Product No.
FGHS2334KB0 FGHS2334KW0 FGHS2344KF0
Series
Gallery
Color
black
Volts
115
Wiring Diagram
241912901
Owner's Guide
241979200
Market
North America North America
Energy Guide
241935576
Service Data Sheet 240389638
Publication No.
5995533345
09/02/13
(EN/SERVICE/DCS)
137
Gallery
Gallery
white
stainless
115
115
241912901
241912901
241979200
241979200
North America
241935576
241935576
240389638
240389638
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FGHS2334K
FGHS2344K
Advertisement
Table of Contents
Related Manuals for Frigidaire FGHS2334K
Summary of Contents for Frigidaire FGHS2334K
- Page 1 Product No. FGHS2334KB0 FGHS2334KW0 FGHS2344KF0 Series Gallery Gallery Gallery Color black white stainless Volts Wiring Diagram 241912901 241912901 241912901 Owner's Guide 241979200 241979200 241979200 Market North America North America North America Energy Guide 241935576 241935576 241935576 Service Data Sheet 240389638 240389638 240389638 SIDE-BY-SIDE...
-
Page 2: Freezer Door
Publication No: 5995533345 FGHS2334K FREEZER DOOR N58FFDEAA0 02/09... - Page 3 FGHS2334K Publication No: 5995533345 FREEZER DOOR Model Index: A FGHS2334K (FGHS2334KB0) B FGHS2334K (FGHS2334KW0) C FGHS2344K (FGHS2344KF0) POS. NO PART NO. DESCRIPTION 241786008 A - C Gasket-frzr door, black, magnetic 241786004 - B - Gasket-frzr door, white, magnetic 240367301 A B C Bin-door, frzr-upper 240359001 A B C...
-
Page 4: Refrigerator Door
Publication No: 5995533345 FGHS2334K REFRIGERATOR DOOR N58RFDAAB4 02/09... - Page 5 FGHS2334K Publication No: 5995533345 REFRIGERATOR DOOR Model Index: A FGHS2334K (FGHS2334KB0) B FGHS2334K (FGHS2334KW0) C FGHS2344K (FGHS2344KF0) POS. NO PART NO. DESCRIPTION 241786007 A - C Gasket-refr door, black, magnetic 241786003 - B - Gasket-refr door, white, magnetic 240363701 A B C Bin-door, 2-liter 240338303 A B C...
- Page 6 Publication No: 5995533345 FGHS2334K CABINET N58BAAAAE1 02/09...
- Page 7 FGHS2334K Publication No: 5995533345 CABINET Model Index: A FGHS2334K (FGHS2334KB0) B FGHS2334K (FGHS2334KW0) C FGHS2344K (FGHS2344KF0) POS. NO PART NO. DESCRIPTION 240435911 A B C Cover-air duct 241719710 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test 14A# 241547901 A B C...
- Page 8 Publication No: 5995533345 FGHS2334K SHELVES 108A N58SJCAAD1 02/09...
- Page 9 FGHS2334K Publication No: 5995533345 SHELVES Model Index: A FGHS2334K (FGHS2334KB0) B FGHS2334K (FGHS2334KW0) C FGHS2344K (FGHS2344KF0) POS. NO PART NO. DESCRIPTION 241657601 A B C Shelf, flip up, wire 241657501 A B C Shelf, fixed, freezer 241657503 A B C Shelf, fixed upper, freezer 241552801 A B C...
- Page 10 Publication No: 5995533345 FGHS2334K CONTROLS 210A F58TEACAE0 02/09...
- Page 11 FGHS2334K Publication No: 5995533345 CONTROLS Model Index: A FGHS2334K (FGHS2334KB0) B FGHS2334K (FGHS2334KW0) C FGHS2344K (FGHS2344KF0) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft 241563601 A B C Bushing-motor mtg...
- Page 12 Publication No: 5995533345 FGHS2334K SYSTEM N58CAAAAC14 02/09...
- Page 13 FGHS2334K Publication No: 5995533345 SYSTEM Model Index: A FGHS2334K (FGHS2334KB0) B FGHS2334K (FGHS2334KW0) C FGHS2344K (FGHS2344KF0) POS. NO PART NO. DESCRIPTION 240333602 A B C Condenser 218679606 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System 241516901 A B C Cord-service...
-
Page 14: Ice And Water Dispenser
Publication No: 5995533345 FGHS2334K ICE & WATER DISPENSER F58XFCAAA0 02/09... - Page 15 FGHS2334K Publication No: 5995533345 ICE & WATER DISPENSER Model Index: A FGHS2334K (FGHS2334KB0) B FGHS2334K (FGHS2334KW0) C FGHS2344K (FGHS2344KF0) POS. NO PART NO. DESCRIPTION 218976419 A B C Tube-water inlet, valve to door 218976429 A B C Tube-water inlet, 97.50", brown/tan 218976915 A B C Tube-water inlet, inlet valve, to filter...
-
Page 16: Ice Container
Publication No: 5995533345 FGHS2334K ICE CONTAINER 37A 34 34 33 N58YBAAAA7 02/09... - Page 17 FGHS2334K Publication No: 5995533345 ICE CONTAINER Model Index: A FGHS2334K (FGHS2334KB0) B FGHS2334K (FGHS2334KW0) C FGHS2344K (FGHS2344KF0) POS. NO PART NO. DESCRIPTION 241716101 A B C Auger-ice 241685201 A B C Cam-drive 241734001 A B C Container-ice, bucket only 241685101 A B C Drum-ice disp 241734202...
-
Page 18: Ice Maker
Publication No: 5995533345 FGHS2334K ICE MAKER A R M A R M L O C L O C K E D K E D U N T U N T I N T I N T L A C L A C INSTALLATION PARTS N58I1151-1 02/09... - Page 19 FGHS2334K Publication No: 5995533345 ICE MAKER Model Index: A FGHS2334K (FGHS2334KB0) B FGHS2334K (FGHS2334KW0) C FGHS2344K (FGHS2344KF0) POS. NO PART NO. DESCRIPTION 218976419 A B C Tube-water inlet, valve to door 218976429 A B C Tube-water inlet, 97.50", brown/tan 218976915 A B C Tube-water inlet, inlet valve, to filter 240561701...
- Page 20 Publication No: 5995533345 FGHS2334K ICE MAKER A R M A R M L O C L O C K E D K E D U N T U N T I N T I N T L A C L A C INSTALLATION PARTS N58I1151-1 02/09...
- Page 21 FGHS2334K Publication No: 5995533345 ICE MAKER Model Index: A FGHS2334K (FGHS2334KB0) B FGHS2334K (FGHS2334KW0) C FGHS2344K (FGHS2344KF0) POS. NO PART NO. DESCRIPTION 240542901 A B C Cap-water valve 5303207328 A B C Screw, hex washer head, 8-15A x 1.000, (2) 5304456686 A B C Bracket-leveling, ice maker...
-
Page 22: Wiring Schematic
Publication No: 5995533345 FGHS2334K WIRING SCHEMATIC 02/09... -
Page 23: Wiring Diagram
FGHS2334K Publication No: 5995533345 WIRING DIAGRAM 02/09 # Functional Parts * Non-Illustrated Parts...
