-39224 LOGGED LOGGED CAUSE/ ERROR ERROR CORRECTIVE MESSAGE DATA ACTION E03-028: 0000h = CIM control Control data link failure between LINK FAIL - data link failure. CIM and console. CONSOLE 0001h Attached console is "Logged Out" or "Disabled." For a C3 Desktop/ Modular console, 0001h indicates the...
Page 285 LBI-39224 LOGGED LOGGED CAUSE/ ERROR ERROR CORRECTIVE MESSAGE DATA ACTION E05-021: INCOMPATIBLE - AUDIO BUS E05-023: INCOMPATIBLE - CEC/IMC MANAGER E06-116: information A Controller Board was installed INVALID VALUE - contained in the data that conflicted with an existing ASSIGNMENT word.
Page 286 LBI-39224 LOGGED LOGGED CAUSE/ ERROR ERROR CORRECTIVE MESSAGE DATA ACTION E08-18: No information in the Controller Board device DEVICE CONFLICT - data word. type/assignment setting CONTROL BOARD conflicting with another board's setting. For example a VMIM 5 and a MIM 5 will conflict with each other.
Page 287 LBI-39224 LOGGED LOGGED CAUSE/ ERROR ERROR CORRECTIVE MESSAGE DATA ACTION E11-143: None This invalid feature data system ENCRYPTION FAIL - error is issued if no license data is LICENSE DATA BAD available. Starting with Group 12, CEC/IMC Software will require licenses to specify the operational features and maximum capacities for a CEC/IMC Node.
Page 288 LBI-39224 LOGGED LOGGED CAUSE/ ERROR ERROR CORRECTIVE MESSAGE DATA ACTION E11-146: Abbreviated name of The feature license has expired. ENCRYPTION FAIL - license that has The licensed feature will not LICENSE EXPIRED expired: actually be disabled until the "FS Patch" - Failsoft CEC/IMC Manager for Windows Patch NT is restarted.
Page 289 LBI-39224 7.2 APPENDIX B - LOGGED WARNING DEFINITIONS LOGGED LOGGED CAUSE/ WARNING WARNING CORRECTIVE MESSAGE DATA ACTION W00-xxx: (none) A warning has been generated UNKNOWN within the CEC/IMC, but the WARNING CEC/IMC Manager cannot determine what it is. This is usually a result of a Controller Board residing in the system with firmware prior to version 2.00 or...
Page 290 LBI-39224 LOGGED LOGGED CAUSE/ WARNING WARNING CORRECTIVE MESSAGE DATA ACTION W02-050: Value of sum count Current summed audio list has the OUT OF RANGE - when the attempt was maximum number AUDIO SUM COUNT made to add another channels allowed and an attempt channel.
Page 291 LBI-39224 LOGGED LOGGED CAUSE/ WARNING WARNING CORRECTIVE MESSAGE DATA ACTION W03-066: Message ID value that Unsupported message ID from a UNSUPPORTED ID - generated CIM, MIM, NIM, LRIM or MOM. PATCH/ warning. SIMULSELECT W03-067: Message ID value that During a System Manager database UNSUPPORTED ID - generated upload, an unsupported CIM or...
Page 292 LBI-39224 LOGGED LOGGED CAUSE/ WARNING WARNING CORRECTIVE MESSAGE DATA ACTION W06-033: Logical ID (LID) of The CEC/IMC has received a MISMATCH - AUDIO unit that channel assignment for a unit that CHANNEL experienced marked active another missed channel drop. channel. This is a missed channel drop condition –...
Page 293 LBI-39224 LOGGED LOGGED CAUSE/ WARNING WARNING CORRECTIVE MESSAGE DATA ACTION W07-120: (none) A new error message has been OVERFLOW - MOM received, but the MOM error status ERROR ARRAY array is full. The status of the new error will not be stored. W08-084: Message group value Unsupported...
Page 294 LBI-39224 LOGGED LOGGED CAUSE/ WARNING WARNING CORRECTIVE MESSAGE DATA ACTION "Queued" Call was queued at secondary site(s). "Sys Busy" Call received System Busy at secondary site. "Denied" Call was denied at secondary site. "Inv Chan" Call received an invalid channel assignment.
Page 295 LBI-39224 LOGGED LOGGED CAUSE/ WARNING WARNING CORRECTIVE MESSAGE DATA ACTION "CIC Denied" The encrypted Jessica/CTIS call warning and the caller was denied at the landline callee of interface. failed confirmed call. "CTIM Duplex" A "call back" was not received warning and the caller from the landline interface for callee of the encrypted Jessica/CTIS call.
Page 296 LBI-39224 LOGGED LOGGED CAUSE/ WARNING WARNING CORRECTIVE MESSAGE DATA ACTION W10-114: Channel number that The NIM (StarGate systems) has TIMEOUT - SAFETY was cleared. received no activity on an active TIMER channel for approximately ten (10) minutes. The NIM will clear the channel at this point and issue this warning.
Page 297 LBI-39224 LOGGED LOGGED CAUSE/ WARNING WARNING CORRECTIVE MESSAGE DATA ACTION W15-144: Data field contains The attempted action was denied UNAVAILABLE - Logical ID (in hex) of because the system was in Failsoft FAILSOFT PATCH console that operation and the Failsoft Patch attempted to perform feature was not enabled.
Page 298 LBI-39224 LOGGED LOGGED CAUSE/ WARNING WARNING CORRECTIVE MESSAGE DATA ACTION Notes for W18-xxx warnings: Controller Boards with firmware versions prior to 2.12 do not log these warnings. For Controller Boards with firmware versions 2.12 or greater but less than 3.00, W18-132 will be logged for changes in device type, version number, and date/time stamp.
