DIGITAL THEATER SYSTEMS, INC.
Digital Sound For Movies
DTS-6 /-6D System Testing
And

Troubleshooting

August 1999
Digital Theater Systems, Inc.
5171 Clareton Drive
DTS SA, UK
Agoura Hills, CA 91301 USA
Telephone: 44 (0) 118 934 9199
Telephone (818) 706-3525
Fax: 44 (0) 118 934 9198
Fax (818) 706-1868
Email cinematech@dtsonline.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTS-6 and is the answer not in the manual?

Questions and answers

Summary of Contents for DTS DTS-6

  • Page 1: Troubleshooting

    DIGITAL THEATER SYSTEMS, INC. Digital Sound For Movies DTS-6 /-6D System Testing Troubleshooting August 1999 Digital Theater Systems, Inc. 5171 Clareton Drive DTS SA, UK Agoura Hills, CA 91301 USA Telephone: 44 (0) 118 934 9199 Telephone (818) 706-3525 Fax: 44 (0) 118 934 9198 Fax (818) 706-1868 Email cinematech@dtsonline.com...
  • Page 2: Table Of Contents

    SCSI Blinking Timecode Reader LED (Troubleshooting Guide) ………………………. 26 – 28 Timecode Signal Drawing ………………………………………………………………………28 DTS-6 35mm / 70mm System Parts List ……………………………………….. 29 DTS-6D 35mm / 70mm System Parts List ……………………………………… 30 Replacement Parts List ( ) ………………………………………………. 31 DTS-6/ -6D How To Contact DTS ……………………………………………………………...
  • Page 3 (delay) on the DTS player. OFFSET Insert the Setup Disc into the DTS player. You may use either the RevC or DS1 Setup Disc. The player should easily accept the DTS disc. Once the DTS player boots up, it should automatically switch the cinema processor to the correct format and tone/pink noise should be heard in the theater.
  • Page 4: Dts System Test

    Turn off the subwoofer speaker and look at the pattern on the RTA (real time . On a DTS-6D, you’ll see a dramatic roll-off at 80Hz (on a DTS-6, its less of a roll-off). It is analyzer) normal to hear DTS subwoofer, above 80Hz, in the surrounds.
  • Page 5 The DTS-6 system can default to either “A” type (04) or “SR” (05). This is determined by jumper settings on external DTS logic boards.
  • Page 6: 70Mm Failsafe Test

    DTS 70mm Fail-safe Test NOTE: If using one DTS-6D unit, there is no fail-safe or fall-back available on this type of system. If using two DTS-6D units, verify connections to the fail-safe board. See installation manual. There are no magnetic sound tracks on DTS 70mm prints.
  • Page 7: Dts Test Discs (History)

    DTS TEST DISCS Below is a list of all the test discs released by DTS. Some of these test discs are obsolete and should no longer be used. In most cases, the discs are obsolete due to software changes that made them incompatible with current DTS players.
  • Page 8: Dts Empirical Test Disc

    TIMECODE HEAD OFFSET current offset setting before your selection is made and restore the setting for proper DTS movie playback. NOTE: *Some of these test signals may cause serious damage to sound systems that are not properly designed to reproduce the extended dynamic range of a digitally-based sound storage system.
  • Page 9 If not on, verify only theatrical discs are in the player. Use only one movie title and trailer disc at a time. • If not on, verify the movie discs match the movie playing. Turn DTS player power off, wait 3 seconds, and power on the DTS player. This must be done when changing movie/trailer discs.
  • Page 10 If only one reel blinks, ask distributor for replacement reel. • If the reader blinks every other reel and is in a platter house, turn off the DTS player. Take the unit out of the rack and open the lid. Look inside, at the timecode card (one with s).
  • Page 11 4. Channel(s) are mixed together or coming out of the wrong speakers. Force the DTS player to play in optical sound format by selecting either 04 or 05 and powering off DTS player. If channel(s) still wrong, not a DTS player problem. Are all amps powered on? Are they correctly wired? If the problem goes away, then play movie in optical until there is time to troubleshoot.
  • Page 12 DTS-6 to an UltraStereo, be sure pin 18 is cut away on the DTS audio board. If not cut, it will cause the left surround and mono surround outputs to be tied together, lowering left surround’s output and rolling off its high end when the DTS-6 player is set for split surround.
  • Page 13 • If a substitute cable was made for the installation (not made by DTS) verify the cable is shielded and that one end of the shield is earth grounded. Do not route DTS audio cables next to power lines, florescent light, or projector motors.
  • Page 14 Monitor signal and turn the DTS level pot. If no change is seen, the pot is bad. Replace player. • Is the signal level the same with the DTS disconnected from CP? If signal increases, something after DTS is padding down the signal.
  • Page 15 17. Volume too loud / soft. If the overall volume is too loud/soft: Adjust fader pot on CP. Do not adjust DTS player trim pots behind front panel. If sound level not balanced between analog and digital, verify B-chain alignment.
  • Page 16 Verify wiring of DTS Timecode “Y” cable. Carefully inspect any cable reworked to pass through conduit or not made by DTS. On the projector side of the 9-pin cable, note that Pin 1 for Proj. 1 comes from Pin 1 DTS player. Pin 1 for Proj. 2 comes from Pin 2 DTS player.
  • Page 17 DTS-6 /-6D UNIT TROUBLESHOOTING When making any repairs to the DTS player, be sure to update the TCR firmware (U14 on the D422 board). DRIVE PROBLEMS Noisy operation The drive motors on in-service older DTS-6D players are at the end of their useful life. Replace the drive.
  • Page 18 NOTE: On DTS ROM-DOS players with SCSI board, the RevE is located at U12 on the DTS D422 board. FUTURE DOMAIN ROM-DOS If the DTS player uses SCSI board, U12 is not used. Instead,...
  • Page 19: Replacing Teac Cd-Rom Drives

