Summary of Contents for AEG Electrolux U32098 FM4863-an
- Page 1 FM4863-an Induction wok Installation and Operating Instructions...
-
Page 2: Dear Customer
Dear Customer, Please read these user instructions carefully and keep them to refer to later. Please pass the user instructions on to any future owner of the appli- ance. The following symbols are used in the text: Safety instructions Warning! Information that affects your personal safety. Important! Information that prevents damage to the appliance. -
Page 3: Table Of Contents
Contents Operating Instructions Safety instructions..........Description of the Appliance . -
Page 4: Operating Instructions
Operating Instructions Safety instructions Please comply with these instructions. If you do not, any damage re- sulting is not covered by the warranty. This appliance conforms with the following EU Directives: – 73/23/EEC dated 19.02.1973 Low Voltage Directive – 89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending Directive 92/31/EEC –... -
Page 5: Safety During Use
Safety during use • Overheated fats and oils can ignite very quickly. When cooking with fat or oil (e.g. chips) do not leave the appliance unattended. • Risk of burns! Fat or oil added to a pan which has already been heat- ed ignites very quickly and can spit. -
Page 6: Description Of The Appliance
Description of the Appliance Cooking surface layout Frontline strip Control panel layout Child lock pilot light Heat setting indicator Heat setting 6 / power function Child lock Wok niche 2300W with power function 3200W Control panel Timer indica- Timer Timer selection Heat setting selec- Heat setting indicator... -
Page 7: Touch Control Sensor Fields
Touch Control sensor fields The appliance is operated using Touch Control sensor fields. Functions are controlled by touching sensor fields. Touch the sensor fields from above, without covering other sensor fields. Sensor field On / Off Increase settings Reduce settings Timer Increase settings Reduce settings... -
Page 8: Residual Heat Indicator
Residual heat indicator Warning! Risk of burns from residual heat. After being switched off, the cooking zones need some time to cool down. Look at the residual heat indicator Residual heat can be used for melting and keeping food warm. Accessories Wok pan (supplied) •... -
Page 9: Operating The Appliance
Operating the appliance Only use a wok pan that is suited to this appliance. Switching the appliance on and off Control panel To switch on To switch off After switching on, within approx. 10 seconds a heat setting or a func- tion must be set, otherwise the appliance automatically switches itself off. -
Page 10: Using The Child Safety Device
Using the child safety device The child safety device prevents unintentional use of the appliance. Switching on the child safety device Step Switch on appliance. (Do not set a heat setting.) Touch Appliance switches off. The child safety device is switched on Deactivating the child safety device Step Switch appliance on... -
Page 11: Using The Timer
Using the timer Two functions are possible: Function Safety cut-out Countdown timer Setting the time Step Control panel Touch Touch The pilot light lights up. The time is set. The time counts down to 0. Switching timer function off Step Control panel Touch Touch... -
Page 12: Changing The Time
Changing the time Step Control panel Touch Touch The pilot light lights up. The time is set. The time counts down to 0. Safety cut-out Cooking surface • If after switching on the cooking surface, a heat setting is not set within approx. -
Page 13: Tips For Cooking With The Wok
Tips for cooking with the wok The induction wok is eminently suitable for preparing “á la minute” dishes, in particular Chinese specialities. The food is continuously turned during the short frying time. The induction heating system means that in the wok you can cook extremely quickly and at high heat. -
Page 14: Cookware For Induction Cooking Zones
Cookware for induction cooking zones Cookware material Cookware material Steel, enamelled steel Cast iron Stainless steel Aluminium, copper, brass Glass, ceramic, porcelain Cookware for induction cooking zones is labelled as suitable by the manufacturer. Suitability test Cookware is suitable for induction cooking, if … •... -
Page 15: Methods Of Preparation In The Wok
Methods of preparation in the wok Stir frying • Wok is swirled with oil. • Ingredients cut into small pieces, including sauces and seasonings, are quickly fried over a high heat while continuously being stirred. • Due to the extremely short cooking time the ingredients should be ready before you start cooking. -
