Euphonix Studio Monitor Express Guide Manual page 12

section 6
The Config tab displays the currently selected Core Audio device driver, Dim and fixed
output levels.
audio Device: This drop-down menu selects the Core Audio driver for the sound card to
use with SME.
12
set Dim level: Sets the program signal's absolute Dim Level when the Control Room
Setup Touchscreen's Dim button is active.
set fixed level: Sets a fixed output level for the Control Room output. This is useful for
sending the DAW output to a separate mixer or router that has its own level controls, in-
stead of controlling the output level from SME.
NOTE: When the output driver is changed, patching is reset to default settings with no external or out-
put patches enabled. Patches must be reassigned in the Patching tab.
config
figure 5
Artist Series
professional control surfaces
Config Tab
