PRODUCT NO.
BASE MODEL NO.
FRT18GS6AQ2
FRT18GS6A
FRT18GS6AW2
FRT18GS6A
MARKET
North America
WIRING DIAGRAM - 240379007
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - 240379007
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995369104
020327
-EN/SERVICE/DCS
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18GS6A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18GS6A
Summary of Contents for Frigidaire FRT18GS6A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18GS6AQ2 FRT18GS6A R134a bisque FRT18GS6AW2 FRT18GS6A R134a white MARKET North America WIRING DIAGRAM - 240379007 OWNER’S GUIDE - 240400105 SERVICE DATA SHEET - 240379007 TOP MOUNT REFRIGERATOR Model No. ELECTROLUX HOME PRODUCTS, INC FRT18GS6A P.O.
- Page 2 Publication No. FRT18GS6A 5995369104 DOOR 03/02...
- Page 3 FRT18GS6A Publication No. 5995369104 DOOR A = FRT18GS6A (FRT18GS6AQ2) B = FRT18GS6A (FRT18GS6AW2) POS. NO PART NO DESCRIPTION 240514605 Gasket-frzr door,white ,magnetic 240514606 Gasket-refr door,white ,magnetic 240311502 Support-door rack,2 liter ,RH 240311501 Support-door rack,2 liter ,LH 240337703 Door-dairy,w/o graphics ,clear 240331402 Rack-door,17.99"...
- Page 4 Publication No. FRT18GS6A 5995369104 CABINET 03/02...
- Page 5 FRT18GS6A Publication No. 5995369104 CABINET A = FRT18GS6A (FRT18GS6AQ2) B = FRT18GS6A (FRT18GS6AW2) POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462008 Cover-evap coil 240532102 Seal-coil cover...
- Page 6 Publication No. FRT18GS6A 5995369104 SHELVES 03/02...
- Page 7 FRT18GS6A Publication No. 5995369104 SHELVES A = FRT18GS6A (FRT18GS6AQ2) B = FRT18GS6A (FRT18GS6AW2) POS. NO PART NO DESCRIPTION 215667501 Tray-ice,plastic 240358002 Shelf-freezer,full width 5303299664 Spacer,shelf 240362502 Diffuser,air ,top 240362601 Diffuser,air ,bottom 240371304 Seal,foam ,air diffuser 240505801 Switch,light/lamp 240436701 Light Bulb/Lamp, A-15, 40 W, 120 V, miniature 241500701 Socket-light/lamp 240352701...
- Page 8 Publication No. FRT18GS6A 5995369104 SYSTEM 03/02...
- Page 9 FRT18GS6A Publication No. 5995369104 SYSTEM A = FRT18GS6A (FRT18GS6AQ2) B = FRT18GS6A (FRT18GS6AW2) POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Wiring Harness, machine compt, w/electric cord 6* # 240375501 Wiring Harness,control box 6* # 240385401 Wiring Harness,freezer section 14 # 5303918208 Defrost Heater Kit...
-
Page 10: Wiring Schematic
Publication No. FRT18GS6A 5995369104 WIRING SCHEMATIC 03/02... -
Page 11: Wiring Diagram
FRT18GS6A Publication No. 5995369104 WIRING DIAGRAM # = Fast-moving Parts 03/02 * = Non-Illustrated Parts...
