Emerson MEDIA AIR CLEANER ACM1000M-XXX Owner's Manual

Media air cleaner with media filter
Hide thumbs

Advertisement

Quick Links

Media Air Cleaner
With Media Filter
Model Number
ACM1000M-XXX
ACM1400M-XXX
ACM1600M-XXX
ACM2000M-XXX
OWNERS MANUAL
• Installation
• Operation
• Maintenance
Please read and familiarize yourself with the contents of this manual before
installing, operating or performing maintenance on the unit.
White-Rodgers is a division
of Emerson Electric Co.
www.white-rodgers.com
PART NO. 37-7001A
0922

Advertisement

loading

  Related Manuals for Emerson MEDIA AIR CLEANER ACM1000M-XXX

  Summary of Contents for Emerson MEDIA AIR CLEANER ACM1000M-XXX

  • Page 1 OWNERS MANUAL • Installation • Operation • Maintenance Please read and familiarize yourself with the contents of this manual before installing, operating or performing maintenance on the unit. White-Rodgers is a division of Emerson Electric Co. www.white-rodgers.com PART NO. 37-7001A 0922...
  • Page 2: Table Of Contents

    INTRODUCTION The Emerson Media Air Cleaner comes complete with a 4” media furnace air fi lter. This fi lter must be changed every three to six months to maintain effi ciency of the fi lter and furnace system. Please read instructions before installing and using the Air Filter Compartment.
  • Page 3: How The Air Filter Works

    HOW THE AIR FILTER WORKS Dirty air fl ows through your return air ducts and enters the compartment where particles (hair, lint, etc.) are removed by 4" FILTER the fi lter. See fi gure 1. Filtered air re-enters to the supply duct system of your building.
  • Page 4: Preinstallation

    2. Allow 25” of clearance in front of the air fi lter compartment door to permit removal of fi lters. See fi gure 4 for complete compartment dimensions. AIR FLOW FURNACE OPENING AIR CLEANER OPENING TRANSITION SECTION FURNACE (IF NEEDED) LOCATING THE AIR FILTER AN AIR FILTER MUST BE MOUNTED IN THE RETURN AIR DUCT OF A CENTRAL FORCED-AIR SYSTEM, ON THE AIR ENTERING SIDE OF FURNACE.
  • Page 5: Typical Mounting Positions

    TYPICAL MOUNTING POSITIONS AIR FLOW Figure 5 BASEMENT FURNACE (LOWBOY) Filter is mounted horizontally in return plenum, just above furnace. AIR FLOW Figure 7 HIGHBOY FURNACE Side installation. Filter is mounted vertically, where return air enters side inlet of furnace. LESS THAN 7 INCHES Figure 9...
  • Page 6: Installation

    INSTALLATION REMOVE OLD FILTER AND DISCARD (Figure 11) NOTE: This fi lter may be mounted in the furnace compartment. CLEAN BLOWER COMPARTMENT NOTE: The air fi lter cannot remove dirt from blower and ducts. INSTALLATION The following is a typical installation of the air fi lter on a “Highboy”...
  • Page 7 NOTES...
  • Page 8 White-Rodgers is a division of Emerson Electric Co. The Emerson logo is a trademark and service mark www.white-rodgers.com of Emerson Electric Co.
