Host Print Set-up Guide
D60425-06
November 2007
MPI Tech A/S
Vadstrupvej 35
2880 Bagsvaerd
Denmark
Tel: +45 44 36 60 00
Fax: +45 44 36 61 11
www.mpitech.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HOST PRINT D60425-06 and is the answer not in the manual?

Questions and answers

Summary of Contents for MPI Technologies HOST PRINT D60425-06

  • Page 1 Host Print Set-up Guide D60425-06 November 2007 MPI Tech A/S Vadstrupvej 35 2880 Bagsvaerd Denmark Tel: +45 44 36 60 00 Fax: +45 44 36 61 11 www.mpitech.com...

  • Page 2: Table Of Contents

    Table of contents PSF/MVS AFP Printing Using TCP/IP ..........3 PSF/MVS direct attachment ..............3 PSF/MVS start-up procedure .............3 z/OS SCS Printing Using TN3270e ............5 TN3270E Setup using z/OS Communication Server ......5 2.1.1 Mainframe TCPIP profile definitions: ..........5 2.1.2 SNA Definitions: ................5 Mainframe Printing Using SNA............6 Logmode ..................6 Ethernet - PS PU definition for 3174...........7...

  • Page 3: Psf/Mvs Afp Printing Using Tcp/Ip

    PSF/MVS AFP Printing Using TCP/IP This chapter provides information on how to create MVS definitions for printing from PSF/MVS via TCP/IP. The following topics are addressed: JES printer statements PSF Start-up procedure Once these parameters have been configured, and the basic TCP/IP installation of the PrintServer with IPDS has been completed, direct AFP / IPDS from PSF / MVS will be possible.
  • Page 4 //PRT420 CNTL //PRT420 PRINTDEV FONTDD=*.FONT01, /* FONT LIBRARY DD OVLYDD=*.OLAY01, /* OVERLAY LIBRARY DD PSEGDD=*.PSEG01, /* SEGMENT LIBRARY DD PDEFDD=*.PDEF01, /* PAGEDEF LIBRARY DD FDEFDD=*.FDEF01, /* FORMDEF LIBRARY DD JOBHDR=*.JOBHDR, /* JOB HEADER SEPARATOR OUTPUT */ JOBTRLR=*.JOBTLR, /* JOB TRAILER SEPARATOR OUTPUT*/ DSHDR=*.DSHDR, /* DATA SET HEADER SEPERATOR MESSAGE=*.MSGDS,...

  • Page 5: Z/Os Scs Printing Using Tn3270E

    z/OS SCS Printing Using TN3270e This chapter provides examples of how to set up SCS printing using TN3270e. 2.1 TN3270E Setup using z/OS Communication Server The IBM z/OS is capable of supporting TN3270e sessions communicating directly. The following describes the required mainframe definitions for a LinkCom or DocOut.

  • Page 6: Mainframe Printing Using Sna

    Mainframe Printing Using SNA This chapter provides: Note: The descriptions below appear in Ethernet and Token Ring versions respectively, and the sections are marked accordingly. Be sure to select the right section. • sample LU1 printer logmode definitions: 3.1 Logmode •...

  • Page 7: Ethernet - Ps Pu Definition For 3174

    3.2 Ethernet - PS PU definition for 3174 Sample definition for installation in association with a locally attached 3174. 3174 VTAM definition V1SNA1C2 VBUILD TYPE=LOCAL * LOCAL SNA 3174 V1LS1C2 CUADDR=3C3, DLOGMOD=D4A32782, PACING=3, VPACING=3, MAXBFRU=10, SSCPFM=USSSCS, USSTAB=VUSSTAB, LOGTAB=VMODETAB, MODETAB=VMODETAB * SINGLE ETHERNET DEVICE WITH ID=40005A0001C2 IDS1C2P1 LU LOCADDR=02,DLOGMOD=RSCSPRT1,PACING=0,MODETAB=RSCSTAB, USSTAB=VUSSTAB1,VPACING=3...

  • Page 8: Ethernet - Ps Pu Definition For 3745

    PrintServer Definition file extract &&??##N1,0# ; Start of file - Don't remove this ! ;------------------------------------------------------------------------ Configuration for the Ethernet PrintServer (This is an example. Please modify the parameters to match your configuration). 00824001 ;------------------------------------------------------------------------ ;*************************************#********************************** ;*************************************#********************************** BEGIN_CONFIGURATION PU BLOCKNUMBER ; Fill in your Block number IDNUMBER 00000 ;...
  • Page 9 PU/LU Definitions SPPRKEN VBUILD TYPE=SWNET, SWITCHED MAJOR NODE MAXNO=1, MAXGRP=1 STATOPT=‘NN PRINTER’ PA01B91 PU ADDR=C1, IDBLK=017, IDNUM=E2961, DISCNT=NO, MAXOUT=1, MAXDATA=1033, MODETAB=MTABPS, PACING=3, VPACING=3, MAXPATH=1, PUTYPE=2, DLOGMOD=MODPS PATH B91PATH DIALNO=020400036E0035C9,GRPNM=ZTOKEN,GID=1,PID=1 TA01B911 LU LOCADDR=2,DLOGMOD=MODPS PSF JCL //PRTN CNTL //PRTN PRINTDEV FONTDD=*.FONT300, /*FONT LIBRARY DD OVLYDD=*.OLAY01, /*OVERLAY LIBRARY DD PSEGDD=*.PSEG01,...

