Summary of Contents for EarthQuake iQuake IQ-52B MKII
- Page 1 Portable Media Device Player MKII Series User’s Manual Models: IQ-52W (white) IQ-52B (black) IQ-52S (silver) IQ-52R (red) IQ-52P (pink) Earthquake Sound Corp. | (510) 732-1000 | U.S. Toll Free: (800) 576-7944 www.earthquakesound.com...
-
Page 2: Table Of Contents
© 2010 Earthquake Sound Corporation. All rights reserved. This document should not be construed as a commitment on the part of Earthquake Sound Corporation. The information is subject to change without notice. Earthquake Sound Corporation assumes no responsibility for errors that may appear within this document. -
Page 3: Safety Instructions
Safety Instructions Safety First This documentation contains general safety, installation, and operating instructions for the iQuake-52 MKII Series. It is important to read this user’s manual before attempting to use this product. Pay particular attention to the safety instructions. Symbols Explained: Appears on the component to indicate the presence of uninsulated, dangerous voltage inside the... - Page 4 To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. Earthquake Sound Corp. | (510) 732-1000 | www.earthquakesound.com...
-
Page 5: Unpacking System Components
• Keep all power cords away from all signal cables to prevent humming from induced noise. • Choose reliable signal cable cords (Earthquake Sound also specializes in high performance RCA cables and patches). • All speaker wires that are ran through the walls should be twisted type to reduce potential hum noise pick-up. -
Page 6: What Your Iq-52 Comes With
MDF and unique interior reinforcement designed to absorb vibration and impact generated under extreme conditions. The exterior of the enclosure is finished with multi-layers of glossy lacquer paint. (white, black, silver, red, or pink) Note: *Charges most iPods® Earthquake Sound Corp. | (510) 732-1000 | www.earthquakesound.com... -
Page 7: Rear Panel Features
Rear Panel Features Input Mode: iPod®, RCA, AUX mode select button. USB: To sync your iPod® with your computer. S-Video: A standard 4-pin S-Video cable connector. RCA Input: Used to connect signals from unbalance, -10dBv devices. The white connector is for the Left input and the red connector is for the Right input. -
Page 8: Amplifier Overview
This is virtually any usually used for folks room of your who live in countries house. other than the US. Earthquake Sound Corp. | (510) 732-1000 | www.earthquakesound.com... -
Page 9: Remote Control Features
IQ-52 Remote Control Features BACK LIGHT: Press to turn on iPod back light for 30 seconds MUTE: Press to change between mute and mute off. REPEAT: Press to change iPod repeat status as follows: repeat off repeat one track repeat all track repeat off. VOL UP: Press “... -
Page 10: Installation And Precautions
Before connecting power, please make sure that the On/Off switch to the off position. Use of improper Voltage may result in hazardous conditions and/or damage to speaker components not covered by speaker warranty. Earthquake Sound Corp. | (510) 732-1000 | www.earthquakesound.com... -
Page 11: Connection Info
Speaker Wire Connections Use 3 meter 1/4” TS to 1/4” TS speaker cable included in the IQ-52 package to connect the left and right speakers via the 1/4” TS jacks on the back of each speaker. Connecting to a Computer Sound Card or Other Audio Output Device Before connecting the IQ-52 Powered Speaker System, make sure the power from the computer or other output device has been turned off and the IQ-52 system is also turned off. -
Page 12: Compatible Products
Answer: The Video Processor in the IQ-52 system may not play all devices with video capabilities. Question: Why is the remote control not working? Answer: The remote control has a plastic tab protecting the battery. Simply pull the plastic tab off. Earthquake Sound Corp. | (510) 732-1000 | www.earthquakesound.com... -
Page 13: Specifications
Specfications Type: Two-way Powered Speaker System LF Driver: Woofer: 5-1/4" Magnetically Shielded Carbon Fiber Cone HF Driver: Tweeter: 1" Magnetically Shielded Natural Silk Dome Frequency Response: 45Hz-22 kHz Crossover Frequency: 3.0 kHz S/N Ratio: >95dB (typical, A-weighted) Power: 200 Watts Input Impedance: 10K Ohms Unbalanced Polarity:... -
Page 14: Warranty Information
Customer will be charged a minimum of one (1) hour of labor (ongoing rates) plus shipping charges back to customer. (C) Earthquake agrees to repair or replace - at our option - all such defective products/parts subject to the following provisions: Defective products/parts have not been altered or repaired by other than an Earthquake factory approved technician. -
Page 15: Mccone Avenue Hayward, Ca
Subsequent damage to other products. A warranty claim will not be valid if the warranty registration card is not properly filled & returned to Earthquake with a copy of the sales invoice. (E) Service Request: To receive product/s service, contact Earthquake service department at... - Page 16 Sound That Will Move You Earthquake Sound reserves the right to amend details of the specifications without notice. Copyright © Earthquake Sound Corporation Earthquake Sound Corporation • 2727 McCone Avenue Hayward CA, 94545 Phone: 510-732-1000 Fax: 510-732-1095...
