SERIAL #:
Natural Gas Conversion Kit
F O R U S E W I T H M O D E L : 8 5 - 1 6 2 0 - 6 O N L Y / F O R O U T D O O R U S E O N L Y
T H I S N A T U R A L G A S C O N V E R S I O N K I T
C A N O N L Y B E U S E D W I T H C E N T R O
E N T E R T A I N M E N T I S L A N D 6 0 0 0 S I
M O D E L 8 5 - 1 6 2 0 - 6 .
Read and save this manual for future reference.
If pre-assembled, leave this manual with
unit for consumer's future reference.
Centro Customer Care Hotline
1-877-707-5463
D A N G E R
If You Smell Gas
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department.
W A R N I N G
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
W A R N I N G
Failure to follow all of the manufacturer's
instructions could result in hazardous
fires, explosions, property damage,
or serious personal injury or even death.
W A R N I N G
Follow all leak check procedures carefully
prior to operation of barbecue,
even if barbecue was store assembled.
Do not try to light this barbecue
without reading the Lighting Instructions
section of this manual.
T H I S B A R B E C U E I S F O R
O U T D O O R U S E O N L Y
Attention: Centro
recommends that a
®
qualified gas technician perform the
gas supply conversion and orifice replacement
for this BBQ model.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Centro Natural Gas Conversion Kit
Summary of Contents for Centro Natural Gas Conversion Kit
-
Page 1: Natural Gas Conversion Kit
T H I S B A R B E C U E I S F O R Centro Customer Care Hotline O U T D O O R U S E O N L Y... - Page 2 I N S T A L L A T I O N This kit converts your grill to natural gas at 7 inch water column supply pressure. • Verify supply pressure with your local gas company. If supply pressure is different than S A F E T Y P R E C A U T I O N S 7 inch, contact a certified plumber for assistance.
- Page 3 U S E A N D C A R E Natural Gas Connections and Service Regulators Above 1/2 psi. Prior to 1998, all residual gas service regulators were set with an outlet pressure of 7 inches water column. In the 1998 edition of NFPA 54, the National Fuel Gas Code, a change was made allowing service regulators of 2 and 5 psi.
- Page 4 C O N N E C T I N G Y O U R 1. A professionally-installed shut-off valve between the supply piping and the socket is recommended, but not required, by the National Fuel Gas Code. G R I L L T O T H E Socket connection must be made outdoors.
- Page 5 4. When the quick disconnect socket and the gas hose are connected, a valve in the sock- et opens automatically to permit full gas flow. When the gas hose is disconnected, the valve in the socket instantly and positively shuts off the flow of gas. Because the valve in the socket positively shuts off the flow of gas, the grill can be disconnected from the gas source by disconnecting the gas hose from the quick disconnect socket.
- Page 6 W A R N I N G Do not use hard metal piping of any kind to connect this type of grill to natural gas source. Use only hose specified by manufacturer. Using hard metal piping or convoluted metal tubing is an unsafe practice.
- Page 7 C A U T I O N Natural Hazard – Spiders FACT: Sometimes spiders and other small insects climb into the burner tubes attached to the burners. The spiders spin webs, build nests and lay eggs. The webs or nests can be very small, but they are very strong and can block the flow of gas.
- Page 9 P A R T S L I S T A N D D I A G R A M ( 8 5 - 1 6 2 1 - 4 ) The Natural Gas Conversion Kit includes: 1. NG hose 2. Orifice removal tool 3.
- Page 10 A S S E M B L Y I N S T R U C T I O N S Remove warming rack, cooking grates, flame tamers, and control knobs from Centro 6000SI BBQ.
- Page 11 Fig. A Screw Remove all burners including the 3 main U burners, by unscrewing the screw and nut that affix the burner to the burner support bar, as shown in Figure A. Fig. B Figure B shows all 3 main U-Burners removed. Fig.
- Page 12 Fig. A Using the Orifice removal tool provided, insert into hole on the rear of the control panel (Fig. A and B), inside the burner box. Tool will fit directly around the valve orifice. Once a connection is felt, turn the tool counter-clockwise to remove all orifices, including Sear Zone.
- Page 13 Fig. A Replace Rotisserie and Sear Zone Control knobs (Figure A). Only the 3 Main Burner Valves must be worked on in this step. Using the screwdriver tool provided, place the end of the screw driver into the valve stem (located on the front of the Control Panel as shown in Figure B).
- Page 14 Safety Check. Confirm the following: 1. All 4 orifices have been removed from valves (3 main U-Burner and Sear Zone Burner) 2. All 3 main U-Burner valve stems (Step 5) have been adjusted to a horizontal position. Once confirmed, the main burner conversion steps are com- pleted.
- Page 15 Fig. 8 Fig. A Remove the side burner from the unit (Fig.A). Fig. B Orifice removal tool Side Burner Using the orifice removal tool, remove the side burner valve orifice valve orifice (Figure B). (View from inside the garbage door, underneath the Multi-purpose Side Burner).
- Page 16 Fig. A Rotisserie Burner Orifice Replacement Rear Rotisserie Unscrew the 5 screws and nuts of the Rotisserie Burner from the Windshield 5 screws that need to Rear Windshield Cover, located on the back of the burner box. be taken out Fig.
- Page 17 Fig. A Unscrew the Wing nut by hand so that the orifice can be taken out from the Rotisserie Burner Venturi (Figure A). Result shown in Figure B. Use the orifice removal tool to take out the LP orifice, as shown in Figure C.
- Page 18 Fig. A Regulator Gas Supply Conversion hose Using a wrench, remove the hose and regulator inside the cart, as shown in Figure A. Then connect a NG hose and perform leak test and safety check on all maintenance. Fig. B Fig.
- Page 19 D I S T R I B U T O R Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8...
