- Page 1 USER’S MANUAL Before using the TV, please read this manual thoroughly, and retain it for future reference. English ELCHS371 French ELDHS421 Spanish PART NO. IES080547...
-
Page 2: Table Of Contents
CONTENTS Important Safety Instructions ....................2 Preparation for using your new TV ...................4 Learning about your TV ......................4 View the front panel control ......................4 View the back connection panel (ELCHS371) ................4 View the back connection panel (ELDHS421) ................5 Selecting a location for the TV ....................6 Connection to other devices ......................6... -
Page 3: Important Safety Instructions
The lightning flash symbol with an arrowhead inside a CAUTION triangle alerts the user about an uninsulated dangerous voltage that may be of sufficient magnitude to constitute a risk of electric shock. RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF AN ELECTRIC SHOCK, The flash with the symbol of an exclamation point DO NOT REMOVE THE COVER (OR BACK). - Page 4 Important safety instructions POWER SOURCE : This TV should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company .
-
Page 5: Preparation For Using Your New Tv
Preparation for using your new TV Learning about your TV You can operate your TV via the buttons in the front cabinet or the remote control. The terminals in the back cabinet provide all the connections from other equipments to your TV. View the front connection panel Menu INPUT... -
Page 6: View The Back Connection Panel (Eldhs421)
Preparation for using your new TV Connection to other devices View the back connection panel (ELDHS421) Power Input AUDIO IN HDMI3 HDMI2 VIDEO SERVICE VIDEO COMP1 COMP2... -
Page 7: Selecting A Location For The Tv
Preparation for using your new TV Selecting a location for the TV 1. Place the TV on an open bench in a location where light does not directly hit the screen. 2. Place the TV far enough from the walls to allow proper ventilation. Inadequate ventilation may cause overheating, which may damage the TV. -
Page 8: The Side Panel Connection (Eldhs421)
Preparation for using your new TV The side panel connection (ELDHS421) The equipment with HDMI output jack ( such as DVD players, set-top boxes, etc.). HDMI1 VIDEO S-VIDEO HEADPHONE OPTICAL The equipment with AV or S-Video output function ( such as VCD, DVD, set-top boxes, etc.). -
Page 9: The Back Panel Connection (Elchs371)
Preparation for using your new TV The back panel connection (ELCHS371) The equipment with HDMI output jack ( such as DVD players, set-top boxes, etc.). Computer Update jack VGA AUDIO IN HDMI2 HDMI1 VIDEO SERVICE COMP2 COMP1 VIDEO RECORDER DVD With Component jacks... -
Page 10: The Back Panel Connection (Eldhs421)
Preparation for using your new TV The back panel connection (ELDHS421) The equipment with HDMI output jack ( such as DVD players, set-top boxes, etc.). Computer Update jack AUDIO IN HDMI3 HDMI2 VIDEO SERVICE VIDEO COMP1 COMP2 Video Recorder The equipment with AV output function ( such as VCD, DVD, set-top boxes, etc.). -
Page 11: Connecting Your Tv
Preparation for using your new TV Connecting your TV Caution: Do not plug in the TV until you have finished connecting all of your equipments. Connecting to an antenna To enjoy the televison program transmitted by your local TV station, you need an indoor or outdoor antenna (not supplied). -
Page 12: Connecting Hdmi
Preparation for using your new TV The Y, PB/CB and PR/CR” connectors on your component devices (PVR or DVD) are sometimes labeled Y, B-Y and R-Y or Y, CB and CR (Colors for inputs and cables must correspond to both devices). NOTE Some devices such as a PVR or DVD players require ’Component/YPBPR’... -
Page 13: Connecting To A Cable Converter Box
Preparation for using your new TV Connecting to a cable converter box This television has an extended tuning range and can tune most cable channels without using a cable converter box. Some cable companies offer premium pay channels in which the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the cable company. -
Page 14: Using The Remote Control
Using the remote control Preparing the remote control for use Installing the remote control batteries 1. Open the battery cover on the back of the remote control. 2. Install two AAA size(1.5V) batteries. Match the + and - signs on the batteries to the signs on the battery compartment. -
Page 15: Learning About The Remote Control
Using the remote control Learning about the remote control Power indicator INPUT: Switch among TV, Video, S-Video, Power ON/OFF INPUT Component,HDMI and VGA Mute: Mute the sound ZOOM: Select Screen Mode ZOOM MUTE PICTURE PICTURE AUDIO PICTURE: Select the picture mode AUDIO: Select the sound mode GUIDE: ATSC tuners feature the Electronic... -
Page 16: Understanding The Tv Features
Understanding the TV features Multimedia - All in one TV receiver, Video Monitor and PC display. Wider viewing angle for 16:9 and 4:3 display screens - over a 160 degree viewing angle and a 16:9 ergonomic display panel. Digital display device - Irrespective of magnetic or geomagnetic effects, this device accurately reproduces images without any distortion or blur. - Page 17 Basic operation Normal The original 4:3 aspect ratio (1.33:1 signal) is preserved, so black bars are added to the left and right of the image. Standard TV broadcasts are displayed with a 4:3 aspect ratio. Wide When watching a standard broadcast or full-frame movie in this mode, the display image is stretched proportionately to fill the TV screen.
