    PN 50893:B ECN 00-317 Auxiliary Power Supply APS-6RF Instruction Manual Document 50893 07/20/2000 Rev:...
  • Page 2 While a fire alarm system may lower insurance Fire Alarm System Limitations rates, it is not a substitute for fire insurance! An automatic fire alarm system–typically made up of Heat detectors do not sense particles of combustion and smoke detectors, heat detectors, manual pull stations, alarm only when heat on their sensors increases at a audible warning devices, and a fire alarm control with predetermined rate or reaches a predetermined level.

  • Page 3: Installation Precautions

    Adherence to the following will aid in problem-free Installation Precautions installation with long-term reliability: WARNING - Several different sources of power can be Like all solid state electronic devices, this system may connected to the fire alarm control panel. Disconnect all operate erratically or can be damaged when subjected sources of power before servicing.
  • Page 4 This Page Intentionally Left Blank APS-6RF Instruction PN 50893:B 7/20/00...

  • Page 5: Table Of Contents

    Table of Contents Table of Contents 1. Overview Introduction ..................... 7 Description ....................... 7 Specifications ....................9 2. Installation Introduction ....................11 Wiring the APS-6RF ..................12 Field Wiring an APS-6RF................12 Connecting Multiple APS-6RF Power Supplies........13 Connecting the APS-6RF to an IC-4F/ICE-4F Module......14 Configuring the APS-6RF................
  • Page 6 This Page Intentionally Left Blank APS-6RF Instruction PN 50893:B 7/20/00...

  • Page 7: Overview

    1. Overview Introduction This document contains information for installing, servicing, and configuring the APS-6RF Auxiliary Power Supply. The table below contains a list of document sources for supplemental information: Part Control Panels Refer to... Number Sensiscan 2000 Sensiscan 2000 Manual 15017 Sensiscan 200 Sensiscan 200 Manual...
  • Page 8 1. Overview Description The figures below identify the features of the APS-6RF power supply: Trouble In (J4) - Trouble Out (J3) “P” style connectors for internal cabinet connections Three 24 VDC output circuits LED Status Indicators: Two (2) power-limited Green LED – Indicates AC power on One (1) non power-limited Yellow LED –...

  • Page 9: Specifications

    Specifications 1. Overview Specifications The APS-6RF is compatible with the Sensiscan 2000, and Sensiscan 200 control panels. Specifications for the APS-6RF are: Electrical Specifications AC Primary Input Power 120 VAC, 60 Hz, 2.5 A Wire Size: #14 AWG with 240 VAC, 50 Hz, 1.2 A 600 VAC insulation 24 VDC Secondary Input Power Current draw with AC power loss...
  • Page 10 NOTES APS-6RF Instruction PN 50893:B 7/20/00...

  • Page 11: Installation

    2. Installation WARNING: Use extreme caution when working with the APS-6RF. High voltage and AC line-connected circuits are present. Turn off and remove all power sources. To reduce the risk of electric shock make sure to properly ground the unit. Introduction This section contains instructions for common wiring, configuring and servicing the APS-6RF.

  • Page 12: Wiring The Aps-6Rf

    2. Installation Wiring the APS-6RF Wiring the APS-6RF This section contains instructions for wiring the Auxiliary Power Supply as follows: • Typical field wiring from an APS-6RF to a control panel. • Wiring multiple APS-6RF power supplies. • Connecting an APS-6RF to an IC module Field Wiring an APS-6RF You can use J1 and J2 in place of TB2 when the APS-6RF is powering internal modules (such as an IC-4F, ICE-4F, TC-2F, TC-4F) with...

  • Page 13: Connecting Multiple Aps-6Rf Power Supplies

    Wiring the APS-6RF 2. Installation Connecting Multiple APS-6RF Power Supplies Typical trouble bus connections for multiple APS-6RF power supplies using trouble connectors J3 and J4. Use Cable 71033 or 75098 (same cables; different lengths) for all wiring. See appendix on your system for specific “Trouble Input” connection. Note: J3 and J4 can be interchanged.

