Caple Oven Electronic Programmer Manual

A. Autotimer

The electronic programmer is a device which groups together the following functions: -
24 hour clock with illuminated display
•
Timer (up to 23 hours and 59 minutes)
•
Program for automatic oven cooking
•
Program for semi-automatic oven cooking.
•

Description of the buttons:

Timer
Cooking time
End of cooking time
Manual position and cancellation of programmed cooking.
Advancement of the numbers of all programs.
Turning back of the numbers of all programs and changing the frequency of the audible
signal.

Description of the lighted symbols:

AUTO - flashing - Programmer in automatic position but not programmed.
AUTO - always lighted - Programmer in automatic position with program inserted.
Automatic cooking taking place.
Timer in operation.
And AUTO - flashing - Program error.
(The time of day lies between the calculated cooking start and end time).
NOTE: Select a function using the respective button and, in 5 seconds, set the
required time with the
A power-cut makes the clock go to zero and cancels the set programs.

Electronic Clock

The programmer is equipped with an electronic clock with lighted numbers which indicates
hours and minutes.
Upon immediate connection of the oven or after a power-cut, three zeros will flash on the
programmer panel.
To set the hour it is necessary to push the
you have set the exact hour.
In another way push simultaneously the
the or button.
NOTE: The hour setting after programming deletes any program.

Electronic Programmer (6 Buttons)

/ buttons ("one-hand" operation).
Page 1 of 3
button and then the
two buttons and at the same time push
or button until
ELECTRONIC PROGRAMMER.DOC
