Summary of Contents for Curtis VR245
-
Page 2: Table Of Contents
Contents Contents…………………………………………………………………………………………………1 Function Description: ………………………………………………………………………………….2 Notice for use…………...………………………………………………………………………………2 System requirements…………………………………………………………………………………..4 Start to use………………………………………………………………………………………………5 1. Appearance and Buttons………………………………………….……………………5 2. Basic operation…………………………………………………………………….……7 Application of Attached ArcSoft VideoImpression…………………………………………………14 Introduction interface for software installation…………………………………………………….14 Xvid codec Installation………………………………………………………………………………15 MediaImpression Installation and Use……………………………………………………………..17 Product specifications……………………………………………………………………………..…23 Standard accessories………………………………………………………………………………...24... -
Page 3: Function Description
Function Description Welcome to purchase and use this digital video camera. Before use, please read this user manual carefully. With this digital video camera, you can take video clips and still photo. With the playback function, you can playback the taken video with this digital video camera; in addition, you can download the video from the digital video camera into your PC. - Page 4 5. These memory cards cannot be used for permanent storage of data. You must copy the documents in the digital video camera in the proper storage position. 6. When storing documents into the memory or the memory card, make sure that the size of the documents does not exceed the capacity of the memory.
-
Page 5: System Requirements
System requirements When operating and using this digital video camera, be sure to meet the requirements on the basic system for computer. It is strongly recommended to use the best computer units to operate the camera so as to bring its functions into full play. Below are the requirements on the basic system: Operation System Microsoft Windows 2000,XP, vista, Windows7... -
Page 6: Start To Use
Start to use 1. Appearance and Buttons Up key Shutter/OK Delete key Mode key Left key Right key Down key... - Page 7 USB Connector Lens USB Switch TV Out Port Busy LED Microphone Power Key Speaker SD/MMC HDMI Out Port Card Slot Battery Cover Tripod Strap Holder...
-
Page 8: Basic Operation
2. Basic operation 2.1 Install battery Press / slide down the Battery Cover and insert lithium battery. Align with correct polarity of battery terminals. Close the Battery Cover. 2.2 Charge Battery 1. Power off the camera. 2. Connect the camera to the computer USB port or the power adapter (not include) with USB cable to charge the battery. - Page 9 camera. Push and release inserted card if you wish to remove or replace the card. Turn your camcorder OFF before inserting / removing the SD Card. - Note that the SD Card has a tiny LOCK switch on the side. Set the switch to un-LOCK position to be able to store recorded videos, still pictures on inserted SD Memory Card.
- Page 10 press the up key or down key to adjust the value. at this mode, you can view the Firmware version too. 2.6 Change mode After power on, it will enter video record mode, press MODE key to change mode between video record, Still photo record, Playback; 2.7 Video record In Video record mode, press shutter key to start video recording, While recording, press the shutter key again to stop recording.
- Page 11 Note: While the memory is full or the SD card was locked, when you press the Shutter key, the camera will can not recording. Before inert or remove the card, please turn off the camera first. 2.9 Playback videos or photos Press mode key continuously to change playback mode, press ◄...
- Page 12 2.10 V output After the camera is powered on, insert the terminal of the TV cable into the TV output port of the camera, the yellow port of the other terminal should be connected to VIDEO IN port of TV， red(or white) port of the other terminal should be connected to AUDIO IN port of TV.
- Page 13 3 Delete files When in preview or playback mode. Press the Delete key will enter Delete menu mode, use direction key of Up or Down to select “Delete current” or “Delete all” . Select “Delete current” then press OK key will delete current image;...
- Page 14 ▲ Open USB port ▲Connect camera to PC (1) Connect camera to PC (2) ▲...
-
Page 15: Application Of Attached Arcsoft Videoimpression
Application of Attached ArcSoft MediaImpression There are two software in CD provided for image processing: Xvid codec, MediaImpression Introduction interface for software installation Put the CD attached into the CD-ROM of the computer, then the following menu will occur: If the CD driver does not automatically carry out or close such function, please click autorun.exe... -
Page 16: Xvid Codec Installation
program under the root directory of the CD. Xvid codec Installation Instal Xvid codec: Click ” Install Xvid codec “ button and complete the installation as per the tips. -
Page 18: Mediaimpression Installation And Use
Notice: This software can be find in attached CD, If you want to play recorded video on your computer, please install Xvid codec, if your computer have install Xvide codec, this operation may do not it. MediaImpression Installation and Use: Install Mediainpression: Click “Install MediaImpression”... - Page 20 After installation, please restart the computer. Run MediaImpression : Double click the icon on the desktop or follow “Start → Programs” to open: MediaImpression After starting MediaImpression, click the “Import” to import the media.
- Page 21 Choose the video camera storage and choose the output location. Choose require file and click the import, selected file will be stored in the output location.
- Page 22 Click “Go to start page” to return the main screen, click the “Video” or “All media” to use the “You Tube” function.
- Page 23 Choose file and click the “upload to You Tube. Enter you username and password to login the You Tube, execute upload.
-
Page 24: Product Specifications
Product specifications: Image sensor 1.3 Mega Pixels Function mode Record video, Record still photo, playback, mobile disk, Lens F2.8, f=3.1mm Focus range 120cm~infinite Digital focusing 4× Shutter Electronic LCD display 2.0 inch TFT Display Video: HD(1280x720), D1(720x480), VGA(640x480) Resolution Still photo: 3.1M(2048X1536), 1.3M(1280x960), VGA(640x480) White balance Automatic... -
Page 25: Standard Accessories
Standard accessories: Installation CD User manual USB extension cable TV cable Hand Strap Carrying Pouch...