Page 16: Cleaning And Care
Cleaning and Care Take care! Risk of burns from residual heat. Warning! Sharp objects and abrasive cleaning materials will damage the appliance. Clean with water and washing up liquid. Warning! Residues from cleaning agents will damage the appliance. Remove residues with water and washing up liquid. Cleaning the appliance after each use 1. -
Page 17: What To Do If
What to do if … Problem The cooking zone cannot be switched on or is not operating The residual heat indicator is not displaying anything Power function cannot be switched on lights up and number are dis- played It is very hard to adjust the heat settings Possible cause More than 10 seconds have... -
Page 18: Disposal
If you are unable to remedy the problem by following the above suggestions, please contact your dealer or the Customer Care De- partment. Warning! Repairs to the appliance are only to be carried out by quali- fied service engineers. Considerable danger to the user may result from improper repairs. -
Page 19: Installation Instructions
Installation Instructions Safety instructions The laws, ordinances, directives and standards in force in the country of use are to be followed (safety regulations, proper recycling in accord- ance with the regulations, etc.) Installation may only be carried out by a qualified electrician. The minimum distances to other appliances and units are to be ob- served. - Page 20 • This appliance’s mains cable must be a special cable (type H05BB-F Tmax 90°; or higher). The latter is available from the Customer Care Department. A device must be provided in the electrical installation which allows the appliance to be disconnected from the mains at all poles with a contact opening width of at least 3 mm.
-
Page 21: Assembly
Assembly... -
Page 23: Installing More Than One Frontline Hob
Installing more than one Frontline hob Additional parts: cross bar(s), heat resistant silicon, rubber block, shav- ing blade. Only use special heat-resistant silicon. Cut-out section Distance from the wall: at least 50 mm Depth:490 mm Width: The widths of all appliances to be built-in are added together, minus 20 mm (see also “Overview of all appliance widths”) Example: Installing more than one appliance... - Page 24 5. Place first appliance in the cut-out. Lay connecting cross bar in the cut-out and push up halfway against the appliance. 6. Put silicon on the appliance corners that will touch one another. Put silicon on the end of the cross bar. 7.
- Page 25 8. Place Frontline strips on the appliances. Check that the Frontline strips are in line with one another. 9. Tighten the fixing plate / retaining grip screws. 10. Inject a line of silicon into the gap between the appliances. 11. Dampen silicon line with a little soapy water. 12.
- Page 26 Overview of all appliance widths 180 mm Worktop-mounted cooker hood 360 mm Glass ceramic cooking surface with 2 radiation cooking zones Glass ceramic cooking surface with 2 induction cooking zones Gas hob with 2 burners Grill Grill/Deep fat fryer 580 mm Glass ceramic cooking surface with 4 radiation cooking zones Gas hob with 4 burners 720 mm...
-
Page 27: Rating Plate
Rating Plate 941 177 661 AEG-ELECTROLUX 3,2 kW 220-240 V 50/60 FM4863-an 59 WOK 01 AG... -
Page 28: Guarantee Conditions
Guarantee Conditions Belgium DECLARATION OF GUARANTEE TERMS. Our appliances are produced with the greatest of care. However, a defect may still occur. Our con- sumer services department will repair this upon request, either during or after the guarantee peri- od. The service life of the appliance will not, however, be reduced as a result. This declaration of guarantee terms is based on European Union Directive 99/44/EC and the provi- sions of the Civil Code. -
Page 29: European Guarantee
Tel.: 02.363.04.44 European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed below the appliance guarantee will move with you subject to the following qualifications:- •... - Page 30 Domáce spotrebièe SK, Seberíniho 1, 821 03 Bratislava +35 8 26 22 33 00 Konepajanranta 4, 28100 Pori Electrolux Service, S:t Göransgatan 143, +46 (0)771 76 76 76 S-105 45 Stockholm Tarlabaþý caddesi no : 35 Taksim +90 21 22 93 10 25 Istanbul 129090 Ìîñêâà, Îëèìïèéñêèé...
-
Page 31: Service And Spare Parts
Service In the event of technical faults, please first check whether you can remedy the problem yourself with the help of the operating instruc- tions (section “What to do if…”). If you were not able to remedy the problem yourself, please contact the Customer Care Department or one of our service partners. - Page 32 315 840 503-A-150906-01 Subject to change without notice...
