- Page 2 Stylus cover ········································ 1 using the latest tuning technologies. • A powerful magnet is used in the Stylus cleaning brush ························· 1 cartridge. Note that carelessly bringing a Stylus position adjustment gauge ······ 1 DENON (then Nippon Columbia Co., Ltd.) steel screwdriver or other such item near Owner’s Manual ································· 1 developed DL-103 jointly with NHK Science the cartridge will result in it being attracted Data sheet ·········································· 1 & Technical Research Laboratories to by the magnet and may result in damage Q0 Service Station list ·...
- Page 3 日本語 SVENSKA NEDERLANDS ESPAÑOL ITALIANO FRANCAIS DEUTSCH ENGLISH Mounting to the head shell Tracking force adjustment • To protect the stylus, be sure to mount the stylus cover when Tracking force in the range of 25 mN ±3 mN (2.5 g ±0.3 g) should be performing this procedure. used. • Adjust to the stylus position specified for the turntable system you are using and mount properly without tilting or turning it. Output voltage The output voltage is 0.3 mV. If your amplifier does not support • When adjusting the stylus position, the MC cartridge input, use a step-up transformer or head amplifier use the provided stylus position...
- Page 4 ENGLISH DEUTSCH FRANCAIS ITALIANO ESPAÑOL NEDERLANDS SVENSKA Specifications Principle: Moving coil (MC) type External Dimensions Diagram (unit: mm) Output Voltage: 0 .3 mV (1 kHz, 50 mm/s horizontal direction) Channel Balance: 1 dB max. (1 kHz) Channel Separation: 25 dB min. (1 kHz) Electrical Impedance: 40 Ω ±20 % Compliance: 5 x 10 m/N (Using a 100 Hz record) 0 .2 mm square solid diamond Stylus: Tracking Force: 2 5 mN ±3 mN (2.5 g ±0.3 g) Frequency Response: 2 0 Hz to 45 kHz Weight: 8.8 g Load Impedance:...
