Califone HPK-series User Manual

6. TROUBLESHOOTING

No Sound / • Ensure cords are connected securely to the headphone/
Low Volume headset and the audio source/computer.
• Ensure the audio source is not muted and volume is up.
• For the headphones/headsets with a recharging jack, ensure
the battery is fully charged.
7. SPECIFICATIONS & FEATURES
Standard Kits • HPK-1000: Includes HPE-1000 & HPC-1000
• HPK-1010: Includes HPE-1010 & HPC-1010
• HPK-1020: Includes HPE-1020 & HPC-1020
• HPK-1030: Includes HPE-1030 & HPC-1030
• HPK:1040: Includes HPE-1000 & HPC-1020
• HPK-1050: Includes HPE-1010 & HPC-1030
Features • 40mm Neodymium transducers
• Adjustable Headband
• Adjustable uni-directional microphone (HPE-
1010 & HPE-1030)
• Excellent Isolation / Ambient Noise
Reduction
• In-line volume control
• Straight, replaceable cords.
• "Dishwasher Safe" (HPE-1000 & HPE-1010
only)
Plug Types
HPC-1000 & HPC-1010: USB plug
HPC-1020: Stereo 3.5mm plug with 6.5mm adapter
HPC-1030: Stereo 3.5mm plug + 3.5mm plug for mic
Frequency Response 20 Hz - 20 kHz
THD % < 2 % (80Hz - 20kHz)
Headphone Input Impedance 50 ohms
Limiter Level: 85 +/- 3 dB (No weighting) **
Speed: < 20 ms
** Depends on signal and ear/head-coupling.
Microphone (HPC-1010 & HPC- Uni-directional electret (requires bias voltage
1030) between 2 to 10 V)
Battery Usage Time (HPE-1020 & > 8 hours (depends on usage)
HPE-1030 only)
Battery Recharge Time (HPE-1020 & < 2 hours
HPE-1030 only)
Product Construction Earcups: ABS plastic
Earpads: PVC
Cords: Polyurethane
califone.com
Product Dimensions Headphones: 8.25" x 6.3" x 3"
HPC-1000 & HPC-1010: 7.5' total cord length
HPC-1020 & HPC-1030: 6.25' total cord length
Product Weight (incl. accessories)
HPC-series < 3 oz
HPE-series: < 10 oz
8. WARRANTY
Califone warrants this product to be free from defective material
and workmanship for one year from the purchase date. Our "Project
Intercept" Customer Satisfaction program will replace defective parts and
repair malfunctioning equipment under this warranty when the defect
occurs under normal use.
All Damage Claims Must Be Made With the Freight Carrier
Notify the freight carrier immediately if you observe any damage to the
shipping carton or product. Repack the unit in the carton and await
inspection by the carrier's claim agent. Notify your dealer of the pending
freight claim.
Returning Your Unit for Service or Repairs
Should your unit require service, contact our Customer Service
Department online at califone.com/techsupport or via email
warranty@califone.com or by phone at 800-722-0500 / 818-407-2400
to first obtain an RA (Return Authorization) number before returning
it to Califone. The unit must be returned to our factory via prepaid
transportation only after the factory issues an RA number, which must be
clearly written on the outside of the box.
Califone International, Inc.
®
1145 Arroyo Avenue, #A
San Fernando, CA 91340 USA
Toll Free 800.722.0500 | Toll Free Fax 877.402.2248
International Customers call 818.407.2400 or Fax 818.407.2405
califone.com
Califone HPK-series Rev 01 0710
Model HPK-series
Headphones/Headsets

User Manual
