BMP-001
Quick Installation Guide
Package Contents
1. Media Box main unit 2. Remote control
3. QIG 4. AV cable 5. Power adapter
Main interface and functions
Power interface: DC 5V/1.5A
Main functions:
1. Multimedia player (VIDEO/ AUDIO/ PHOTO)
2. Calendar 3. Alarm clock
Input interface:
1. IR receiver 2. USB2.0 port
3. 4in1card reader (SD, MMC, MS(Pro), XD)
Output interface
1.Video interface : RCA composite video jack,
Component video jack (Y Pr/Cr Pb/Cb), VGA port
2. Audio interface : RCA audio jack(L&R), Earphone jack
Power interface
1. Power Jack 2. Power switch 3. Power LED indicator
Notice: The Media Box supports FAT32 file system for first logic
partition
Remote control keys and operations
Key
Function
Description
UP/DOWN/
Direction keys
Move the highlight square cursor
LEFT/RIGHT
ENTER
Selection key
Execute the selected function
RETURN
Return key
Go to previous layer
Switch USB/Card or switch
MENU
Control key
control bar
YCbCr
YCbCr output
Switch output to Y Pr/Cr Pb/Cb
Video
Video output
Switch output to RCA composite
VGA
VGA output
Switch output to VGA
Main menu
While connect the power adapter, audio cable(RCA L&R),
video cable(RCA composite or
Y Pr/Cr Pb/Cb
insert USB/Card, then power on, select proper output, then
main menu will show on the screen, you can use remote
control to operate this system. Media Box will detect
whether the USB drive or memory card is inserted on this
device and
on the top right corner of the screen.
indicate
1.PHOTO
Enter PHOTO to view images in the USB drive/memory
card, this device supports JPEG/BMP/GIF formats.
After entering PHOTO, system will list all images in
selected drive, you can browse all directories in this drive.
or VGA), and
ENTER
RETURN
UP/DOWN
LEFT
RIGHT
MENU
Select
Goto previous layer
Move cursor
Switch to music/slide show
Thumbnail mode
Switch USB/Card
