MONARCH INSTRUMENT
Instruction Manual
Phasar-Tach
Phasar-Tach-R
Portable Tachometers
15 Columbia Drive
Amherst, NH 03031-2334 USA
Phone: (603) 883-3390
© Monarch Instrument 2002 all rights reserved
Fax: (603) 886-3300
E-mail: support@monarchinstrument.com
1071-4860-122
Website: www.monarchinstrument.com
Advertisement
Table of Contents
Summary of Contents for MONARCH INSTRUMENT Phasar-Tach
- Page 1 MONARCH INSTRUMENT Instruction Manual Phasar-Tach Phasar-Tach-R Portable Tachometers 15 Columbia Drive Amherst, NH 03031-2334 USA Phone: (603) 883-3390 © Monarch Instrument 2002 all rights reserved Fax: (603) 886-3300 E-mail: support@monarchinstrument.com 1071-4860-122 Website: www.monarchinstrument.com...
-
Page 2: Limited Warranty
For technical OR OTHER THEORY OF LIABILITY. assistance, contact the sales organization from which you purchased the product or Monarch Instrument This limited warranty does not extend or apply to consumables (including, but not limited to, lamps and directly. -
Page 3: Table Of Contents
Division of Monarch International Inc. OPERATION ................. 2 15 Columbia Drive, Amherst NH 03031 USA USING THE PHASAR-TACH WITH A REMOTE OPTICAL declares under Monarch’s sole responsibility that the product: SENSOR (ROS-5P) ............... 3 Name: Hand Held Tachometer CALIBRATION AND SELF-TEST .......... 3... -
Page 4: Specifications
SPECIFICATIONS OPTIONS AND ACCESSORIES This product is designed for indoor or outdoor use under the following ROS-5P* Remote Optical Sensor with 8 foot [2.4 m] cable and conditions (per IEC1010-1): mounting bracket Speed Range: 5 RPM to 100,000 RPM EC-25P 25 foot [7.6 m] extension cable for remote sensors with Accuracy: ±... -
Page 5: Overview
BATTERIES Humidity: Maximum relative humidity 80% for temperature up to 88 °F [31 °C] decreasing linearly to 50% The Tachometer operates from four ‘AA’ size batteries which are located relative humidity at 104 °F [40 °C] under the hinged top of the instrument. To access these batteries, grip the Dimensions (LxWxH):6.13”... -
Page 6: Using The Phasar-Tach With A Remote Optical
For longer duration measurements, the trigger latch on the side of the pistol Remote Optical Sensor can be used for measurements. The ROS-5P operates grip handle can be depressed after pulling the trigger, and the instrument 3 feet [0.9 m] and ±45° from the reflective tape. may be mounted on the 1/4-20 threaded bushing at the base of the handle.