    Replacing CD-ROM Drives We have used only two manufacturers of drives, Toshiba and TEAC. Do not substitute with any CD-ROM other manufacturer. Only drives approved by DTS will work. Toshiba / Future Domain SCSI and the “ chip ROM-DOS” When replacing drives with ones made by Toshiba, be sure to use the current “...
  • Page 20 Install the Acqutec ROM and Adaptec SCSI boards. These boards must be used. See the “DTS- 6D” diagram for board orientation. It will be the same for the DTS-6 or DTS-6D. Use the saved screw from the old SCSI board and a new #4 screw to mount both boards to player’s chassis.
  • Page 21: 16X Teac

    DTS-6(D) TEAC CD-ROM Jumper Settings 16X TEAC 2 3 4 5 6 7 DRIVE “A” P R S W DRIVE “B” T E R M + 5 V + 1 2 V 2 3 4 5 6 7 *See note DRIVE “C”...
  • Page 26: Blinking Timecode Reader Led (Troubleshooting Guide)

    D422-U14 inside player, card with 4 LEDs Bad/Poor Timecode On 35mm film, the DTS timecode track is located between the picture and the analog sound track. On 70mm film, its located outside the perfs. The 35mm timecode track should start 4 perfs after the sync pop.
  • Page 27 DTS chassis are earth grounded. The current reader cables (from the DTS factory) have a shield wire shrink-wrapped to the cable’s jacket, on the reader end. Cut the shrink-wrap away and connect the wire to one of the screws that hold the reader to its bracket.
  • Page 29: Dts-6 35Mm / 70Mm System Parts List

    D435-09 Timecode Y cable, 40 ft. / 50 ft. D435-10 Timecode Y cable, 60 ft. / 60 ft. D427-00 Subwoof relay board (used only with DTS-6 units # 1000 - 0001) D475 Index switch assembly 2800-0200-01 Fuse, 2 amp (plug-in)
  • Page 30: Dts-6D 35Mm / 70Mm System Parts List

    Interface cable, D567 to Dolby CP200, CP100, CP50 (DTS-6D interface) 2/board D714 Interface cable, DTS-6D to Smart Mod 5, 2C, SR33, SR55, DM6 D706 Interface cable, DTS-6D to Smart Mod 6 2501-0001-00 Power cord, straight, detachable, standard bare-ended available, call DTS...
  • Page 31: Replacement Parts List ( Dts-6/ -6D )

    Replacement Parts List Replacement Parts common to both the DTS-6 and DTS-6D 6303-0001-00 CD-ROM drive cleaning disc 2201-SW0D-02 Power supply module 5108-0019-00 Adaptec SCSI Board 5108-0020-00 Acqutek ( ) Board 9050-0TCR-00 Firmware ( ) IC, in D422-U14 9050-AQRM-04 Firmware IC, in...
  • Page 32: How To Contact Dts

    Business hours are from 8:30am until 5:30pm PDT. After hours, an automated answering service will take your call and a DTS engineer will be paged to help you. Be sure to leave a clear message and include the entire telephone number where you can be reached.
