- Page 1 DICKSON Temperature Chart Recorder Operation Contents: Product Applications and Useful Features Product Specifications Charts & Accessories Calibrations Operating Instructions / Getting Started Troubleshooting Warranty / Factory Service & Returns Rev. 06/03...
-
Page 2: Product Applications
Product Applications The SC3 sets a new standard for compact recorders while providing the accuracy and resolution required for regulatory compliance and quality control. The reusable SC3 is rugged enough to withstand the rigors of transportation and storage applications. Best of all, its unbeatable low price makes temperature recording affordable for virtually any application. -
Page 3: Product Specifications
Product Specifications Temperature Sensor: Precise spiral wound bi-metallic strip transducer Recorder Accuracy: ±4˚F (±2.5˚C) over full scale Ambient Operating Temperature: -22 to +122˚F (-30 to +50˚C) Response Time: 11 minutes to move 63% of full scale in air moving 5’ per second Temperature Ranges: (˚F or ˚C depending on chart installed) -14 to +32˚F (-25 to 0˚C), +4 to +50˚F (-15 to +10˚C), +22 to +68˚F (-5 to +20˚C),... - Page 4 Charts °F and °C Switchable 7 Day 7 Day 24 Hour 24 Hour Range °F Chart °C Chart °F Chart °C Chart -14 to +32°F / -20 to 0°C C302 C310 C301 C309 +4 to +50°F / -15 to +20°C C304 C312 C303...
- Page 5 Calibration Services - New Units N100 - NIST Traceable Calibration 1-Point: Includes documentation to one Dickson pre-selected point on new units only. N300 - NIST Traceable Calibration 3-Point: Includes documentation of three Dickson pre-selected points (a high, medium, and low) on new units only. N400 - Deluxe A2LA Accredited NIST Traceable Calibration 3-Point: ISO Guide 25/A2LA Docu- mentation of 3 pre-selected points of as found data before and after calibration for Dickson temperature and/or humidity instrumentation on new units only.
-
Page 6: Getting Started
Getting Started • Place chart on recorder • Set time by inserting a coin into chart hub and turning clockwise until the current hour is referenced to the time index clip. (Time index clip is directly to the right and below the pen tip). •... -
Page 7: Troubleshooting
Troubleshooting Pen Tension If the pen is not touching the paper, remove red pen and push the metal pen arm down near the middle of the arm. If that does not work unscrew the pen arm from the recorder and bend the pen arm down. Make sure the unit is in a stable environment, replace the pen arm at the same spot from where it was removed. -
Page 8: Warranty
Warranty Dickson warrants that the products it sells will be free from defects in material and workmanship under normal use and service for a period of twelve months after delivery. In the event of a claim under this warranty, the product or part must be returned to the factory for repair or replacement (shipping pre-paid) with a Return Authorization Number (see Return Information above).
