Compaq Premier Sound PS115 Specification

QuickSpecs
M
O D E L S
Compaq Premier Sound™ PS115 Speakers
133566-022
The Compaq Premier Sound PS115 Speakers offer users a compact, high-end sound solution.
O
V E R V I E W
Compaq Premier Sound PS115 Speakers offer users a compact, superb multimedia solution, providing crisp, clear highs, warm midranges and clean
robust basses for an impressive stereo sound experience.
This product is for users who need a more robust sound solution than a standard integrated desktop speaker. Specifically, this audience ranges from
mainstream application users to advanced film, video, and high-end post-production, to game developers and graphic designers.
Target Audience
The Compaq Premier Sound PS115 Speaker system is targeted for both home and business users who need and want a more robust sound solution.
Specifically, this audience ranges from mainstream application users to advanced film, video, and high-end post- production, to game developers and
graphic designers.
Performance
The Compaq Premier Sound PS115 Speakers are designed to exceed the customer's expectation of audio quality in small, compact, cost-effective
loudspeakers using the following advanced technologies:
Wide frequency bandwidth down to 75 Hz allows for controlled, smooth, hi-fi like bass
An amplifier capable of transmitting 18 W per channel so that distortion is controlled at both typical as well as low frequencies levels that require
more power
Transducer or speaker drive transforms the electric signals and delivers lower frequency output by lengthening the voice coils, increasing magnet
size, and enhancing the power handling capability
Bass reflex loudspeaker enclosures contain the transducers and amplifiers and are specifically designed to enhance the bass output in a small
space
The 10 stages of fixed equalization "shape" and "push the music back" so that a listener sitting 2-3 feet away is not blasted by the music, but rather
hears a natural sound reproduction.
Key Features
Attractive, slim form factor with cloth grille
Tone Control (loudness control) – User is able to optimize system's performance and listening for full response even at very low levels
Volume control
On/Off push button
Green on/off light
Headphone jack located on front of speaker
Line in for CD and other devices
Color coded connectors for easy hook-up
Integrated, low distortion, stereo amplifier rated at 10 watts per channel (RMS at 1% THD)
Exceptional low frequency output to 75 Hz provides wide spatial imaging
Acoustically tuned bass reflex enclosure
Low distortion, long throw, 3" full range drivers
Power in one box – master/slave configuration
External power supply
Same color scheme as all Compaq products
DA-10407 World Wide — Version 3 — June 14, 2001
Compaq Premier Sound
PS115 Speakers
1