  • Page 10: Token Ring - Ps Pu Definition For 3174

    3.4 Token Ring - PS PU definition for 3174 Sample definition for installation in association with a locally attached 3174. 3174 VTAM definition V1SNA1C2 VBUILD TYPE=LOCAL * LOCAL SNA 3174 V1LS1C2 CUADDR=3C3, DLOGMOD=D4A32782, PACING=3, VPACING=3, MAXBFRU=10, SSCPFM=USSSCS, USSTAB=VUSSTAB, LOGTAB=VMODETAB, MODETAB=VMODETAB * SINGLE TOKEN RING DEVICE WITH ID=40005A0001C2 IDS1C2P1 LU LOCADDR=02,DLOGMOD=RSCSPRT1,PACING=0,MODETAB=RSCSTAB,...

  • Page 11: Token Ring - Ps Pu Definition For 3745

    PrintServer Definition file extract &&??##N1,0# ; Start of file - Don't remove this ! ;------------------------------------------------------------------------ Configuration for the Token Ring PrintServer (This is an example. Please modify the parameters to match your configuration). 00824001 ;------------------------------------------------------------------------ ;*************************************#********************************** ;*************************************#********************************** BEGIN_CONFIGURATION PU BLOCKNUMBER ;...
  • Page 12 PU/LU Definitions SPPRKEN VBUILD TYPE=SWNET, SWITCHED MAJOR NODE MAXNO=1, MAXGRP=1 STATOPT=‘NN PRINTER’ PA01B91 PU ADDR=C1, IDBLK=017, IDNUM=E2961, DISCNT=NO, MAXOUT=1, MAXDATA=1033, MODETAB=MTABPS, PACING=3, VPACING=3, MAXPATH=1, PUTYPE=2, DLOGMOD=MODPS PATH B91PATH DIALNO=020400036E0035C9,GRPNM=ZTOKEN,GID=1,PID=1 TA01B911 LU LOCADDR=2,DLOGMOD=MODPS PSF JCL //PRTN CNTL //PRTN PRINTDEV FONTDD=*.FONT300, /*FONT LIBRARY DD OVLYDD=*.OLAY01, /*OVERLAY LIBRARY DD PSEGDD=*.PSEG01,...

  • Page 13: Configuration Of Ms Sna/His Server

    Configuration of MS SNA/HIS Server This chapter provides examples of how to set up SCS printing using TN3270e. 4.1 General setup 4.1.1 Adding DLC 802.2 protocol to your Windows Server / Workstation In order to communicate via Token ring or Ethernet over SNA, you must add the DLC protocol to your Windows Server or Workstation running SNA Server.

  • Page 14: Sna Server Configuration - Create A Link

    4.1.2 SNA Server configuration – Create a link You must define the Server LAN card to be used to communicate with the host. - Folder Link Services, make a right click and select Link Service. Select DLC 802.2 Link Service from the list. - In the DLC 802.2 Link Service Properties window, select the LAN card you want to use.
  • Page 15 Connections : General Connections : Address Note : Remote Network Address must match the Host MAC Address (TIC)
  • Page 16 Connections : System Identification Note : local Node ID must match the ID_NUM and ID_BLOCK parameters of the VTAM PU Definition Connections : System Identification Note : MAX BTU Length must match the MAX_DATAD parameter of the VTAM PU Definition...

  • Page 17: Sna Server Configuration - Create A Printer Lu

    4.2 SNA Server configuration – Create a Printer LU Attached to the connection, you must create your printer LU. In order to run with MPI Router, you must define a LUA LU. - Make a right click on your connection and select Application LU (LUA). - This new window appears: Note : The number specified for LU must match the LOCADDR parameter of the VTAM LU Definition...

  • Page 18: Configuring Blueserver For Sna Communication

    4.3 Configuring BlueServer for SNA communication 4.3.1 Setup Connection tab Notes: - The other tabs “IPDS Settings”, “Paper Controls”, are not used in this case. - The SCS Settings tab is only used only for SCS printout.

