- Page 1 Users’ Guide: WLN1500UG001 Enfora® Wi-Fi® Adapter for Treo 600/650 Smartphone Users’ Guide Revision 1.00...
-
Page 2: Copyright Statement
Further, Enfora Inc. reserves the right to revise this publication, and to make changes from time to time in the contents hereof without obligation of Enfora Inc. to notify any person of such revision or changes. -
Page 3: Table Of Contents
OFTWARE NSTALLATION NSTALLING THE MARTPHONE INTO THE ® W EMOVING THE NFORA ETWORK AND ATTERY TATUS CONFIGURING YOUR ENFORA® WI-FI® ADAPTER ... 9 ADDITIONAL INFORMATION... 13 ... 13 ETWORK NFORMATION ADVANCED CONFIGURATION... 14 ... 14 OWER ESTORE EFAULT SETTINGS SOFTWARE LICENSE AGREEMENT... 15 LIMITED WARRANTY... -
Page 4: Safety Information For Wireless Handheld Devices
2. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. (This does not apply to the antenna that is part of the Treo 600/650.) The Federal Communications Commission (FCC) with its action in ET Docket 96-8 has adopted a safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC certified equipment. - Page 5 DISPOSE OF BATTERIES ACCORDING TO THE INSTRUCTIONS. Use the following or equivalent certified Power Supply. Make: PHIHONG, Model PSA11R-050 Rated Input: 100-240Vac, 0.5A, 50-60hz, DC Output: 5V DC, 2.0A Limited Power Source. WLN1501/WLN1502 Wi-Fi Adapter Page 2 Copyright, 2005 Enfora, Inc.
-
Page 6: General Safety Instructions
Check if all peripherals are properly connected before turning on any equipment. • Make sure to disconnect the power plug from the power source before installing or removing the Enfora® Wi-Fi® Adapter. • Always hold the product with dry hands. Droplets of water may cause it to short circuit and damage to the product. -
Page 7: Package Contents
The following contents are included in the WLN1501 – Wi-Fi® Adapter for Treo 600: Description Enfora® Wi-Fi® Adapter for Treo Smartphone Install CD-ROM AC/DC Power Supply The following contents are included in the WLN1502 – Wi-Fi® Adapter for Treo 650: Description Enfora®... -
Page 8: Appearance
Appearance The following images show the Enfora® Wi-Fi® Adapter for the Treo 600/650 Smartphone. Enfora Wi-Fi Adapter DC Power Input WLN1501/WLN1502 Wi-Fi Adapter Copyright, 2005 Enfora, Inc. Lock Release Button Treo Smartphone Headphone Jack Lock/Release Button Treo Smartphone Headphone Jack... -
Page 9: Hardware And Software Information
Hardware and Software Information Battery Operation Prior to using the Enfora® Wi-Fi® Adapter, charge the new battery for a minimum of 2 hours to obtain a full charge. The Enfora® Wi-Fi® Adapter derives its power from a self-contained battery pack to ensure there is no battery drain on the handheld device. -
Page 10: Installing The Treo Smartphone Into The Enfora® Wi-Fi® Adapter
4. With the Treo positioned at about a 5º to 10º from the inner surface of the Enfora® Wi-Fi® Adapter; push the Treo, gently down, onto the mating connector of the Enfora® Wi-Fi® Adapter. You will hear/feel a click as the Enfora® Wi- Fi® Adapter connector is seated into the Treo. -
Page 11: Removing The Enfora® Wi-Fi® Adapter From The Treo 600/650
Removing the Enfora® Wi-Fi® Adapter from the Treo 600/650 1. Hold the Enfora® Wi-Fi® Adapter upright. 2. Grasp the edges of the Treo with one hand and grasp the edges of the Enfora® Wi-Fi® Adapter with your other hand. 3. With the index finger of the hand holding the Enfora® Wi-Fi® Adapter, depress the Release Button. -
Page 12: Configuring Your Enfora® Wi-Fi® Adapter
2. Select the Enfora® Wi-Fi® icon from applications on your Treo 600/650 handheld. 3. The first time you use the Enfora® Wi-Fi® Adapter you will need to configure it. If you know your Network Name (SSID) select Add and continue to Step 6. If you do not know the Network Name (SSID) select Scan to search for any available Access Points/Wi-Fi®... - Page 13 Network Name. The Network Name that you selected form the Scan list will appear in the Network Name field. Click OK and proceed to the next step. WLN1501/WLN1502 Wi-Fi Adapter Copyright, 2005 Enfora, Inc. Create Profile Profile and Network Name...
- Page 14 Wi-Fi® Network you plan to connect to. If your network does not require a Network Name you can leave Any as the Network Name. 8. The Enfora® supported Network Mode is Infrastructure. You must connect the Wi-Fi ® Adapter to an Access Point. Ad-hoc mode is not supported.
- Page 15 11. Select OK from the Profile Settings window to return to the main Manager window. 12. In the Manager window check the status of the Enfora® Wi-Fi® Adapter. When the status displays Associated you can click on Connect to enable a Wireless connection.
-
Page 16: Additional Information
Additional Information Network Information To find out your Network Settings click on the preference button. Then select Network Information. 1. The Network Information available is listed below: WLN1501/WLN1502 Wi-Fi Adapter Copyright, 2005 Enfora, Inc. Page 13... -
Page 17: Advanced Configuration
Advanced Configuration Power Save The Enfora® Wi-Fi® Adapter has a Power Save setting. By default the Power Save option is Enabled. To disable Power Save open the Enfora® Wi-Fi® Adapter Manager and select Device Information from the Options menu. From the Device Information window select the drop down box to Enable or Disable the Power Save option. -
Page 18: Software License Agreement
Software, its documentation and all copies and derivatives thereof, regardless of the form or media, are held by Enfora or its licensors, as applicable. No other right or license is granted to you except the limited right to use the Software and its documentation as provided in this Agreement. - Page 19 This Agreement (and the accompanying Limited Warranty) set forth the entire agreement between you and Enfora, supersedes all prior agreements, whether written or oral, with respect to the Software, and may be amended only in a writing signed by both parties.
-
Page 20: Limited Warranty
Purchaser shall bear the risk of loss or damage in transit to any product returned by purchaser to Enfora, or any returned product not found to be defective or covered under this warranty and reshipped by Enfora to purchaser. -
Page 21: Other Considerations
(iii) caused by use of any software other than any software supplied by Enfora, or by use of the product other than in accordance with its documentation or (iv) the result of electrostatic discharge, electrical surge, fire, flood or similar causes. - Page 22 Enfora and the distributor or reseller, if any, from whom purchaser purchased the product. That agreement may provide, for example, a different product return procedure that may also be available to purchaser (e.g., the product may be returned to Enfora through that distributor or reseller).
