Elkay The Mystic MYSTIC211415 Specifications

SPECIFICATIONS

GENERAL
Highest quality contoured sink formed of #16 gauge, type 304
(18-8) nickel bearing stainless steel. Model MYSTIC211415
includes overflow assembly. Models MYSTIC211420CB
and MYSTIC211435CB includes cutting board.
DESIGN FEATURES
Bowl Depth: 6".
Finish: Exposed surfaces are polished to a lustrous starburst
satin finish.
Underside: Fully protected by heavy duty Sound Guard
coating designed to prevent condensation and dampen sound.
OTHER
Drain Opening: 1-1/2" (MYSTIC 2111415), 2" (MYSTIC211420CB),
3-1/2" (MYSTIC211435CB).
MYSTIC211415 comes with an overflow assembly.
NOTE: All Elkay undermount sinks are designed to affix
to the underside of any solid surface countertop.
Installation: See illustrated profile below.
These sinks comply with ASME A112.19.3.
SINK DIMENSIONS (INCHES)*
Overall
Model
Number L W
MYSTIC211415 23 3 / 16 13
16
MYSTIC211420CB 23 3 / 16 13
16
MYSTIC211435CB 23 3 / 16 13
16
*
Length is left to right. Width is front to back
**
Template and countertop mounting clips are packed with every sink.
14-3/16"
16-13/16"
Model MYSTIC211415 Illustrated
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
elkayusa.com
®
Inside Bowl
Cutout in
L W D Countertop
/ 20 3 / 14 3 / 6
16 8 16
See
/ 20 3 / 14 3 / 6
Template**
16 8 16
/ 20 3 / 14 3 / 6
16 8 16
.
20-3/8"
23-3/16"
2222 Camden Court
Oak Brook, IL 60523
The Mystic
® under-
Minimum
Cabinet
Size
27
27
27
The template provided with each sink provides
the only type of installation recommended by Elkay.
COUNTERTOP
MOUNTING
BRACKET
6"
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
® by Elkay Undermount Sink
Model MYSTIC2114 Series
Model MYSTIC211420CB
Model MYSTIC211420CB
(Without Cutting Board)
Cutting Board
Installation Profile
CONTOUR EDGE
TO CUSTOMER DESIRE
FASTENER
(NOT FURNISHED)
1-1/8"
Printed in U.S.A.
©2007 Elkay
(3/07)
1/4"
SILICONE CAULK
(NOT FURNISHED)
SINK
