BTH-818 Bluetooth Headset User Manual
1. BTH-818 Headset
1.1 Introduction to your new headset
Thank you for purchasing the new BTH-818 Bluetooth Headset – We trust it will deliver the
best that both Bluetooth convenience and reliability has to offer.
The BTH-818 represents the latest innovation in both functionality and audio quality –
enabling users with compatible mobile devices the use of a calling number display while
also supporting the latest SmartPhones utilising both Handsfree and Headset Profiles –
Ensuring compatibility with Nokia, Sony Ericsson and many more mobile phones along
with Windows powered SmartPhones. This guide is provided as an introduction to using
the headset with Bluetooth mobile phones using either a Handsfree or Headset profile.
1.2 Key Features
Bluetooth operating distance - 10 meters.
Talk time – 7 hours.
Standby time – Approx 300 hours.
Uses high capacity rechargeable Li-ion polymer battery
Detects and warns of low battery conditions.
Convenient user interface with on-board LCD.
Call List function for up to ten recently used phone numbers
Phone Book function with ten permanent quick dial number memory
Five ring tone options.
Mute-call function.
Setup and Time display.
Up to 5 Bluetooth devices can be paired simultaneously.
Easy to use and setup.
1.3 Technical Specification
Bluetooth Standard
Operation Range
Audio Codec
Operating Frequency
Dimensions:
Connection
Device Weight
Talk time
Standby time
Output Power
Security
Power Consumption
Battery
Charging
Charging time
Operating Temperature
Storage Temperature
Certification
LCD
Headset passkey
v1.1
10 meter (Approx 33 feet)
15 bit resolution, S/N > 60dB
2.4 Ghz - 2.4835 Ghz ISM Band
(L)72mm*(W)26mm * (H)16mm
Point-to-point
35g (including battery)
7 hours
300 hrs
0 Dbm (class II)
128 bits encryption
40mA working, 1mA standby
Rechargeable Li-ion polymer 300mAh
5vdc, 100~240V AC adapter
2~3 hrs
-10º~55º C
-20º~60º C
CE, FCC, BQB
1/16 duty cycle 5V.
0000
1
v2.01
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Globalsat BTH-818
Summary of Contents for Globalsat BTH-818
- Page 1 BTH-818 Bluetooth Headset User Manual v2.01 1. BTH-818 Headset 1.1 Introduction to your new headset Thank you for purchasing the new BTH-818 Bluetooth Headset – We trust it will deliver the best that both Bluetooth convenience and reliability has to offer. The BTH-818 represents the latest innovation in both functionality and audio quality –...
- Page 2 2. BTH-818 Appearance and Pushbutton Descriptions: 2.1 Operational Button Descriptions Figure 1 Terminates the current call. Power Switch / Initiates an outgoing call or accepts an incoming call. Increase Volume Decrease Volume Earpiece on-cable switch allows call pickup - Identical to key in function.
- Page 3 Figure 2 Figure 3...
- Page 4 2.3 Operation and Fitting Figure 4 Figure 5...
-
Page 5: Operation
2.4 Symbols Displayed on LCD Display Battery charge condition Turn off the ring tone Call & Phone Book Indicator Missed Call Indicator Activating the Bluetooth Bluetooth is Being Connected Time of Graphic Display 3. Operation 3.1 Setting Up the Headset for the First Time 3.1.1 Initial Recharge of The BTH-818 Before initially using this product, please charge the battery for 2-3 hours. - Page 6 Figure 6 Figure 7 3.1.2 Setting the Time of Day Before using BTH-818 product, please set up system time. The setting procedure is outlined below: Menu Set System Time press to select time column press to change time and key to confirm the time as selected. 3.2 Resetting the Headset for Initial Use To re-initialize the BTH-818 headset, press and hold for three seconds, until you...
- Page 7 Figure 8 Note: 1. For some mobile phones like T610, you can easily change the device name from the option menu. (All the device names have to be in English else it will show “Unknown Device” on the BTH-818). 2. When the pairing is completed, it will show “Unknown Device” on the GV-101. After the bluetooth is fully connected with the BTH-818, the selected device name will be shown on the BTH-818.
- Page 8 Menu Option Descriptions: SetRing Option to Set Up Ring Tones Device MGT Bluetooth Pairing Management. Set System Set Up System Parameters. 3.5 Bluetooth Pairing Management The BTH-818 headset must first be paired with your Bluetooth mobile phone prior to use. You may need to refer to your mobile phone’s instruction manual for the correct pairing procedure for your device as every phone has a different pairing procedure.
- Page 9 Note: 1. For some mobile phones like T610, you can easily change the device name in the settings. (All names have to be in English otherwise the BTH-818 will show “Unknown Device”). 2. When the pairing is completed, it will show “Unknown Device” on the mobile phone. After the bluetooth is fully connected with the BTH-818, the selected device name will be shown on the mobile phone.
- Page 10 Then, press to call based on the call list or phone book. When scrolling through the list, you may notice that the end of call list connects to the beginning of phone book. Figure 10 Figure 11 Figure 12 3.6.1 Adding Numbers From Call List into Phone Book Pressing once, the system will show “L/N Redial”...
- Page 11 Figure 13 3.7 Deleting Phone Book Numbers Press once – The headset will show “L/N Redial” and will enter the call list mode; Press to enter the phone book and select the number to delete. Press and hold until you hear one “beep”, the call number selected is then deleted from the phone book.
- Page 12 4.1 Changing the Earphone Volume Level While making a call, you can use to change the earphone’s volume level. 4.2 Muting the Microphone During a Call Press during a call to switch to mute mode. The display will show the mute symbol and you will hear a warning tone from the headset to remind you to return from mute mode.
- Page 13 Pressing the button will shut down the ring tone. When the icon displays, it means that the ring tone has been muted. 4.4 Changing the Headset Ring Tone Enter the option menu Set Ring press button. The headset will play the ring music as selected. You can use the buttons to select press...
- Page 14 4.7 Backlight Operation While operating any of the BTH-818 function keys, the backlight will activate for 5 seconds before automatically switching off. 4.8 Automatic Bluetooth Disconnection (Power Save Mode) Enter the Option Menu Set System Auto Disconnection If Selecting “YES” - Bluetooth connection will automatically disconnect after 30 seconds of inactivity to save power.
- Page 15 a. Check to see if the headset is fully recharged and that the Bluetooth mobile phone is well within effective operating distances. b. Ensure that both the earphone and Bluetooth headset are correctly connected. Unable to Connect a Call from the Phone Book or Call List a.
