User Guide:

GSM0110UG001

Enfora GSM0110

Compact Flash Card

Users Guide

Revision 1.01

Table of Contents

Need help?

Do you have a question about the GSM0110UG001 and is the answer not in the manual?

Questions and answers

Summary of Contents for Enfora GSM0110UG001

Page 1 User Guide: GSM0110UG001 Enfora GSM0110 Compact Flash Card Users Guide Revision 1.01...
Page 2: Disclaimer
Further, Enfora Inc. reserves the right to revise this publication, and to make changes from time to time in the contents hereof without obligation of Enfora Inc. to notify any person of such revision or changes.
Page 3: Fcc Compliance Statement
CAUTION Changes or modifications without the express consent of Enfora, Inc. voids the user’s authority to use the equipment and will avoid any applicable warranty. This equipment has been tested and found to comply with the limits pursuant to Part 15 Subpart B , Part 22 and Part 24 of the FCC rules.
Page 4: Safety Instructions
Safety Instructions • Use of radio equipment is prohibited in hospitals and may interfere with the use of medical equipment. Do NOT use the GSM0110 Compact Flash Card in hospitals. • FCC regulations prohibit using your wireless device during any air flight. Switch OFF your Compact Flash Card prior to flight and in accordance with the airline’s acceptable devices policy.
Page 5: General Safety Instructions
General Safety Instructions • Check if all peripherals are properly connected before turning on any equipment. • Make sure to disconnect the power plug from the power source before installing or removing peripherals. • Always hold the product with dry hands. Droplets of water may cause it to short circuit and damage to the product.
Page 6: Table Of Contents
Running pocket PhoneTools ..................12 pocket PhoneTools Functions ..................14 Creating a GPRS Connection..................17 Mobile PhoneTools – Using the Enfora CF Card on Your Laptop ....... 22 Installing mobile PhoneTools..................22 Manual Modem Installation..................30 Button Definitions ....................... 31 Display Definitions ......................
Page 7: Overview
Overview Welcome! Thank you for purchasing the GSM0110 Compact Flash Card! Welcome to the world of wireless data. Your GSM0110 Compact Flash Card is a compact, wireless data modem that uses the GPRS (General Packet Radio Services) wireless communication system, allowing you to transfer data on the go. Wireless IP (Internet Protocol) supports browser-based applications, giving you feature rich capability with the Internet in your hand.
Page 8: Package Contents
Revision History Date Author Description 8/24/05 1.00 C. French Initial Release 09/08/06 1.01 D. O’Neil Removed reference to optional battery Package Contents Check the contents of the package. The following items should be included. If there is any item that is damaged or missing, please contact your dealer immediately. Description Quantity The GSM0110 Compact Flash Card...
Page 9: Appearance
Appearance The GSM0110 Compact Flash Card On/Off Button Holder Antenna: Connector Shown in operating position Headset Jack Status GSM0110UG001 Page 3...
Page 10: Network Status (Link) Led Description
Network Status (Link) LED Description Color LED Status Connection Status Green Continuous Blinking Searching for Network Green Single Blink Connected to GSM Network Green Double Blink Transmitting/Receiving Data Single Blink New SMS received Single Blink – One short blink very 6 seconds Double Blink –...
Page 11: Installing The Cf Card Into The Pda
To remove the SIM Card: Gently lift up on the notched corner side of the SIM. Push the SIM out of the holder. Installing the CF Card into the PDA To install into a PDA: 1. Locate the Compact Flash slot on your PDA. Note: If your PDA has a PCMCIA slot, insert the CF card into the PCMCIA adaptor (included) before inserting the CF card into the PDA.
Page 12: System Requirements
To remove from the Laptop: Follow your laptop and operating system instructions for the steps required to remove a PCMCIA device. Note: Some operating systems may require you to stop certain services, such as the PCMCIA service, prior to physically removing the CF card. System Requirements Check your hardware and software to see if they satisfy the requirements below.
