ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FDB954SDC1
Series
Built-in 24"
Color
stainless
Owner's Guide
154448401
Service Data Sheet
154459001
Energy Guide
154485214
Installation Instructions 154427301
Market
North America
Publication No.
5995426300
05/01/11
(EN/SERVICE/ECL)
821
Copyright
24-INCH BUILT-IN
DISHWASHER
Model No.
FDB954SD
©
All rights reserved.
Advertisement
Related Manuals for Frigidaire FDB954SD
Summary of Contents for Frigidaire FDB954SD
- Page 1 Product No. FDB954SDC1 Series Built-in 24" Color stainless Owner's Guide 154448401 Service Data Sheet 154459001 Energy Guide 154485214 Installation Instructions 154427301 Market North America 24-INCH BUILT-IN P30L0032.EPS P30C0137.eps P30B0032.eps P30U0018.eps P30M0033.eps DISHWASHER P30F0022.eps P30R0066.eps ELECTROLUX HOME PRODUCTS, INC. Model No. P.O.
-
Page 2: Control Panel
Publication No: 5995426300 FDB954SDC1 CONTROL PANEL 01/05... - Page 3 FDB954SDC1 Publication No: 5995426300 CONTROL PANEL POS. NO PART NO. DESCRIPTION 154370303 Panel, control, black 154445003 Insert, control panel, black 154445801 Control, electronic 154200401 Screw, 6-10 x 3/8, pan plask 154287901 Cover, control 154422303 Nameplate, black 154433001 Vent assy, static dry 154436201 Screw, dry duct, (3) 34 #...
- Page 4 Publication No: 5995426300 FDB954SDC1 DOOR 01/05...
- Page 5 FDB954SDC1 Publication No: 5995426300 DOOR POS. NO PART NO. DESCRIPTION 154430501 Spring, door, (2) 154325201 Linkage, door spring, (2) 154093301 Screw, arm assy, (4) 154325304 Arm Assy, LH 154325303 Arm Assy, RH 154400601 Pin, arm assy 154079601 Nut, arm assy, and handle mtg. 154299004 Door, inner assy 154230103...
- Page 6 Publication No: 5995426300 FDB954SDC1 01/05...
- Page 7 FDB954SDC1 Publication No: 5995426300 POS. NO PART NO. DESCRIPTION 154209301 Tub assy, w/frame parts 154429101 Strike, door 154211801 Gasket, tub 154200602 Screw, 10-16 x 3/8, hex 154333902 Roller, tub 5303943103 Screw, w/washer, (8) 154446001 Tubing, water inlet 5303318539 Clamp, tubing, (2) 24 # 154525301 Hose, drain...
-
