ASSEMBLY, CARE & USE MANUAL
WARNING & SAFETY INFORMATION
ELECTRIC PATIO GRILL
MODELS 20150112, 20150213, 20150513, 20150613, 20150713
THIS PRODUCT IS FOR OUTDOOR USE ONLY
Approximate assembly time : 60 minutes
Tool needed for assembly: Phillips Head Screwdriver
WARNING
WARNING
This manual contains important
Use only outdoors where it is
information necessary for the proper
well ventilated.
and safe use of this unit.
Read and follow all warnings
and instructions before using
Fuel, such as charcoal briquettes, wood or heat
grill and during use.
pellets, are not to be used in the unit.
Keep this manual for future reference.
Failure to follow these warnings and instructions properly could result in personal injury or death.
Advertisement
Table of Contents
Summary of Contents for Master Bilt 20150112
- Page 1 ASSEMBLY, CARE & USE MANUAL WARNING & SAFETY INFORMATION ELECTRIC PATIO GRILL MODELS 20150112, 20150213, 20150513, 20150613, 20150713 THIS PRODUCT IS FOR OUTDOOR USE ONLY Approximate assembly time : 60 minutes Tool needed for assembly: Phillips Head Screwdriver WARNING WARNING This manual contains important Use only outdoors where it is information necessary for the proper...
- Page 2 GENERAL WARNINGS AND SAFETY INFORMATION READ ALL INSTRUCTIONS When using electrical appliances, basic safety precautions should always be followed including the following: • Cannot be operated for more than hours. • Use GFI protected electrical outlet to reduce the risk of electrical shock. •...
-
Page 3: General Warnings And Safety Information
GENERAL WARNINGS AND SAFETY INFORMATION • Be careful when removing food from electric grill. All surfaces are HOT and may cause burns. Use protective gloves or long, sturdy cooking tools. • Drip tray is only for the bottom of electric grill. Do not put drip tray on cooking grate this may damage electric grill. - Page 4 GENERAL WARNINGS AND SAFETY INFORMATION • Fatty foods (hamburgers,etc.) can have excess grease and cause fl are ups. When cooking fatty foods use a low setting with lid open. • Clean internal base pan before each use. This will cut down on build-up and fl are-ups. •...
-
Page 5: Parts List
DO NOT RETURN TO RETAILER For Assembly Assistance, Missing or Damaged Parts Call: MASTERBUILT Customer Service at 1-800-489-1581. STOP! Please have Model Number and Serial Number available when calling. These numbers are located on silver label on back of unit. PARTS LIST PART NO DESCRIPTION... -
Page 6: Hardware List
HARDWARE LIST M6x35 34x25 M4x40 Phillips Head Screw Flat Washer Thumb Screw Phillips Head Screw Qty: 2 Qty: 4 Qty: 2 Qty: 2 M6x13 M8x55 Bakelite Spacer M4x12 Phillips Head Screw Phillips Head Screw Qty: 2 Phillips Head Screw Qty: 40 Qty:2 Qty: 3 M6x8... - Page 7 ASSEMBLY • BEFORE ASSEMBLY READ ALL INSTRUCTIONS CAREFULLY. • ASSEMBLE UNIT ON A CLEAN, FLAT SURFACE. • TOOL NEEDED: PHILLIPS HEAD SCREWDRIVER • UNPACK ALL PARTS AND LAY OUT IN FRONT OF YOU. CHECK TO MAKE SURE ALL PARTS ARE IDENTIFIED AND ACCOUNTED FOR. *Note that the front of the grill is actually the shortest width of the bottom storage shelf (12).
- Page 8 ASSEMBLY STEP 4 Attach bottom shelf (12) to legs (18) using screws (G) with the feet facing away from right side of the shelf as shown. Repeat for wheel legs (19) on left side using screws (G). REMEMBER! The short side of bottom shelf (12) is the front of grill.
- Page 9 ASSEMBLY STEP 5b Repeat step 4a for leg (19, “FL”). STEP 5c Place panel (14b) [the panel with the serial plate] over panels (13) and insert screw (G); into bottom holes.
- Page 10 ASSEMBLY STEP 6 Insert support (11b) into front leg (18, “FR”) with holes facing in- ward. Insert other (11a) into back leg (18, “BR”) with holes facing inward. Repeat steps for left side. When all supports are in place screw holes should be facing each other as shown in image.
- Page 11 ASSEMBLY STEP 8 Attach drip tray bracket (8) to grill base (5) using washers (I) and screws (L). Note: Make sure to use screw (L) from the blister pack, and not screw (G) as screw (L) is shorter than (G). M6x13 M6x8 Phillips Head...
- Page 12 ASSEMBLY STEP 10 Place logo base (28) onto grill base (5). Secure using washers (J) and screws (H). STEP 11 Note: Hinge for grill base is larger than hinge for grill lid. Attach left bottom hinge (24) to grill base (5) using washers (C) and screws (G).
- Page 13 ASSEMBLY STEP 12 Note: Hinge for grill lid is smaller than hinge for grill base. From inside grill lid, align holes of left lid hinge (25) to grill lid (1) holes. Secure with screws (G) and fl at washer (C). Repeat step on other side with right lid hinge (26), washer (C) and screw (G).
- Page 14 ASSEMBLY STEP 14 *Note: Wing nut is packaged with temperature gauge. Attach temperature gauge (2g) and temperature gauge base (2b) WING NUT to grill lid (1) using wing nut. Tip: Make sure the temperature readings and Masterbuilt logo in the gauge are aligned cor- rectly before tightening down the wing nut.
- Page 15 ASSEMBLY STEP 16 Attach left side shelf (6) to both supports (11) using screws (G). Repeat step on opposite side with right side shelf (3). GO BACK AND TIGHTEN ALL SCREWS AT THIS TIME. Note: The left side shelf is the shelf with a square notch in it as seen in FIGURE 1.
- Page 16 ASSEMBLY STEP 18 Attach heating element (4) to grill base (5) using screws (A) as shown. Thumb Screw STEP 19 Position cooking grate (20) on top of grill base (5). Note: The 2 support bars on cooking grate (20) should span left to right, with the grates going front to back.
- Page 17 ASSEMBLY STEP 20 Insert warming rack (21) onto cooking grate (20), with forks of warming rack straddling grate as shown in FIGURE 3. FIGURE 3 STEP 21 Plug controller (10) into side of grill base (5) from below side shelf (6), coming in at a slight angle, carefully inserting plug while lifting so that top of controller slips into...
- Page 18 ASSEMBLY STEP 21 Slide drip tray (7) into drip tray bracket (8) from the right side. ASSEMBLY IS COMPLETE SAFE STORAGE AND MAINTENANCE • Inspect hardware and assembled parts on a regular basis to insure grill is in safe working condition. •...
-
Page 19: Limited Warranty
LIMITED WARRANTY Masterbuilt warrants its products to be free from defects in material and workmanship under proper assembly, normal use and recommended care for 90 days from the date of original retail purchase. Masterbuilt warranty does not cover paint fi nish as it may burn off during normal use. Masterbuilt warranty does not cover rust of the unit. - Page 20 Masterbuilt Manufacturing, Inc. 1 Masterbuilt Ct. Columbus, GA 31907 Customer Service 1-800-489-1581 www.masterbuilt.com...