Page 299 LBI-39224 LOGGED LOGGED CAUSE/ WARNING WARNING CORRECTIVE MESSAGE DATA ACTION W20-136: Channel number in A conventional channel definition CONV CHAN - conflict. has been received from a remote CONFLICT CEC/IMC that falls within the local CEC/IMC conventional channel range. Each CEC/IMC has a unique conventional channel range assignment sixty-four...
Page 300 LBI-39224 LOGGED LOGGED CAUSE/ WARNING WARNING CORRECTIVE MESSAGE DATA ACTION W24-147: Abbreviated name of Pending License expiration LICENSED FEATURE license that has warnings are issued for any license - EXPIRES expired: that will expire within 30 days. "FS Patch" - Failsoft The licensed feature will not Patch actually be disabled until the...
Page 301 REG_SZ. Choose OK to add this value. The program will then ask for a string in the text box provided, enter EXACTLY: SOFTWARE\Ericsson\EDACS\CurrentVersion Choose OK. The resulting string in the right-hand side of the screen should like:...
Page 302 Ericsson, and leave the Class field blank. Choose OK. – Click on the Ericsson entry so that it is highlighted. Select Edit from the menu bar and Add Key from the drop-down menu. For Key Name enter EDACS, and leave the Class field blank.
Page 303 LBI-39224 7.4 APPENDIX D - FONT SELECTABLE DIALOG BOXES Console Channel Configuration dialog box – Text in scroll boxes DVIM Channel Configuration dialog box – Text in scroll boxes C3 Modular/Desktop Console Configuration dialog box – Text in scroll boxes Site Channel Configuration List dialog box –...
Page 304 LBI-39224 This page intentionally blank...
Page 305: Appendix E - Popup Message Box Definitions
LBI-39224 7.5 APPENDIX E - POPUP MESSAGE BOX DEFINITIONS The CEC/IMC Manager server (GUI_SERVER.exe) is not available. This may be only a momentary condition and choosing Retry may begin the client program (W_GUI.exe). The name "mom_lab1" is a fictitious name, the name displayed will be the actual name of the machine (computer) running the CEC/IMC Manager server or a TCP/IP address of the form XXX.XXX.XXX.XXX.
Page 306 LBI-39224 One or more required files could not be located when attempting to execute the client program. In the example shown above the DLL file "MFC40.DLL" could not be found in the specified path C:\…, where "C" is the drive where the client program is installed and "…" would be replaced by the remaining path name for the client program.
Page 307 LBI-39224 In systems with a System Manager running V5.0 software, the Unit ID (LID) and Console Alias fields may be edited. The Unit ID values entered in these fields must be valid LIDs (existing at the System Manager), identified as consoles at the System Manager, and be downloaded to the CEC/IMC Manager.
Page 308 LBI-39224 The Delete button has been chosen in one of the Console Configuration dialog boxes, this pop-up box is prompting confirmation of the decision to delete the currently selected Console configuration database. T1/E1 selection is performed at the CEC/IMC Manager on a CEC/IMC wide basis.
Page 309 LBI-39224 A Send of an unconfigured and inactive (** prefix) interface module was attempted from the Site Channel Configuration List dialog box. Site "4" is a "filler" site number, the actual site number displayed will be the corresponding "site assignment number" of the interface module selected in the "Active/Configured Sites:"...
Page 310 LBI-39224 When the CEC/IMC MOM Controller Board CEC/IMC Manager communication link is established, the CEC/IMC Manager compares the disk stored Slot assignments with the MOM Controller Board NOVRAM Slot assignments. If that comparison fails, this error will be displayed. The Node ID (if displayed) refers to the CEC/IMC "switch assignment number."...
Page 311 LBI-39224 The information saved was successfully saved to the CEC/IMC Manager hard disk. The T1/E1 database was successfully downloaded (sent) from the CEC/IMC Manager to the CEC/IMC MOM Controller Board. Configuration data was successfully sent from the CEC/IMC Manager and to the CEC/IMC MOM Controller Board. Any audio configuration changes will be sent to the appropriate interface module Controller Board.
Page 312 LBI-39224 This page intentionally blank...
Page 313: Glossary
LBI-39224 Glossary of Terms Aegis Aegis is Ericsson's digital voice audio system that employs advanced Digital Signal Processing (DSP) circuitry. Aegis has two primary modes – "Aegis digital" and "Aegis private." Aegis digital mode offers improved weak signal performance and impedance to unauthorized monitoring when compared to standard analog (clear) voice transmissions.
Page 314 LBI-39224 Call Director patch The Call Director patch feature allows the dispatcher at a console to "patch" a telephone line to a specific unit, talk group, conventional channel, or radio patch in the CEC/IMC network. The term patch or patched, derived from phone patch, is used to signify the CD is connected to the CEC/IMC.
Page 315 The CEC/IMC Manager (formerly referred to as the "MOM PC") provides CEC/IMC monitoring and configuration functions. This IBM PC compatible computer running custom software developed by Ericsson is the window into the CEC/IMC for the system administrator and service technicians. CI Board Conventional Interface Board –...
