Frigidaire FRT15B3A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT15B3A
  6. Factory parts catalog
Frigidaire FRT15B3A Factory Parts Catalog

Frigidaire FRT15B3A Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT15B3A:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT15B3AQ2
FRT15B3A
FRT15B3AT2
FRT15B3A
FRT15B3AW2
FRT15B3A
FRT15B3AZ2
FRT15B3A
MARKET
North America
WIRING DIAGRAM - 240379007
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - 240379007
ELECTROLUX HOME PRODUCTS,INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque-RH
R134a
bisque-LH
R134a
white-RH
R134a
white-LH
Publication No.
5995372959
020528
-EN/SERVICE /KC
390
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT15B3A
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT15B3A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT15B3A

Summary of Contents for Frigidaire FRT15B3A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT15B3AQ2 FRT15B3A R134a bisque-RH FRT15B3AT2 FRT15B3A R134a bisque-LH FRT15B3AW2 FRT15B3A R134a white-RH FRT15B3AZ2 FRT15B3A R134a white-LH MARKET North America WIRING DIAGRAM - 240379007 OWNER’S GUIDE - 240400105 TOP MOUNT SERVICE DATA SHEET - 240379007 REFRIGERATOR Model No.