Page 13: Pocket Phonetools
Pocket PhoneTools Installing pocket PhoneTools for Pocket PC The software for pocket PhoneTools is located on the CD-ROM labeled BVRP pocket PhoneTools. Note: Install your CF card into the PDA anytime prior to running Pocket PhoneTools. You may receive a notification window from the Pocket PC informing you that there are no connections created for this device.
Page 14 5. Select your Install Language. 6. The pocket PhoneTools Install Wizard will appear. 7. Select Next to continue. 8. Read the License Agreement. Select Yes if you agree with the terms of the license agreement. 9. Specify a destination folder for pocket PhoneTools or accept the default folder. GSM0110UG001 Page 8...
Page 15 10. Select Next. 11. Setup will now install the software. Select Cancel if you wish to stop the installation process. 12. pocket PhoneTools will connect with your PDA and then copy the files to your PDA. GSM0110UG001 Page 9...
Page 16 13. Select Yes to install the BVRP Software pocket PhoneTools to the default directory. 14. The install progress will be displayed on the PC screen. 15. When the installation is complete you will be prompted to check your PDA. Check to see if there are any additional steps to be performed on your PDA to complete the installation.
Page 17 GSM0110UG001 Page 11...
Page 18: Running Pocket Phonetools
Running pocket PhoneTools Note: Install your CF card now, if you have not done so already. 1. Select pocket PhoneTools icon from the 2. You will need to configure your Network Programs window. Operator. Select Yes to configure your Network Operator. 3.
Page 19 6. The main pocket PhoneTools menu will 5. Select Yes to save your settings. appear. Note: To create an Internet Connection see the section entitled Creating a GPRS Connection. GSM0110UG001 Page 13...
Page 20: Pocket Phonetools Functions
pocket PhoneTools Functions Inbox Items Outbox Items Sent Messages Phonebook Sort Items Messages Displayed Create SMS Retrieve SMS Add phonebook entry Internet Connection Hide Toolbar Dialer Menu GSM0110UG001 Page 14...
Page 21 Dialer Menu Selecting the Dialer Icon from the main menu will launch the Dialer. To have the Dialer load when pocket PhoneTools starts select Tools>Settings>Dialer and Select On when loaded. GSM0110UG001 Page 15...
Page 22 Battery Status of Place a Call End a Call Connections Status Clear Number Speaker On/Off Microphone On/Off Volume control Contacts Main Contact List Phone Logs GSM0110UG001 Page 16...
Page 23: Creating A Gprs Connection
Creating a GPRS Connection Note: Selecting any Internet (Globe) Icon inside of pocket PhoneTools will launch the Internet Connection Wizard if no connection already exists. To create a new GPRS connection on your PDA, follow these steps: 1. In the pocket PhoneTools Taskbar 2.
Page 24 7. Select GPRS connection. If you are using 6. Select any of the listed applications to the default APN leave Use Standard Settings run once a connection is made. Select checked and proceed to step 13. If you are Next. using a unique APN or Static IP or DNS, uncheck Use Standard settings.
Page 25 8. The default APN for the carrier will Configure your IP information based on be listed. Check the drop down box for the information provided by your carrier. any other available APN’s. If you have Select Next. a different APN from your carrier enter it into the text field.
Page 26 13. Select No. Check with your network operator 12. Select Next. to see if they support CSD calls. Note: CSD calls may incur additional charges with your carrier. See the FAQ section for more information on CSD calls. 14. Select OK to return to the General 15.
Page 27 16. Select the Globe Icon to start your 17. Connection status will be Internet Connection. displayed in the Task Bar. Start / Stop Internet Connection GSM0110UG001 Page 21...
Page 28: Mobile Phonetools - Using The Enfora Cf Card On Your Laptop
PhoneTools software (not your Operating System). Installing mobile PhoneTools In order to use the Enfora CF Card to make a GPRS connection, you will use mobile PhoneTools, which is provided on the CD that came with your Enfora CF Card.
