Simplicity 1687237 Installation Instructions

Installation
Instructions
Kit Contents:
Ref Part No. Qty.
1 1732322 1
2 2825094 2
3 1733415 1
Figure 1. Contents
This kit adds an optional headlight to
snowthrowers equipped with an stator coil.
WARNING
Before beginning any service work turn off the
engine, remove the key, and wait for all
movement to stop. Wait for hot surfaces like the
muffler and cylinder head to cool.
M A N U F A C T U R I N G , I N C .
500 N Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA
Description
Headlight Assembly
Wire Ties
Bracket, Clamp
Oval Headlight Kit
For Fits Intermediate, Pro, and Large Frame Snowthrowers
INSTALLATION
1. Models with tube handle bars: Mount the headlight to
the handle bars using the clamp provided.
Models with channel handle bars: Mount the head-
light assembly directly to the handle bars using an
available hole in the channel assembly.
2. Check that the light does not interfere with the opera-
tion of the controls, or control linkage. If it does, relo-
cate it.
3. Route the wire leads to the engine.
4. Connect the bullet lead to the engine's stator coil out-
put.
5. Connect the eyelet connector to the foot of the
engine block, secure to one of the engine mounting
bolts.
6. Secure the wires, using the wire ties provided, to the
handle bars away from moving parts. Be sure all
controls function correctly.
© 2006 Simplicity Manufacturing, Inc. All Rights Reserved
Part No. 1687237
Form No. 1733417-00
Rev. 7/2006
TP 200-4352-00-AT-SN
