Summary of Contents for Electrolux EWG 12440 W
- Page 1 User Manual Washing Machine EWG 12440 W...
- Page 3 Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable. You find some examples on the cover in this manual.
-
Page 4: Table Of Contents
4 contents electrolux Contents Safety information...5 Product description ...7 Control panel ...8 Use...9 Washing hints ...17 International wash code symbol ...20 Washing programme ...21-22 Programme information ...23 Care and cleaning ...24 Something not working...27 Techical data ...31 Consumption values ...32 Installation ...33... -
Page 5: Safety Information
Damage to the fabric can ensue if you over-fill. Refer to the manufacturer’s recommendations of quantities. safety information electrolux 5 ● Wash small items such as socks, laces, washable belts etc in a washing bag or pillow case as it is possible for such items to slip down between the tub and the inner drum. - Page 6 6 safety information electrolux ● If the appliance is installed in a location subject to frost, please read the “dangers of freezing”chapter. ● Any plumbing work required to install this appliance should be carried out by a qualified plumber or competent person.
-
Page 7: Product Description
The Eco Valve allows total use of detergent and reduces water consumption so saving energy. Detergent dispenser drawer Control panel Door opening handle Drain filter Adjustable feet Detergent dispenser drawer Prewash Wash Fabric Softener electrolux product description 7... -
Page 8: Control Panel
8 electrolux control panel Control panel Programme selector dial Temperature button Spin reduction button «Easy Iron» button «Extra Rinse» button «Delay» button Display Start/Pause button «Door locked» light Time manger buttons... -
Page 9: Use
Open the door by carefully pulling the door handle outwards. Place the laundry in the drum, one item at a time, shaking them out as much as possible. Close the door. use electrolux 9 and «Delay» buttons until the appears (disappears) on (from) - Page 10 10 electrolux use Measure out the detergent and the fabric softener Pull out the dispenser drawer until it stops. Measure out the amount of detergent required, pour it into the main wash compartment and, if you wish to carry out a programme with the «prewash»...
- Page 11 «Start/Pause» button ● at the end of the programme, the ● 0.00 display shows a « The pilot light (Door locked) goes out and the door can be opened. use electrolux 11 Spin » flashing.
- Page 12 12 electrolux use Select the Easy Iron option Selecting this button the laundry is gently washed and spun to avoid any creasing. In this way ironing is easier. Furthermore the machine will perform some additional rinses for cotton and synthetics.
- Page 13 Err is displayed for few seconds and the integrated red «Start/Pause» light start flashing. Alarm codes In the event of operating problems, some alarm codes can be displayed, for example “Something not working”). use electrolux 13 0.00 ». (see paragraph...
- Page 14 14 electrolux use End of programme When the programme has finished three flashing zero is displayed, the locked) and the «Start/Pause» go out and the door can be opened. Heating phase During the washing cycle the display shows the temperature icon to indicate that the appliance has started the heating phase of the water in the tub.
- Page 15 The washing water in the tub will not emptied out. Interrupting a programme Depress the «Start/Pause» button to interrupt a programme which is running, the corresponding light starts to flash. Depress the button again to restart the programme. use electrolux 15 Soil Level...
- Page 16 16 electrolux use Cancelling a programme Turn the selector dial to «O» to cancel a programme which is running. Now you can select a new programme. Opening the door after the programme has started First set the machine to pause by pressing the «Start/Pause»...
-
Page 17: Washing Hints
(e.g. hair clips, safety pins, pins). Button up pillowcases, close zip fasteners, hooks and poppers. Tie any belts or long tapes. washing hints electrolux 17 Remove persistent stains before washing. Rub particularly soiled areas with a special detergent or detergent paste. - Page 18 18 electrolux washing hints Removing stains Stubborn stains may not be removed by just water and detergent. It is therefore advisable to treat them prior to washing. Blood: treat fresh stains with cold water. For dried stains, soak overnight in water with a special detergent then rub in the soap and water.
- Page 19 The washing machine incorporates a recirculation system which allows an optimal use of the concentrated detergent. Pour liquid detergent into the dispenser drawer compartment marked before starting the programme. Any fabric softener or starching additives must be poured into the compartment marked starting the wash programme.
-
Page 20: International Wash Code Symbol
20 electrolux International wash code symbol International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature... -
Page 21: Washing Programme
Delicates example curtains. 40° - 30° For cancelling the wash programme which is running and for switching the machine off. washing programmes electrolux 21 Options Spin Red./No Spin/ Rinse Hold Easy Iron, Extra Rinse, Time Manage r Spin Red./No Spin/... - Page 22 22 electrolux washing programmes Washing programmes Programme/ Type of laundry Temperature Specially programme for wool garments bearing the Wool “Pure new wool, non- 40° - 30° shrink, machine washable” label. Special programme Handwash for hand washing 40° - 30° fabrics.