Page 29 3. Click on mobile PhoneTools Software Installation. 4. Click on the Language Version of mobile PhoneTools that you need. 5. You will see the following InstallShield Wizard screen: 6. Click on Next to continue. GSM0110UG001 Page 23...
Page 30 7. You will see the following License Agreement screen: 8. Click on Yes to continue. You will see the following screen: 9. Click on the radio button marked Complete. 10. Click on Next to continue. You will see the following Setup Status screen: GSM0110UG001 Page 24...
Page 31 11. Once the installation is complete, you will see the following screen which prompts you to configure a Persistent Connection. GSM0110UG001 Page 25...
Page 32 The Persistent Connection Features are: 1) Start mobile PhoneTools on boot, and 2) Automatic Internet Connection (connection automatically reconnects if dropped). During this step of the setup process you can choose whether or not you would like to install Persistent Connection Features. If you do not choose to install Persistent Connection Features, proceed to Step Do not check the above checkmark box if you do not want to install Persistent Connection Features.
Page 33 To disable or enable the above features after installation, click on the menu from mobile PhoneTools, then click on Settings, then the Miscellaneous Tab. 14. Select the Persistent Connection Feature(s) you would like to enable. 15. Click Next to continue. You will see the following screen: GSM0110UG001 Page 27...
Page 34 If you did not install Persistent Connection Features double-click on the mobile PhoneTools icon on your desktop and proceed to Step 18. 18. Next, you will see the Installing PCMCIA Card screen. Insert the Enfora CF Card into your laptop now.
Page 35 20. You are now ready to begin using your Enfora CF Card. GSM0110UG001 Page 29...
Page 36: Manual Modem Installation
Manual Modem Installation The following instructions apply if you choose not to use mobile PhoneTools. This option will only install the modem driver and INF file. 1. Insert CD into the CD-ROM. 2. Select exit if the automatic installation program launches. 3.
Page 37: Button Definitions
Button Definitions Information Help Minimize Program Close Program Show / Hide Dialpad Start / Stop Internet Connection Send SMS message Access Phonebook Access E-mail Display Definitions Globe not used Roaming indicator Signal Strength New message Indicator Error indicator Current Carrier GSM0110UG001 Page 31...
Page 38: Mobile Phonetools Internet Connection Wizard
mobile PhoneTools Internet Connection Wizard: There are two ways to create an Internet connection: 1. Select the Globe Icon within mobile PhoneTools. The Internet Connection Wizard will automatically start if there are no existing Internet connections defined. 2. Use the Menu > Setup > Internet connections option. Then, activate Add new Connection.
Page 39 Use Default Network Customize Network Settings Settings GSM0110UG001 Page 33...
Page 40 GSM0110UG001 Page 34...
Page 41: Troubleshooting
Troubleshooting If you have any questions regarding installation, set up, or operation of the GSM0110 CF Card, please contact the vendor or distributor from whom you purchased the card, or your wireless network carrier. http://www.enfora.com GSM0110UG001 Page 35...
Page 42: Limited Warranty
LIMITED WARRANTY Scope Enfora warrants to the original purchaser of the product that, for a period of one (1) year from the date of product purchase, the product hardware, when used in conjunction with any associated software (including any firmware and applications) supplied by Enfora, will be free from defects in material or workmanship under normal operation.
Page 43 (iii) caused by use of any software other than any software supplied by Enfora, or by use of the product other than in accordance with its documentation or (iv) the result of electrostatic discharge, electrical surge, fire, flood or similar causes.
Page 44 Governing Law This limited warranty shall be governed by the laws of the State of Texas, United States of America, without regard to conflict of laws principles. This limited warranty shall not be governed in any respect by the United Nations Convention on Contracts for the International Sale of Goods.
