- Page 1 CRYSTAL-MM-HP PC/104 Format SoundBlaster Pro Compatible High-Power Stereo Audio Module User Manual V2.0 © Copyright 2007 Diamond Systems Corporation 1255 Terra Bella Ave Mountain View, CA 94043 Tel (650) 810-2500 Fax (650) 810-2525 techinfo@diamondsystems.com www.diamondsystems.com...
-
Page 2: Table Of Contents
J9: Base Address / Interrupt Level / DMA Level Configuration..............8 J10: Speaker Volume Control Configuration..................... 8 J11: 3.5mm Stereo Jack Configuration Header ..................9 INSTALLATION SPECIFICATIONS Input and Output Specifications ......................11 General Specifications ..........................11 CRYSTAL-MM-HP User Manual v2.0 September 2007 Diamond Systems Corporation... -
Page 3: Features And Specifications
Built-in stereo audio power amplifier Built-in dual PC game port Manual and/or software volume control Hardware volume up/down/mute controls Windows 95, Windows 98, and Windows NT driver and application software included CRYSTAL-MM-HP User Manual v2.0 September 2007 Diamond Systems Corporation... -
Page 4: Board Diagram
Address / Interrupt / DMA configuration Volume control selection Stereo jack configuration PC dual gameport connector Alternate PC speaker / Mono I/O connector (not installed) Provides 24VDC power to audio amplifier (optional) DC/DC CRYSTAL-MM-HP User Manual v2.0 September 2007 Diamond Systems Corporation... -
Page 5: I/O Header And Jack Pinouts
This header provides connections to all the most commonly used I/O signals on Crystal-MM-HP. The notations next to the various analog ground pins shows the preferred / conventional connections for those signals. CRYSTAL-MM-HP User Manual v2.0 September 2007 Diamond Systems Corporation... -
Page 6: J8 And J13: Mono And Pc Speaker Input/Output, Standard 1X6-Pin Right-Angle Header
J11 located immediately to the left of these jacks. J12: Game port and MIDI I/O SW A SW C Ground MIDI Out Ground SW D SW B MIDI In CRYSTAL-MM-HP User Manual v2.0 September 2007 Diamond Systems Corporation... -
Page 7: Hardware Configuration
If a stereo microphone is used, then either the left or right channel can be used, but not both. For Line In configuration, Tip = Left, Ring = Right, and Shield = Common. CRYSTAL-MM-HP User Manual v2.0 September 2007 Diamond Systems Corporation... -
Page 8: J9: Base Address / Interrupt Level / Dma Level Configuration
J9: Base Address / Interrupt Level / DMA Level Configuration Select one configuration from the upper 3 choices AND one configuration from the lower 2 choices. J10: Speaker Volume Control Configuration CRYSTAL-MM-HP User Manual v2.0 September 2007 Diamond Systems Corporation... -
Page 9: J11: 3.5Mm Stereo Jack Configuration Header
J11: 3.5mm Stereo Jack Configuration Header CRYSTAL-MM-HP User Manual v2.0 September 2007 Diamond Systems Corporation... -
Page 10: Installation
Also remember that since this board is plug and play, the CPU BIOS must support plug and play operations. On some systems, the plug and play features must be enabled in the BIOS setup screens that are accessed at boot time. CRYSTAL-MM-HP User Manual v2.0 September 2007 Diamond Systems Corporation... -
Page 11: Specifications
PC/104 format: 3.55” x 3.775” L x W PC/104 Bus: 8 bit J1 header standard, 16-bit J2 header optional (order –B16 version) Temperature: -20 to 70 C operating +5VDC ±5% from PC/104 bus Power supply: CRYSTAL-MM-HP User Manual v2.0 September 2007 Diamond Systems Corporation...