  • Page 14: Connecting The Aps-6Rf To An Ic-4F/Ice-4F Module

    2. Installation Wiring the APS-6RF Connecting the APS-6RF to an IC-4F/ICE-4F Module All four (4) NACs on the IC-4F are powered from the APS-6RF output circuit 2 (J2) and the four (4) NACs on the ICE-4F are powered from circuit 1 (J1). The NACs share the total 3A available from each circuit. Typical connections for wiring: IC-4F ICE-4F...

  • Page 15: Configuring The Aps-6Rf

    Configuring the APS-6RF 2. Installation Configuring the APS-6RF The APS-6RF may be configured for the following: • 8-hour delay for reporting loss of AC: cut jumper JP2. • 16-hour delay for reporting loss of AC: cut jumper JP2 and JP3. •...

  • Page 16: Servicing The Aps-6Rf

    2. Installation Servicing the APS-6RF Servicing the APS-6RF The only serviceable components on the APS-6RF are fuses F1 and F2. If a fuse fails, replace it with a fuse of the same type and rating: • F1 AC protection - 4A, 3 AG •...

  • Page 17: Appendix A: Sensiscan 200

    Appendix A: Sensiscan 200 Mounting in a CAB-200 Backbox The Auxiliary Power Supply is mounted as shown in the figure below. To mount the APS-6RF, follow these instructions: Step Action Remove plastic cover from APS-6RF. If 240 VAC is to be used, cut JP1 jumper at this time. See "Configuring the APS-6RF"...

  • Page 18: Connecting The Aps-6Rf To An Mps-24Bf

    Appendix A: Sensiscan 200 Connecting the APS-6RF to an MPS-24BF Connecting the APS-6RF to an MPS-24BF Make the following connections as shown in the figure below. • Connect primary power from TB1 to MPS-24BF terminal block TB1, Pin 3( ) and Pin 4( NEUT •...

  • Page 19: Appendix B: Sensiscan 2000

    Appendix B: Sensiscan 2000 Mounting in CAB-A3F or CAB-B3F Cabinet This section contains instructions for the installation of the Auxiliary Power Supply onto a CHS-4F chassis used in a CAB-A3F or CAB-B3F cabinet. To mount the APS-6RF, follow these instructions: Step Action Remove plastic cover from APS-6RF.

  • Page 20: Connecting The Aps-6Rf To An Mps-24Af

    Appendix B: Sensiscan 2000 Connecting the APS-6RF to an MPS-24AF Connecting the APS-6RF to an MPS-24AF Make the following connections as shown in the figure below. • Connect primary power from TB1 to MPS-24AF terminal block TB1, Pin 5( ) and Pin 7( NEUT •...

  • Page 21: Connecting The Aps-6Rf To An Mps-24Bf

    Connecting the APS-6RF to an MPS-24BF Appendix B: Sensiscan 2000 Connecting the APS-6RF to an MPS-24BF Make the following connections as shown in the figure below. • Connect primary power from TB1 to MPS-24BF terminal block TB1, Pin 3( ) and Pin 4( NEUT •...
  • Page 22 NOTES APS-6RF Instruction PN 50893:B 7/20/00...
  • Page 23 Index Index Numerics 12, 14 16-hour delay IC-4F/ICE-4F 240 VAC connections to operation Installation topics 17, 19 use of internal modules 8-hour delay J1 connection AC protection J2 connection J3 connection J4 connection 15, 17, 19 JP1 jumper backbox JP2 jumper Battery protection JP3 jumper jumpers, location of...
  • Page 24 Index serviceable components Specifications 17, 19 standoff TC-2F/TC-4F terminal block cover Trouble Bus trouble connectors 18, 20, 21 trouble input Warning, High Voltage wiring APS-6RF Instruction PN 50893:B 7/20/00...
  • Page 25 APS-6RF Instruction PN 50893:B 7/20/00...
  • Page 26 APS-6RF Instruction PN 50893:B 7/20/00...

  • Page 27: Limited Warranty

    Limited Warranty The manufacturer warrants its products to be free from defects in materials and workmanship for eighteen (18) months from the date of manufacture, under normal use and service. Products are date-stamped at time of manufacture. The sole and exclusive obligation of the manufacturer is to repair or replace, at its option, free of charge for parts and labor, any part which is defective in materials or workmanship under normal use and service.
  • Page 28 World Headquarters One Fire-Lite Place, Northford, CT 06472-1653 USA 203-484-7161 • Fax 203-484-7118 www.firelite.com...
