Elta 5786CK Instruction Manual

PORTABLE CD/MP3 DISC PLAYER
LECTEUR PORTABLE DE CD/MP3 PORTABLE
TRANSPORTABLER CD/MP3-SPIELER
LETTORE CD/MP3 PORTATILE
APARELHO CD/MP3 PORTATIL
LECTOR PORTÁTIL DE CD/MP3
DRAAGBARE CD/MP3 DISK SPELER
MODEL : 5786CK
1 1
10
9
8
7
1 2 3 4 5 6
ENGLISH
LOCATION OF CONTROLS
1. PROG / MODE BUTTON
2. SKIP / SEARCH DOWN BUTTON
3. SKIP / SEARCH UP BUTTON
4. PLAY / PAUSE BUTTON (POWER ON)
5. STOP BUTTON (POWER OFF)
6. DIR. UP / ASP BUTTON
7. OPEN KNOB
8. HEADPHONE JACK
9. VOLUME
10. B.B.S. SWITCH (BASS BOOST SWITCH)
11. HOLD SWITCH
12. BATTERY COMPARTMENT
13. DC JACK
CAUTION
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE.
THIS SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT QUALIFIED
SERVICE PERSONNEL.
— 1 —
PREPARATIONS BEFORE USING
Battery Installation
1. Open Battery Compartment cover.
2. Insert 2 batteries (LR6, "AA" size, or equivalent)
in the correct polarity as indicated.
12
(Heavy duty batteries are recommended.)
3. Close the cover properly.
*Inorder to operate the player on batteries the optional AC/DC adaptor must be
13
disconnected from the DC 4.5V jack.
AC/DC Adaptor
*Before connection, make sure the AC voltage of the adaptor must correspond to your
local AC outlet voltage.
1. Plug the DC output of the adaptor to the DC 4.5V Jack.
2. Connect the adaptor (4.5V/600mA with polarity
DISC PLAYING
This CD player is designed to play the 8cm and 12cm compact disc without using
adaptor.
Hold Switch
Set the HOLD button to "ON" position, all the buttons will be locked. Before operation, be sure
to set the switch to "OFF" position, for normal operation.
Getting Start
1. Insert the headphone/earphone plug to PHONE JACK.
2. Push the OPEN switch to right side, and then the door open, put a disc into the
CD compartment with label side upward.
3. Push the disc gently around the centre area until it clicks so that the disc fits
into the pivot.
(To remove the disc : Pick up the disc, holding the edge, while pressing the
pivot gently.)
4. Close the door and press the PLAY/PAUSE button once.
5. The Display will show the total number of tracks of the disc, then begin to play the
first track.
General Operation
Play/Pause Buttons
Stop Button
Skip / Search Buttons
Directory UP / ASP Button
) to a power outlet.
— Press once to start playback in the original order.
Press again to stop the disc play temporarily.
— Press once to stop playback.
Press again to turn off power
— Press once to skip to next track or back to
previous track .
— Press continuously to search forward
or backward .
— ASP ON/OFF (For CD)
Directory UP (For MP3 Disc).
— 2 —