Page 316 LBI-39224 control data Control data includes any data used for system control. Controller Board The Controller Board processes control data, holds databases, and controls the Audio Boards within its respective interface module. CTIM Centralized Telephone Interconnect Module – The CTIM is a CEC/IMC interface module used to connect Centralized Telephone Interconnect System (CTIS) equipment to the CEC/IMC so radio users and dispatchers can access land-line telephone systems.
Page 317 LBI-39224 EDACS Enhanced Digital Access Communication System – The term "EDACS radio system" refers to RF equipment that may be interfaced to the EDACS CEC/IMC Digital Audio Switch. The RF equipment may be located at a single location, such as an EDACS trunked site or it may be located at several locations, such as in a voting system.
Page 318 LBI-39224 GETC Ericsson General Electric Trunking Card – The GETC is a microprocessor-controlled shelf that can be configured to perform many different signal processing tasks for EDACS radio communications equipment. In CEC/IMC applications, each GETC is equipped with a 9600 baud modem that provides serial control data communications between different radio systems.
Page 319 CEC/IMC equipment to provide EDACS radio system users access to local public switched telephone networks (PSTN). Jessica incorporates the Ericsson MD110 PBX. It is interfaced to the CEC/IMC via a PIM. (Also see PIM.) LRIM Logging Recorder Interface Module –...
Page 320 LBI-39224 Network Interface Module – Two or more IMC networks can be linked together for distributed multisite communications using a NIM at each IMC Digital Audio Switch. NIMs can also link a remote CEC to an IMC for remote console applications. NOVRAM NOnVolatile Random Access Memory –...
Page 321 Request Status Monitor – The RSM is an IBM PC compatible computer running custom software developed by Ericsson. It allows the system administrator and/or the dispatchers to view status of EDACS units within the CEC/IMC network. Status information is typically initiated (transmitted) by the radio operator to identify the current condition (in route, at scene, etc.) of the unit.
Page 322 LBI-39224 site This term normally refers to radio equipment at a single specific location. (Also see site assignment number.) site assignment number In most cases, the term "site" in this program does not refer to an EDACS trunked site or any other type of radio system. It refers to a site-type interface module...
Page 323 LBI-39224 VMIM ConVentional MASTR II/III Interface Module – The VMIM couples the CIA secondary interface rack to the primary CEC/IMC interface modules. The VMIM - CIA set allows conventional base stations and conventional satellite receiver voting systems to be connected to the CEC/IMC.
Page 324 LBI-39224 This page intentionally blank G-12...
Page 325: Index
LBI-39224 read and delete I/O event Index save and send I/O event access level change 3-8 baud rate create 3-5 CEC/IMC Manager - MOM default 3-3 3-11 System Administrator 3-3 serial control link (NIM) 3- adjacency System Manager - MOM 3- ProSound 3-204, 3-207 ALC 3-30, 3-32, 3-136 bit error rate 3-204...
Page 326 LBI-39224 Conventional Interface (CI) audio board configuration 3-145, 3-155, 3-168, 3- , 3-110 3-105 CIM selection save and send audio board board identification 4-3, 4-5 3-110 configuration client GSC 3-198 remote 2-3 3-39 TDM 3-19, 3-31, , 5-2 single 2-3 activate slots 3-187 assign slots 3-19, 3-31, 3- Clock Board 3-199...
Page 327 LBI-39224 save and send high-level Digital Voice Interface Module configuration 3-164 (DVIM) 3-132 StarGate Network 3-145 DVIM StarGate Network channel configuration 3-135 allocation 3-146 Confirmed Call 3-102 StarGate Network channel save and send configuration programming 3-148 3-138 StarGate Network remote selection 3-133 channel logged warnings 3-151...
Page 328 LBI-39224 module configuration 3-175 save and send module password configuration 3-177 change 3-8 create 3-5, 3-7 default 3-2, 3-3 patch audio board configuration soft 3-130, 3-152 audio interface type selection 3-26 audio board configuration 3-23 MIM selection save and send audio board audio interface type selection 3-33 configuration...
Page 329 LBI-39224 3-40 console user profile TDM bus 3-19, , 3-187 considerations 3-114 activate 3-187 conventional channel allocating considerations 3-151, 3- console interface module 3-110 database transfers 3-14, 3-17 multinode considerations 3- DVIM 3-137 general 3-19 site-type interface T1 transmission system 3-27 module 3-31 3-40 TDM time 3-19,...
Page 330 XLTR 3-127 VMIM audio board configuration save and send audio board 3-89 configuration 3-83 VMIM selection W_GUI.exe 1-1, 2-3 WINMOM 1-1, C-2 Ericsson Inc. Private Radio Systems Mountain View Road Lynchburg, Virginia 24502 1-800-528-7711 (Outside USA, 804-528-7711) Printed in U.S.A.