  • Page 19: Loading The Router Mainframe And Parser

    4.4 Loading the Router Mainframe and Parser 4.4.1 Microsoft SNA/HIS status indication The PSNA201 is SSCP 4.4.2 Blue Server status indication With this configuration, you are now able to print SCS or IPDS jobs from your Mainframe IBM host.

  • Page 20: Configuring Docout For Sna Communication

    4.5 Configuring DocOut for SNA communication 4.5.1 Setup LUA(LU1) tab Select AFP/IPDS (PSF) using SNA (LU1/LUA) SCS (S/390) using SNA (LU1/LUA) Check Configuration: Select: Save Configuration...

  • Page 21: Microsoft Sna/His Status Indication

    4.5.2 Microsoft SNA/HIS status indication The PSNA201 is SSCP 4.5.3 DocOut status indication With this configuration, you are now able to print SCS or IPDS jobs from your Mainframe IBM host.

  • Page 22: Psf/Aix Ipds Printing Using Tcp/Ip

    PSF/AIX IPDS Printing Using TCP/IP This chapter provides details on: Adding a TCP/IP attached printer Set up of the KEEPALIVE TCP/IP feature The basic TCP/IP installation of the PrintServer (IPDS) must be completed before direct AFP / IPDS from PSF/AIX will be possible. 5.1 Adding TCP/IP attached printer The port number is defined in the PSF/AIX SMIT Add a TCP/IP-Attached Printer panel.

  • Page 23: Aix Keepalive Support

    5.3 AIX KEEPALIVE support The no (network options) command can be used by the root user to configure KEEPALIVE frequencies. no -o tcp_keepidle=nnn no -o tcp_keepintvl=nnn when nnn is in half-seconds. The command tcp_keepidle specifies the interval of inactivity causing the TCP to generate a KEEPALIVE transmission for an application that requests them.

  • Page 24: Psf/400 Afp Printing Using Tcp/Ip

    PSF/400 AFP Printing Using TCP/IP This chapter provides configuration guidelines for AS/400 IPDS Printing over TCI/IP. These guidelines are applicable for OS/400 version 3.7, 4.X and 5.X. The examples of completed screens given are for OS/400 version 4.X and 5.X and may contain some additional parameters not seen in version 3.7, these may be ignored.

  • Page 25: Creating The Printer Device Description

    A completed PSF Configuration looks like this: PSF Configuration Information Page 1 PSF configuration: NETWRKPRT Library: User resource library ... . . : *JOBLIBL IPDS pass through ....: *YES Activate release timer.
  • Page 26 Display Device Description Page 1 5716SS1 V4R4M0 981108 BLDRB1 09/11/98 12:02:59 Device description ..: DEVD <DeviceName> Option ....: OPTION *ALL Category of device .

  • Page 27: Scs/Dca Printing Using Tn5250E

    SCS/DCA Printing Using TN5250e To set up TN5250, configure your PrintServer using PrintGuide (see the manual Getting Started with PrintGuide, doc. no. 60364 on the Utility Pack). Start PrintGuide, select Telnet Print Settings (Figure 7), select TN5250e as Connection Type and enter the Device Name for your <PrintServer>. On many AS/400 installations, a device is automatically set up on the AS/400 when the PrintServer is booted.
  • Page 28 Prerequisites: • AS/400 is configured and running TCP/IP • Firmware level* on the interface is at least S80 xxx.360 • Release of PrintGuide* being used is at least S42 065.100 * Latest versions can be obtained from the MPI Tech web page 1.
  • Page 29 3. Double-click on the highlighted session.
  • Page 30 Type in the Device Name. This must be a unique name on the AS/400 that you wish to connect to. It can have up to 10 characters. Type in the Host IP Address of the AS/400 you wish to connect to. The standard Telnet port 23 is used for the Host Port and is predefined.
  • Page 31 The value of CTL should match the virtual controller on the system (Normally QVIRCD0001) The value for TEXT is optional. Create Device Desc (Printer) (CRTDEVPRT) Type choices, press Enter. Device description ..DEVD > DEVXXXX Device class .

  • Page 32: As/400 Printing Using Tcp/Ip Lpr/Lpd

    AS/400 Printing using TCP/IP LPR/LPD This chapter provides: AS/400 definitions Once these parameters have been configured, and the basic TCP/IP installation of the PrintServer has been completed, printing from AS/400 will be possible. This will use the AS/400 Host Print Transform to format and translate EBCDIC data to the printer language selected.

  • Page 33: As/400 Printing

    The value *IP must be used for CNNTYPE The value *OTHER must be used for DESTTYPE The value *YES must be used for TRANSFORM The value used for MRFTYPMDL will depend on the attached printer. Use the ‘F4’ to obtain a list of the possible choices The value used for INTNETADR must be the same as the IP address of your PrintServer.