-
Page 23: Programme Information
To reset a programme and to switch off the machine turn the selector dial to «O». Now can a new programme be selected. programme information electrolux 23 option. option. Before selecting... -
Page 24: Care And Cleaning
24 electrolux care and cleaning Care and cleaning You must DISCONNECT the appliance from the electricity supply, before you can carry out any cleaning or maintenance work. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. - Page 25 When the bowl is full, hook the hose back up and empty the bowl. Repeat the procedure until water stops flowing out. care and cleaning electrolux 25 Unscrew and remove the filter. Clean carefully under a fast running tap. Warning!
- Page 26 26 electrolux care and cleaning Cleaning the water inlet filter If your water is very hard or contains traces of lime deposit, the water inlet filter may become clogged. It is therefore a good idea to clean it from time to time.
-
Page 27: Something Not Working
Service Centre. Malfunction The washing machine does not start: The machine fills then empties immediately: The machine does not fill: Something not working electrolux 27 Possible cause The door has not been ● closed. The plug is not properly ●... - Page 28 28 electrolux Something not working Malfunction The machine does not empty and/or does not spin: The door will not open: No water is visible in the drum There is water on the floor: Possible cause The drain hose is squashed ●...
- Page 29 29 Solution Increase the detergent ● quantity or use another one. Use commercial products to ●...
- Page 30 Something not working 30 electrolux Malfunction Spinning starts late or the machine does not spin: If you are unable to identify or solve the problem, contact our service centre. Before telephoning, make a note of the model, serial number and purchase date of your machine: the Service Centre will require this information.
-
Page 31: Techical Data
Information on the electrical connection is given on the rating plate on the inner edge of the appliance door Minimum Maximum Cotton Synthetics Delicates Wool/Handwash Silk/Lingerie Maximum technical data electrolux 31 60 cm 82 cm 54 cm 0,05 MPa 0,8 MPa 2.5 kg 2.5 kg 1200 rpm... -
Page 32: Consumption Values
32 electrolux consumption values Programme Cottons Normal 90° Cottons 60° Cottons + Prewash 90° Cottons + Prewash 60° Synthetics Normal 60° Synthetics + Prewash 60° Delicates 40° Wool 40° Handwash 40° Silk 30° Lingerie 40° Spin Drain Rinses The consumption data shown on this... -
Page 33: Installation
Installation Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all transit devices so that they can be refitted if the machine ever has to be transported again. 1. Using a spanner unscrew and remove the rear right bolt. - Page 34 34 electrolux installation 7. Plug the open holes with the plugs supplied with the instruction booklet. Positioning Install the machine on a flat hard floor. Make sure that air circulation around the machine is not impeded by carpets, rugs etc.
- Page 35 If it is too short and you do not wish to move the tap, you will have to purchase a new, longer hose specially designed for this type of use. Note ! Installation should comply with local water authority and building regulations’...
- Page 36 2. Onto a sink outlet spigot. If the outlet spigot has not been used before, remove any blanking plug that may be in place. Push the drain hose onto the spigot and secure with a clip if required, ensure a loop is formed in the drain hose (see diagram) to prevent waste from the sink entering the washing machine.
- Page 37 If you require any further advice please contact your local water authority. Electrical connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. Important! This appliance must be earthed. The manufacturer declines any liability should this safety measure not be observed.
- Page 38 38 electrolux installation The wire coloured blue must be connected to the terminal marked «N» or coloured black. The wire coloured brown must be connected to the terminal marked «L» or coloured red. Upon completion there must be no cut,...
-
Page 39: Built-In
The machine is originally pre-arranged for the assembly of a door opening from right to left. building-in electrolux 39 In this case it is sufficient to screw in the hinges (1) and the counter-magnet (6) provided with the appliance, at the right level (Fig. - Page 40 40 electrolux building-in The distance (B) from upper edge of the door to the centre of the hole depends on the adjacent furniture's dimensions. The required dimensions are given in the picture C. The hinges will be fixed to the door by means of screws for wood (2-Fig.
- Page 41 Fix the base firmly to the floor using four appropriate countersunk screws (see Fig. H). building-in electrolux 41 With the appliance installed adjust all four feet ensuring the machine is stable, and a clearance of approximately 5 mm is left between the top of the machine and the underside of the worktop.
-
Page 42: Environment Concerns
42 electrolux environment concerns Environment concerns Packaging materials The materials marked with the symbol are recyclable. >PE<=polyethylene >PS<=polystyrene >PP<=polypropylene This means that they can be recycled by disposing of them properly in appropriate collection containers. Old machine Use authorised disposal sites for your old appliance. -
Page 43: Guarantee Conditions
Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair... - Page 44 • The appliance is installed and used in ac-cordance with instructions issued by Electrolux and is only used within the home, i.e. is not used for commercial purposes. • The appliance is installed in...
- Page 45 +38 61 24 25 731 Slovensko +421 2 43 33 43 22 Suomi www.electrolux.fi Sverige +46 (0)771 76 76 76 Electrolux Service, S:t Göransgatan 143, S-105 45 Stockholm Türkiye +90 21 22 93 10 25 Россия +7 095 937 7837 www.electrolux.com Rr.
-
Page 46: Customer Service Centres
46 electrolux Notes... - Page 48 ANC number: 132 971 320 -00-242007...