-
Page 18: Adjust Volume
Basic operation Use [GUIDE] button Press the [ GUIDE ] button to display features of the ATSC program and the EPG function. Use [DISPLAY] button Press the [ DISPLAY ] button to view current source information. Use [EXIT] button Press the [ EXIT ] button to exit the OSD menu. -
Page 19: Video Mode Adjustment
Basic operation Video mode adjustment 1. Press MENU to open the OSD option 2. Press to highlight Video, then press to enter the Video menu. Video Picture Mode User Brightness Contrast Saturation Sharpness Color Temperature Cool Advanced Video : Select Adjust : Back 3. -
Page 20: Setup
Basic operation Balance - Adjusts the volume of the left and right speakers. Equalizer-You can select the frequency you want to adjust and change its value. Sound Surround -Turns the surround sound effect on or off. Auto Volume Control - Turns automatic volume control on or off. The option keeps the audio in a preset range to eliminate large spikes in volume. -
Page 21: Parental Control
Basic operation Parental control 1. Press MENU to open the OSD option 2. Press to highlight Parental , then press to enter the Parental menu. Parental Change Password Channel Block Input Block Program Block : Select ENTER : Enter EXIT: Exit When you first this function, the default assword is [0000]. - Page 22 Basic operation About MPAA Rating: The Motion Picture Association of America(MPAA) uses a rating system to qualify motion picture content. Television broadcasters employ a rating system to qualify the content of televison programs as well. The MPAA and TV ratings work with the V-CHIP feature and allow you to block out programming above the rating limits you determine.
-
Page 23: Tv Settings
Basic operation ? Input Block - You can block the input source with this function. For example, if you want to block AV input, just highlight [ ] and press [ENTER ]. The AV input will not be seen in the screen. Change Password - The first time you use this function, use the default password. -
Page 24: Base Installation Instruction
Appendix Base installation instruction (for ELCHS371 only) 1. Lay a cloth or other soft material that can afford adequate weight on a flat table to avoid damage to the LCD screen. 2. Put the TV back upward and the LCD screen downward and keep it flat on the table-board. 3. -
Page 25: Troubleshooting
Appendix Troubleshooting Before calling a service technician, please check the following table for a possible cause of the problem and some solutions. Customer important notice : If the TV can not be operated, please unplug the power and restart . Symptoms Possible Solutions §... -
Page 26: Specifications
Appendix Specifications Model ELCHS371 ELDHS421 37 inches 42 inches Diagonal display size Television system American TV standard ATSC /NTSC system Audio multiplex BTSC system VHF: 2~13 UHF: 14 69 CATV:1 ~125 Digital Terrestrial Broadcast (8VSB): 2 Channel coverage Digital cable (64/256 QAM): 1 PC mode 480I/60Hz,480P/60Hz,720P/60Hz,1080I/60Hz YPbPr/YCbCr mode...
