Mazda MPV/Miata (PKM2 Installation Manual

Platform # 05
Description: Mazda Transponder Interface: MPV/Miata (PKM2) NO KEY REQUIRED
Functions: Data Transponder Interface: Override OEM Transponder Immobilizer Via Data
Downloadable Firmware for Platform #05: PKG3,PKG8,PKH1, PKH2,PKH3,PKH4,PKHY1,PKM2,PKN2,PKT2
WARNING: Before beginning your install go to www.XpressDownload.com and be sure to print the LATEST corresponding installation manual
for the firmware that is flashed to the platform you are using.
Section A
See Wire Connection Guide for detailed information regarding wire functionality
INPUT
UPGRADEABLE
N/C
OVERRIDE OEM
OUTPUT
TRANSPONDER
DATA
IMMOBILIZER
DATA
VIA DATA
INPUT
OUTPUT
N/C
INPUT
INPUT
Section B

WIRE GUIDE: CONNECTIONS

10 PIN HARNESS
D2D = Optional use of 4 Pin Data to Data (D2D) cable will replace the analogue wire (w2w) connection
(-)
WIRE I/O
D2D
/(+)
COLOR w2w STATUS
PIN#
(-)
1 D2D
Brown Input
w2w
2 N/C N/C N/C
Green
(+)
Blue w2w Output
3
Violet/
w2w
Data
4
White
w2w
5 Violet Data
(+)
Pink/
6 w2w
Input
White
(+)
7 Pink Output
w2w
N/C N/C N/C
8 Orange
(+)
9 Red D2D Input
w2w
(-)
10 Black D2D
Input
w2w
Legend RCS = Remote Control System
DATA to DATA PORT (D2D):
OPTION A: - D2D Port used to connect to USB Bootloader adaptor & computer to download & flash vehicle interface firmware.
OPTION B: - D2D Port used to connect to the data port of a remote control system equipped with ClearCode ehicle nterface rotocol.
Remote control systems designed with ClearCode VIP can securely communicate via the D2D cable to transmit & receive data commands which initiate
specific vehicle function such as doorlocks & immobilizer override and /or request information from the vehicle such as status of entry points (doors) or
ambiant température, diesel glow plug etc... ClearCode VIP represents the doorway to vehicle integration...As an enhanced security feature, this upgradeable
vehicle interface module automatically detects when the Vehicle Interface Protocol is present and deactivates the analogue override input wire (brown wire)
ensuring that this module can only be activated by an authorized user.
Section C

VEHICLE PROGRAMMING

1) Once module has been properly connected, press and hold programming button then turn key to
2) Start vehicle by key, LED will begin to flash. Module is now programmed.
*To RESET, press and hold button and plug in module. LED comes on. When LED goes off, release button.
Firmware: PKM2
4 PIN DATA TO DATA (D2D) CABLE (OPTIONAL ACCESSORY)
(-)
Brown Ground When Running
N/C Green
N/C
(+) Blue
Ignition ECM Side
Violet/White
Data (Key Side)
Violet Data (ECM Side)
(+) Ignition (Key Side)
Pink/White
(+)
Pink Ignition (ECM Side)
N/C Orange
N/C
(+)
Red (+)12 Volt Constant
(-)
Black Chassis Ground
Programming
button
Connect
Location SPECIFIC WIRE CONNECTION LOCATION
RCS Ground When Running output of remote starter
N/C N/C
Connect in parallel to Pink wire of 10 PIN Harness
Vehicle
Vehicle Connect to Blue/Black Vehicle Data wire (Key Side)
*Data wire in the Miata is Red/Black
Connect to Blue/Black Vehicle Data wire (ECM Side)
Vehicle
*Data wire in the Miata is Red/Black
Vehicle Connect to Black/White Vehicle Ignition wire (Key Side)
Once connected in parallel to Blue wire of 10 PIN
Vehicle
harness, connect to Black/White Vehicle Ignition wire
(ECM Side)
N/C N/C
Vehicle Constant (+) 12 Volt Source
Vehicle Connect to Black or Black/Orange Vehicle Ground wire
N/C = No Connection
Blue connector of D2D Cable plugs into the upgradeable vehicle interface module.
Option A
Firmware Upgrades
USB Adaptor
Option B - Data 2 Data Connection to RCS Data Port
ECM
Side
ACTIVATION and/or FUNCTIONALITY
Immobilizer Bypass Via Data
N/C
Ignition Power Source Supply
Data Commands from Module to Vehicle
Data Commands from Module to Vehicle
Ignition Power Source Return
Ignition Power Source Supply
N/C
Power Source
Ground Source
N/A = Not Applicable W2W= analogue wire to wire
V
IGNITION position, LED should come on solid.

Installation

Manual (1\1 Page)
Internet
P . C .
USB Cable
CLEARCODE VIP
DATA PORT
Key
Side
MAZDA
IMMOBILIZER
MODULE
Immobilizer module is located
under dash on the driver side
to the right of the steering
column.
D2D= data 2 data
I P