Ericsson LBI-39224 Operation Manual

Introduction

APPENDIX C - SNMP AGENT and PROXY for CEC/IMC (Optional)

Chapter 1 Getting Started

About Cec/IMC Manager V5.0

About this Manual

Data Logging Feature

Chapter 2 Installation

Unpacking

Cec/IMC Manager Requirements

Diskette Handling

Making Backups

Multiple Remote Clients

Upgrade Cec/IMC Manager

System Hook-Up

Chapter 3 Operation and Configuration

Starting the Program

User Account Configuration

Cec/IMC Manager Font Selection

Appendix D - Font Selectable Dialog Boxes

Initial Cec/IMC Manager and Mom Controller Board Configuration

System Time and Date

System Manager Database Uploads

Site-Type Interface Module Channel

Confirmed Call

Telephone Interconnect

Console Configuration

Digital Voice Channel Configuration

Distributed Multisite / Stargate Configuration

Conventional Channel Configuration

Appendix B - Logged Warning Definitions

Logging Recorder Configuration

Edacs Data Gateway (Edg) Configuration

Centralized Activity Logger (Cal) Configuration

Auxiliary I/O Configuration

Activate Tdm Bus Slots

Multisite Unit Logout Configuration

Wwvb Time Standard Configuration

Redundant Clock

Prosound Configuration

Exiting the Program

Node Data

Chapter 4 Monitor System

System Monitoring

Feature Data

Diagnostics

Statistics

Chapter 5 Off-Line Diagnostics

Off-Line Diagnostic Functions

Chapter 6 Netclock/2™ Interface Option

Overview

Netclock Installation

Installation Verification

Appendix E - Popup Message Box Definitions

Glossary

Index

Quick Links

Related Manuals for Ericsson LBI-39224

Summary of Contents for Ericsson LBI-39224
